PT-31E/PT-31W
User Manual
11-2012 / v1.1

Advertisement

Table of Contents
loading

Related Manuals for Edimax PT-31E

Summary of Contents for Edimax PT-31E

  • Page 1 PT-31E/PT-31W User Manual 11-2012 / v1.1...
  • Page 2 Edimax Technology Co., Ltd. reserves the right to revise this publication and to make changes from time to time in the contents hereof without the obligation to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    CONTENTS CHAPTER I: PRODUCT INFORMATION ....................... 4 1-1 Package Contents ..........................4 1-2 Getting Familiar with Your New Network Camera ................4 1-3 Camera Installation ..........................7 Chapter II Using Network IP Camera by Web Interface ................11 2.1 Locate the IP address of Network IP Camera ..................11 2.2 Connect to IP Camera’s Web User Interface and Install ActiveX Plugin ..........
  • Page 4 4-3-4 Schedule ..........................84 4-3-5 Event ............................86 4-3-6 Security ........................... 88 4-4 Video Playback ........................... 91 4-4-1 Advanced Search ........................93 4-4-2 Event Search ........................... 96 4-4-3 Video Playback ........................100 Chapter V Troubleshooting ........................103 Federal Communication Commission Interference Statement ..............104...

  • Page 5: Chapter I: Product Information

    CHAPTER I: PRODUCT INFORMATION 1-1 Package Contents Before you start using this product, please check if there is anything missing in the package, and contact your dealer to claim the missing item(s):  1 x Network camera  1 x Power adapter ...
  • Page 6 If the image looks fuzzy, try to turn this focus ring 3 - Focus ring clockwise or counter-clockwise to adjust focus until the image looks clear Receives voice 4 - Microphone There are 2 LED lights inside to indicate the operation of 5 - LED indicators this IP camera: Left: Network activity LED...
  • Page 7 When the IP camera is not functioning properly, you can 3 - RESET use a pen or similar object to press this reset button to reset the IP camera. You can also press and hold this button for more than 5 seconds to clear all settings of IP camera, include administrator password.

  • Page 8: Camera Installation

    second. IP camera will connect AP and set value during 5 ~10 seconds. 4 - DI/DO Digital input / output dry contacts. Connects to external connectors peripherals by wire. See next page for pin definitions. WARNING: DO NOT CONNECT POWERED CABLE! 5 –...
  • Page 9 Step 2: Insert mounting plate B into the slot at the bottom of the network camera. Step 3: Screw mounting plate B to the network camera via the 2 holes indicated by the arrows. Step 4: Mount the network camera on to the wall.
  • Page 10 Step 5: Screw mounting plate A and B together via the hole indicated by the arrow. Step 6: When mounted on the wall, the cables can pass through mounting plate A as in the picture. Step 7: Connect an Ethernet cable to the network camera via the Ethernet port.
  • Page 11 Step 8: Insert the DI/DO signal cable(s) into the DI/DO port. If you do not have DI/DO accessories, you can skip this step. Step 9: Connect the power adapter to the network camera, then plug the power adapter into a wall socket. The camera’s LED lights should light up after a few seconds, and the camera will test its pan and tilt motor within 1 minute.

  • Page 12: Chapter Ii Using Network Ip Camera By Web Interface

    Chapter II Using Network IP Camera by Web Interface 2.1 Locate the IP address of Network IP Camera You can use your new Network IP Camera by its web user interface via web browser. Currently the viewing system requirement for Network IP camera is: OS: Microsoft Windows XP/Vista/7 ■...
  • Page 13 Note: The contents of the CD-ROM can also be downloaded from the Edimax website: http://www.edimax.com/en/index.php 2. After the installation is complete, double-click the “EdiView_Finder” icon to execute the application. 3. Press ‘Discover’ button to search for all IP Cameras on your local network (make sure all IP Cameras are powered on and connect to local network first).

