User's Guide
VersaTools
®
High Resolution Video and Audio
Mini Twisted Pair Transmitters and Receivers
MTP 15HD A Series
68-956-02 Rev. C
07 08

Advertisement

Table of Contents
loading

Related Manuals for Extron electronics MTP RL 15HD A SEQ

Summary of Contents for Extron electronics MTP RL 15HD A SEQ

  • Page 1 Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia 1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Rd. #04-01 Anaheim, CA 92805 3821 AH Amersfoort, The Netherlands PM Industrial Bldg., Singapore 368363 800.633.9876 714.491.1500 +800.3987.6673 +31.33.453.4040 +800.7339.8766 +65.6383.4400 FAX 714.491.1517 FAX +31.33.453.4050 FAX +65.6383.4664 www.extron.com...
  • Page 2 Precautions Safety Instructions • English Warning This symbol is intended to alert the user of important Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended to be used with a main operating and maintenance (servicing) instructions power system with a grounded (neutral) conductor.
  • Page 3 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Table Of Contents

    MTP 15HD A Series About this Manual ... 2 About the MTP Transmitters and Receivers Twisted pair (TP) cable advantages ... 4 Transmission distance ... 4 End Unit Receiver DIP Switch ... 6 Installation ... 6 Rack mounting ... 6 ... 6 UL guidelines ...

  • Page 5: Versatools Mtp 15Hd A Series

    MTP T 15HD A transmitter. • The term “receiver” refers to either of the receiver models — the MTP RL 15HD A or MTP RL 15HD A SEQ. • The term “SEQ receiver” refers specifically to the MTP RL 15HD A SEQ receiver with skew equalization capabilities.

  • Page 6: Twisted Pair (Tp) Cable Advantages

    For example, the maximum suggested range for 1024 x 768 video is 300' (90 m) with the Pre-Peak switch off and 500’ (150 m) with the Pre-Peak switch on, whether the system consists of one transmitter and one receiver or a transmitter and three daisy-chained receivers.

  • Page 7: End Unit Receiver Dip Switch

    VersaTools ® MTP 15HD A Series, cont’d End Unit Receiver DIP Switch Set the receiver’s rear panel End Unit DIP switch up only if either of the following is true: • The receiver being configured is the only receiver connected to the transmitter.

  • Page 8: Back Of The Rack Mounting Instructions

    VersaTools ® MTP 15HD A Series, cont’d M TP T VG M TP T VG M TP T VG Figure 2 — Mounting the MTP on a standard shelf On the non-VersaTools rack shelves, the MTP can be mounted in the front or the rear of the rack.

  • Page 9: Furniture Or Projector Mounting

    VersaTools ® MTP 15HD A Series, cont’d Mount the unit to the rack using the two included rack screws (figure 4). The MTP can be vertically mounted facing in either direction. Rear IN P Figure 4 — Typical back of the rack installations Furniture or projector mounting Use one of the following optional mounting kits to mount the MTP under furniture or to a projector mount (figure 5).

  • Page 10: Connections And Settings

    The stereo audio input is summed and output on the TP cable as mono audio. Twisted pair connection and settings Pre-Peak switch — The Pre-Peak switch alters the TP signal output to correct for long cable runs. See the table on page 5 for suggested switch settings based on the transmitted video format and transmission distance.

  • Page 11: Receiver

    For example, the maximum suggested range for 1024 x 768 video is 300' (90 m) with the Pre-Peak switch off and 500’ (150 m) with the Pre-Peak switch on for either one transmitter and one receiver or a transmitter and three daisy-chained receivers.

  • Page 12: Power Supply Wiring

    MTP 15HD A Series • Connections and Settings MTP 15HD A Series • Installation 1 2 3 4 5 6 Video End Unit switch (6) — Set this switch up if either of the following is true: • The receiver being configured is the only receiver connected to the transmitter.

  • Page 13: Tp Cable Termination

    The audio data that is carried on wire pair 3 and 6 is incompatible with the Extron TPX 88A, which cannot switch the audio, output it locally, or break it away. Enhanced Skew-Free A/V cable is not recommended for Ethernet/LAN applications. This cable is specially designed for compatibility with Extron’s Twisted Pair...

  • Page 14: Front Panel Controls And Indicators

    MTP T 15HD A transmitter M T P S E R I E S MTP RL 15HD A receiver LEVEL M T P S E R I E S MTP RL 15HD A SEQ receiver DELAY LEVEL SELECT GREEN BLUE M T P S E R I E S Figure 12 —...

  • Page 15: Skew Delay Compensation

    Non-SEQ receiver skew compensation Try using the following methods to minimize or eliminate pair skew: • Switch to Extron’s Enhanced Skew-Free A/V UTP cable. • Add a skew compensation cable equal to the length of pair skew to the receiver’s output.
  • Page 16 Max. input voltage (transmitter) 5.5 V p-p Polarity Transmitter ... Positive or negative (follows input polarity) Receivers ... Positive or negative (switch-selectable) Audio Number/signal type ... 1 set of proprietary analog signals Connectors ... 1 female RJ-45 Gain ... Unbalanced output: 0 dB;...

  • Page 17: Part Numbers

    MTP transmitter and receivers for non-CAT 7 cable Part MTP T 15HD A transmitter MTP RL 15HD A receiver MTP RL 15HD A SEQ receiver MTP transmitter and receivers for CAT 7 cable Part MTP C7 T 15HD A transmitter...
  • Page 18 VersaTools ® MTP 15HD A Series, cont’d ® ® VersaTools VersaTools MTP 15HD A Series • Installation MTP 15HD A Series • Part Numbers...