  • Page 14: Connect To Ip Camera's Web User Interface And Install Activex Plugin

    2.2 Connect to IP Camera’s Web User Interface and Install ActiveX Plugin When you know the IP address of IP Camera, you can connect to it by Internet Explorer web browser by entering its IP address in address bar. The use login screen will appear when you get connected: IP Camera’s administrator username is ‘admin’...
  • Page 15 For IE 9: Click ‘Install’ button located at the bottom of IE to install ActiveX plugin. If you’re prompted that: ‘Windows Firewall has blocked some features of this program’ Click ‘Allow access’, or IP Camera will not be able to function properly. When you’re installing Internet Explorer plugin, you may also be prompted that if you want to allow changes to be made to your computer: Click ‘Yes’...

  • Page 16: Viewing Live Video

    After ActiveX plugin is installed, you should be able to see the video stream from camera. NOTE: If this is the first time you use this IP Camera, you can refer to chapter 2.4 for instructions on Setup Wizard, which will guide you to complete the software setup of your new IP Camera.
  • Page 17 There are various controls on web page, here are descriptions of every control item: Item Description ‘Home’ button This button is visible in all setup pages of IP camera, and you can go back to live video view by clicking this button when you’re in other page.
  • Page 18 Click ‘Save’ button when you see the image you wish to save, and you’ll be prompted to indicate the folder on your computer to save image file. If you changed your mind and don’t want to save image file, click ‘Cancel’. ‘Start Video Record’...

  • Page 19: Client Settings

    2.4 Client Settings In ‘Client Settings’ menu, you configure basic IP camera settings like data transfer protocol and data storage folder. To access ‘Client Settings’ menu, click ‘Client Settings’ button on the left. The following screen will appear:...
  • Page 20 Here are the descriptions of every setup item: Item Description RTSP Select this option to use RTSP (Real-Time Streaming Protocol) to transfer video data. HTTP Select this option to use HTTP (Hyper-Text Transfer Protocol) to transfer video data. If you don’t know which one you should use, select ‘RTSP’. Folder Select a folder on your computer to save recorded video.

  • Page 21: Chapter Iii Advanced Configuration

    Chapter III Advanced Configuration If you wish to configure IP camera’s settings, you can access IP camera’s ‘Configuration’ menu, which provides various kinds of system setting. To access configuration menu, click ‘Configuration’ button on the left. The ‘Configuration’ submenu will appear, please pick a setup item you wish to configure. 3-1 System In this menu, you can configure basic IP camera settings like hostname and time.
  • Page 22 Here are the descriptions of every setup item: Item Description Host Name Input the IP camera’s hostname here, it can be any meaningful words or characters that will help you to identify this IP camera. You can use IP camera’s installation location as host name, and this will help you to identify IP camera when you have many IP cameras installed.

  • Page 23: Security

    Please note that if this IP camera can’t access Internet, you must have a time server on local area network, or set the time manually. Set Manually Set IP camera’s date and time manually. Please set current date and time by ‘Date’ and ‘Time’ dropdown menu. When you finish with above settings, click ‘Apply’...
  • Page 24 Here are the descriptions of every setup item: Item Description Password / Retype Input administrator’s new password in both ‘Password’ and ‘Retype Password Password’ field, and click ‘Modify’ button to change administrator’s (Administrator) password. Please note: Don’t forget administrator’s password! Or you’ll need to reset IP camera’s all settings to get administrator’s password recovered.

  • Page 25: Network

    3-3 Network You can configure the network camera’s general and advanced network settings here. 3-3-1 “General” Setup Page Set up IP address for this IP camera. This IP camera supports both IPv4 and IPv6 IP address. Here are the descriptions of every setup item: Item Description Select this option to assign an IP address to LAN port (or obtain...
  • Page 26 Available options are: DHCP IPv4: Obtain an IPv4 IP address from DHCP server on LAN automatically. DHCP IPv4 / IPv6: Obtain both IPv4 and IPv6 address from DHCP server on LAN automatically. Static IPv4 / IPv6: Assign an IPv4 / IPv6 address to IP camera manually.

  • Page 27: Advanced" Setup Page

    camera’s web configuration interface. RTSP Port Input RTSP port number. When this port number changes, you must change corresponding settings in external network devices (NVR or CMS software) so they can receive this IP camera’s video. RTP Data Port Input RTP data port number here. When you finish with above settings, click ‘Apply’...
  • Page 28 Here are the descriptions of every setup item: Item Description Multicast Enable video multicast: Multicast Group Address: Input multicast group address here, must be an address between 232.0.0.0 to 232.255.255.255. Multicast video port: Input port number for video multicast here. Multicast RCTP video port: Input port number for RCTP video here.

  • Page 29: Wireless

    you. You must register a dynamic IP service first. Currently this IP camera supports Dyndns, TZO and No-ip dynamic IP service.. Provider: Select dynamic IP service provider. Host Name: Input the host name you obtained from dynamic IP service provider. User name: Input user name used to login dynamic IP service provider.
  • Page 30 The descriptions of every setting in this menu will be given below: Item Description Wireless Select „Enable‟ to activate wireless network function of this IP camera, Connection select „Disable‟ to disable it. Network Type Select the network type of wireless connection. Available options are „Infrastructure‟...
  • Page 31 SSID Input the SSID of the wireless access point you wish to connect. It should be less than 32 alphanumerical characters. When you select a wireless access point above, it‟s SSID will be filled in this field automatically. However, if the SSID is not displayed (the wireless access point you selected choose to hide it‟s SSID), you have to know it‟s SSID and input it here, or you will not be able to connect it.
  • Page 32 connection. Configure via Click this button and this camera will enter PBC-style WPS Push Button connection state for 120 seconds. Please push „Start PBC‟ button on the wireless access point you wish to connect within 120 seconds to establish WPS connection (The remaining time will be displayed on the button).
  • Page 33 Method 2: USE PINCODE SETTING Step 1: Power on the wireless AP and the wireless network camera. Wait for 1 minute for both devices to be up and running. Step 2: Open web browser and logo in wireless server. Go to wireless/WPS setting page. Step 3: Open web browser and logo in wireless network camera.
  • Page 34 3-4 IP Filter When this IP camera is directly connected to Internet and not protected by firewall, this function acts like a mini built-in firewall to protect the safety of this IP camera and avoid attacks from hackers. Here are the descriptions of every setup item: Item Description Enable Filter...
  • Page 35 camera. If you want to remove a set of IP address from the list, click on the IP address and click ‘Remove’ button. IP Address Input the starting and ending IP address of IP address you wish to (Accepted IP list) deny connections here.

  • Page 36: Video

    3-5 Video You can adjust the image of the IP camera in this menu. There are 3 sub-menus in this menu: Image Setting, Video Setting, and Overlay, which can be accessed by tabs on the top: 3-5-1 Image Setting You can adjust the image parameters in this page. Here are the descriptions of every setup item: Item Description...

  • Page 37: Video Setting

    Shaprness Default Set all above values to default value ‘128’. Mirror Check ‘Vertical’ or ‘Horizontal’ box to flip the image vertically or horizontally, this will help to correct the orientation of image when IP camera is hanged bottom-up by camera holder. You can click both ‘Vertical’...
  • Page 38 Here are the descriptions of every setup item: Item Description H.264 Select the compression of main stream: H.264 / MPEG4. /MPEG4 Video Select video resolution. Resolution - H.264: 2048x1536 (QXGA) / 1920x1080 (1080p) 1280x960 (960p) / 1280x720 (720p) 720x480 (D1) / 640x480 (VGA) 320x240 (QVGA) - MPEG4:...

  • Page 39: Overlay Setting

    3-5-3 Overlay Setting You can adjust the video overlay parameters in this page. Here are the descriptions of every setup item: Item Description Enable Time Check this box to enable overlaying time stamp on video. Stamp Remove the Check this box to remove time stamp’s background color. You may background color find this will help the readability of time stamp text in some cases.

  • Page 40: Audio

    ‘Update’ button to use the picture. Please note that there are certain restrictions: - Select .bmp / .jpg / .jpeg image files only. - Image’s resolution should be less than 160 x 128, and can be divided by 4. - Do not upload image files that size is greater than 64KB. When you finish with above settings, click ‘Apply’...

  • Page 41: Motion

    Enable Speaker Check this box to enable speaker. If you don’t want people at IP camera (Speaker) to hear you, you can uncheck this box to disable it. Audio Type The format is fixed as G.711 (Speaker) When you finish with above settings, click ‘Apply’ button to save changes. 3-7 Motion This IP camera is capable to detect object’s motion, so IP camera will only record when there’s motion and save disk storage space.

  • Page 42: Ptz Control (Rs-485)

    Enable Check this box to enable this motion detection window. You can select (Window 1 to window 1 to 3 to enable up to 3 motion detection windows. When a Window 3) motion detection window is enabled, a rectangular will appear on camera’s view, with its title on the top.
  • Page 43 Here are the descriptions of every setup item: Item Description Enable RS-485 Check this box to enable RS-485 functionality. Use Pelco-D Select this option and RS-485 interface will output pan-tile control signal in Pelco-D format. This format is widely accepted by most of pan-tilt camera cradles.

  • Page 44: Event

    - Stop Bit: Select stop bit: 1 or 2. - Home/Up/Down/Left/Right: Input the command string used to move pan-tilt camera cradle to home or up/down/left/right position. You can click ‘Test’ button to send command string for testing. - Command 1 ~ 5: You can define extra pan-tilt camera cradle control strings here by giving it a name (Command Name) and command string (Hexadecimal Message).

  • Page 45: Settings

    3-9-1 Settings This page lists all existing events. You can click ‘Modify’ button to edit an existing event, or ‘Remove’ to delete an existing event. To create a new even, just click “New” button to add an Event setting. To add a new event, click ‘New’ button and the descriptions of every setup item is listed below:...
  • Page 46 Item Description Enable Setting Check this box to enable this event. If you just want to disable this event temporarily, you can uncheck this box to keep this event and disabling while not deleting it. Title Input any description text for this event so you can identify it quickly. You can use alphabets, numbers, and symbols include: !$-.@^_~ (no spaces allowed).

  • Page 47: Media

    3-9-2 Media You can define what kind of media file should be saved on designated media. Here are the descriptions of every setup item: Item Description One Snapshot Save a picture file when event is triggered. H.264 Video Save a H.264 video clip. You can also select the recording length before and / or after the time when event is triggered in ‘Pre Event’...

  • Page 48: Event Server

    3-9-3 Event Server You can define the details of remote media server: FTP (File), SMTP (Email), and Samba (File). A Samba server can be any computer running windows operating system with network neighbor function enabled. Many stand-alone network file server also support samba server function.
  • Page 49 on FTP server, like ‘upload/record’. If you want to save file on this FTP user’s home directory, you can leave this field blank. - Enable Passive Mode: Check this box to force IP camera to communicate with FTP server in passive mode (Some FTP Server may only work when you check this box, while others don’t).
  • Page 50 input Email server’s username and password in corresponding field. - Requires SSL Encryption: If your Email server required SSL encryption, check this box. Please note that some Email server uses different port number than standard port 25 when SSL encryption is used. - STARTTLS: If your Email server required STARTTLS encryption, check this box.

  • Page 51: Recording To Sd Card

    3-10 Recording to SD Card When a SD card is inserted into IP camera, you can save video files on it. Note: 1. Be sure that the SD Card format should be FAT32. The NTFS format cannot be supported by this camera. 2.

  • Page 52: Sdhc

    3-11 SDHC The IP camera module has an optional SD card slot PCBA board. The standard module does not include this board. The UI shows the capacity is 0 MB when the module without SD card slot and memory card. f you need the function please check the option when you place the order of the IP camera module.
  • Page 53 Set the time range then click “Search” then shows the records like below.

  • Page 54: Log

    3-12 Log You can check the usage log of IP camera here. In this page, you can click: 1. First page / Final page: Jump to first / final page of log. 2. Previous / Next: Jump to previous or next page of log. 3.

  • Page 55: Device Info

    3-13 Device Info You can check the information and network settings of this IP camera. These information are very useful when you need to repair or fix the problem of this IP camera. An example of device info page look like this:...

  • Page 56: Maintenance

    3-14 Maintenance You can do some maintenance job about this IP camera here. Here are the descriptions of every setup item: Item Description Reboot Click this button to reboot the IP camera. This function is useful when you find IP camera is not working properly.

  • Page 57: Language

    Upgrade Upgrade IP camera’s firmware. Click ‘Browse’ button to select a firmware image file on your computer first, then click ‘Upgrade’ button. 3-15 Language You can change the display language of web interface. Click ‘Language’ button and select one language. More languages may available in latest firmware file.

  • Page 58: Chapter Iv: Ediview 64-Channel Viewer

    CHAPTER IV: EDIVIEW 64-CHANNEL VIEWER 4-1 EdiView Installation Please follow the following instructions to setup EdiView on Windows Vista / 7 operating system. Please note: You must login as system administrator when you’re installing EdiView . 1. Locate EdiView setup file, and double-click on it to start EdiView software installation.
  • Page 59 2. You’ll see a User Account Control security warning message appear, click ‘Yes’ to continue. 3. Click ‘Next’ to continue. 4. Click ‘Install’ to begin installation.
  • Page 60 5. ase wait while installation is being performed. This may take few minutes to done, please be patient.
  • Page 61 6. The second part of installation will start automatically. 7. A new setup window will appear, please click ‘Next’ button to continue. 8. You can select a folder on your computer to install EdiView by clicking ‘Change’ button, or simply click ‘Next’ button directly to accept default folder.
  • Page 62 9. Click ‘Install’ to continue. 10. Installation will take few minutes, please be patient.
  • Page 63 11. Click ‘Finish’ when you see this message. EdiView is ready to use now. 12. MSDE (Microsoft SQL Database Engine) installation procedure will start at the same time. Please wait until it completes.
  • Page 64 13. You’ll be prompted that this program has compatibility issues, click ‘Run program’ to continue.

  • Page 65: Ediview Interface

    14. MSDE installation requires computer reboot to complete, click ‘Finish’ to reboot the computer. 15. A new icon will appear on your computer’s desktop, you can double click on it to start EdiView. 4-2 EdiView Interface To start EdiView , double-click EdiView icon on your computer’s desktop: Or click ‘Start’...
  • Page 67 You’ll see a User Account Control security warning message appear, click ‘Yes’ to continue. EdiView login window will appear. Default user ID is ‘admin’ and default password is ‘1234’, click ‘OK’ when ready.
  • Page 68 The main window of EdiView will appear: Date/Time, Remaining disk Exit space Snapshot camera selection Camera View Function Keys Split-screen mode selector...
  • Page 69 The descriptions of every item are listed as follow: Item Description Split-screen mode EdiView supports from 1 to 64 cameras split views. selector The video from IP camera will display in split-screen display cells, and you can view up to 64 IP cameras at the same time.
  • Page 70 Select the file, and click ‘Open’ button to use the picture as background picture. To add a camera, right-click on the background picture and select ‘Add Camera…’ A new window will appear: Select the camera you wish to add from ‘Camera’ dropdown list, and check the box ‘Image Lost’...
  • Page 71 ‘Motion Detected’ if you want to get a warning message when image lost of motion is detected, then select the direction of camera icon, this will help you to remember the orientation of camera on the EMAP. After you click ‘OK’ button, a camera icon will appear on EMAP with its camera number indicated: You can add more cameras to EMAP by repeating procedures listed above.
  • Page 72 Date / Time, Displays current date, time, and remaining disk Remaining Disk Space storage space. Exit Click this button to leave EdiView All camera’s video will displayed in ‘Camera View’ area: (This example picture shows a 4-split camera view with only 2 IP cameras configured) To select an IP camera, click its video and it will be highlighted;...

  • Page 73: Configuration

    The description of these items is listed as follow: Item Description Pan / Tilt control Click the direction arrow to control camera’s pan / tilt. Pan / Tilt speed Drag the slide bar to adjust the pan / tilt speed when you click pan / tilt control arrow.

  • Page 74: Device

    The configuration menu will appear. There are 6 sub menus in the configuration menu: Device (Add or remove IP camera / video server) Recording (Configure video recording) System (Configure system-wide settings) Schedule (Configure schedule recording) Event (Configure event recording) Security (Configure EdiView user list) Detailed descriptions of every sub menu will be given in following chapters.
  • Page 76 IP camera setup window will appear on the right: If your IP camera is located on local area network, click ‘Search’ button. Wait for few seconds or few minutes until the search is complete, and all IP cameras found on your local area network will be listed: In this example, an IP camera has been found at IP address 192.168.2.3.
  • Page 77 When an IP camera is found, you can also select it in the list and: View Image: View the live image from selected IP camera. Detail: Connect to selected IP camera’s web configuration menu. You can also select the video stream type you wish to use: Check ‘Enable Camera’...

  • Page 78: Recording

    Every IP camera has a check box, indicating if it is enabled. If a camera is not enabled, it will not be displayed in EdiView’s video view. You can also manage IP camera list by the following function: Enable All: Enable all IP cameras in the list. Disable All: Disable all IP cameras in the list.
  • Page 79 The descriptions of every item are listed as follow: Item Description Select Camera All IP camera’s Please select an IP camera from the list to setup its recording behavior. EdiView will attempt to connect to selected IP camera, if it’s not connectable, you’ll receive an error message later.
  • Page 80 Use the mouse to click blocks on the grid pattern to assign the areas you wishes EdiView to detect / ignore motion. EdiView will detect motion for areas which are NOT covered by blocks only. To add or erase blocks: To add blocks, click + button;...

  • Page 81: System

    Drag the slide bar to setup sensitivity level from 1 to 10. Larger number indicates more sensitivity. To apply this motion detection settings to all IP cameras, click ‘Apply to All Cameras’ button. When you finish setting, click ‘OK’ button to save changes you made, or click ‘Cancel’ button to discard all settings you made.
  • Page 82 No: Do not display caption on camera view Camera ID: Display Camera’s ID number Camera ID + Camera Name: Display both camera’s ID and camera’s name. Data Storage Setting Setup hard disk data storage: Enable Recycle: Check this box and the latest recording video will overwrite oldest recorded video file automatically.
  • Page 83 you specified here, you’ll receive an alarm message to notify you should do something to prevent from running out of storage space. Start-up Condition Select the behavior of EdiView when computer starts up. You can select multiple options you want to use: Auto run, when Windows start: Check this box and EdiView will run automatically when computer starts.
  • Page 84 same domain name. Receiver: Input the E-mail receiver’s address here. CC: input additional E-mail receiver’s address here. Subject: Input the subject of sent E-mail. This will also help you to identify the E-mail sent by EdiView . Number of attachments: Input the number of snapshot attachments that will sent with E-mail, so you can see the image of camera by E-mail (1 to 10 attachments only).

  • Page 85: Schedule

    4-3-4 Schedule You can configure recording schedule in this sub-menu. When you enter this sub-menu for first time, click ‘Add Job’ button to add a new schedule recording job:...
  • Page 86 A new window will appear on the right: You can configure a new schedule recording job here. The descriptions of every setup items are listed as follow: Item Description Weekly Schedule Select the time period in a week of this schedule.

  • Page 87: Event

    ‘DEL’ first, then click the time period block. Events Select the event to trigger recording: Round-The-Clock: Recording is time-activated (according to schedule). Motion Detection: Recording is motion-activated. DI Input: Recording is activated by DI (Digital Input) signal located on IP camera. IP camera must have DI port and not every IP camera is equipped with DI.
  • Page 88 EdiView can send you an alarm E-Mail message so you can know something happened on the IP camera (motion detected, video lost, or connection lost). A sound can be played to notify the operator at the computer where EdiView is installed, too. To add a new event, click ‘Add’...

  • Page 89: Security

    you want to specify more than one alarm condition for the same IP camera, Trigger Operation(s) Define the action which will be taken when alarm is triggered: Send E-Mail: an E-mail will be sent when alarm is triggered. Play Sound: Play a sound on the computer where EdiView is installed.
  • Page 90 There are two kinds of user in EdiView: Administrator and user. Administrator can configure EdiView, while user can only view video of camera, and perform limited system configuration (schedule, record, and video playback).
  • Page 91 Administrator’s user ID is always be ‘admin’ and cannot be changed. You can only change admin’s password in Administrator’s ‘Password’ and ‘Confirm Password’ field. Please input the same password in both fields for confirmation. To add a user, click ‘Add’ button, a new window will appear on the right:...

  • Page 92: Video Playback

    The descriptions of every setup items are listed as follow: Item Description User ID Input the user ID used to login EdiView Description Input any descriptive text to help you to memorize the purpose of this user ID. Password / Input this user’s password in both fields.
  • Page 93 A new window will appear: To play a recorded video, you can use one of following two functions: Advanced Search Event Search Please refer to following chapters for detailed instructions of every search mode.

  • Page 94: Advanced Search

    4-4-1 Advanced Search You can search for recorded video within specific time period, and get a list of record modes of all IP cameras. When you enter this menu, please specify start time and stop time: Hour in a day DATE (You can input 0 - 23 in ‘Hour in a day’...
  • Page 95 When you finish, click ‘SEARCH’ button to search for recorded video, and you’ll get a similar output like this: In this picture, a recorded video of ‘Camera 1’ has been found at 12 o’clock. A blue mark indicates it’s a ‘Round Clock’ (manual) recording. Other record type include: Blue: Manual Recording Green: Recording is triggered by motion...
  • Page 96 And the video will be prepared for playback.

  • Page 97: Event Search

    4-4-2 Event Search You can search for video for playback by triggering event: round the clock, motion detection, or digital input.
  • Page 98 To search for video, you have to specify: 1) starting and ending time for video searching in ‘Start time’ and ‘Stop time’ field 2) Recording mode: Round Clock, Motion Detection, and I/O Mode (Digital Input). You can check all boxes you wish to search for. 3) Camera: You can check all cameras you wish to search for video.
  • Page 99 When you finish, click ‘Search’ button to search for recorded video, and a list similar to this will appear: You can select the video clip you wish to play, and click ‘Play’ button.

  • Page 101: Video Playback

    4-4-3 Video Playback When a video is loaded, the video playback screen will look like this: Close Time Window Search / Capture Speed Control Video Position Video Playback Control Indicator The descriptions of every item are listed as follow: Item Description Close Window Click X mark to close video playback window.
  • Page 102 Pause a playing video, click ‘Play’ to resume video playback Skip to next video frame Skip to the ending position of video clip Speed Control When video is stopped, you can click + or – button to adjust video playback speed: from 1/4 to 4x speed. You cannot adjust video playback speed when video is playing.
  • Page 103 You can click ‘Save as’ button to save current image (you’ll be prompted for image saving location), or click ‘Print’ to print current image to printer. To back to previous menu, click ‘Cancel’; click ‘Reset’ to reset image parameters back to default value. Time Current time will be displayed here.

  • Page 104: Chapter V Troubleshooting

    Chapter V Troubleshooting Please don’t panic when you found this IP Camera is not working properly. Before you send this IP Camera back to us, you can do some simple checks to save your time: Problem Possible solution(s) description Can’t 1) Please check the IP address of IP Camera again.

  • Page 105: Federal Communication Commission Interference Statement

    Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 106 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2004/108/EC, 2006/95/EC. French: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2004/108/EC, 2006/95/EC. Czechian: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanovení mi směrnic 2004/108/EC, 2006/95/EC.

  • Page 107: Declaration Of Conformity

    Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European directive 2004/108/EC and 2006/95/EC. Equipment: 3Mpx PoE Day & Night PT Network Camera Model No.: PT-31E Report No.: T110906220-E, T110906220-LV...
  • Page 108 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive and EMC directive, ETSI. Equipment: 3Mpx Wireless Day & Night PT Network Camera Model No.: PT-31W...
  • Page 109 This product includes software that is subject to the GNU General Public License version 2. The program is free software and distributed without any warranty of the author. We offer, valid for at least three years, to give you, for a charge no more than the costs of physically performing source distribution, a complete machine-readable copy of the corresponding source code.
  • Page 110 2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided that you also meet all of these conditions: a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of any change.
  • Page 111 License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not distribute the Program at all.
