- Page 2 WARNING To move set, push from left side of set. Casters on right side do not pivot in all directions. Set can tip over if moved from right side, with risk of personal injury. ADVERTENCIA Para mover el conjunto, empuje desde el lade izquierdo del mismo.
-
Page 3: Table Of Contents
TABLE OF CONTENTR Table of Contents Congratulations ............Customer Record ................Care and Cleaning ................Specifications ..................Installation ..............Television Location ................Optional Cable Connections ............... AC Power Supply Cord ............... Cable / Antenna Connections ............. Optional Equipment Connections ......VCR Connection ................. -
Page 4: Congratulations
This PTV is also DTV (Digital TV)-compatible. When connected to a Panasonic digital TV set-top box, this TV can display high-definition (HDTV) 1080i and 720p formats and standard definition (SDTV) 480p and 480i formats. Your new PTV is designed to give you many years of enjoyment. -
Page 5: Installation
INSTALLA TION Installation Television Location This unit can be used as part of an entertainment center. Consult your dealer for available options. Avoid excessive sunlight or bright lights, including reflections. Keep away from excessive heat or moisture. Inadequate ventilation may cause internal component failure. -
Page 6: Optional Equipment Connections
INSTALLA TION Optional Equipment Connections VCR Connection Follow this diagram whenconnecting your televisionto a VCR only. TERMINALS ON BACK OF TV COMPONENT SPEAKER INPUT VIDEO INPUT 50 W (OIN) MAX El:: ANT INPUT LAU_IO_ ANT OUTPUT oming CABLES NOT SUPPLIED Note: The remote control must be programmed... -
Page 7: Front An Input Jacks
INSTALLA TION Optional Equipment Connections (Cont.) Front A/V Input Jacks Open the door on the TV front panel to use the connections for your optional equipment. Press the TV/VIDEO button to select VIDEO 3 input mode. CONNECTIONS ON FRONT OF TV _-_,o_o v,o_o _-A_o,o_ __ Note: A second... -
Page 8: Vcr And Cable Box Connection
INSTALLA TION Optional Equipment Connections (Cont.) VCR and Cable Box Connection Follow this diagram when connecting your television to both a VCR and a cable box. TERMINALS ON BACK OF TV COMPONENT LAUOI_ CABLES NOT SUPPLIED Note: The remote control must be programmed with supplied codes to operate the VCR and cable box. -
Page 9: Amplifier Connection (To Audio Amp)
INSTALLATION Optional Equipment Connections (Cont.) Amplifier Connection (TO AUDIO AMP) Connect to an external audio amplifier input for listening through a stereo system. Note: TOAUDIO AMP terminals cannot be connected directly to external speakers. Audio Adjustments Select SPEAKERS ON located in the onscreen AUDIO menu. Set amplifier volume to minimum. -
Page 10: Home Theater Connection
INS TA LLA TION Home Theater Connection Your TV can be configured to use the TV speakers as center channel speakers in Dolby* surround sound transmission. Connect a Dolby surround sound amplifier to CENTER CHANNEL INPUT on the back of the TV, as shown. EXT & FIXED AUDIO OUT must be selected in the AUDIO Roller Guide TM** Menu under SPEAKERS. -
Page 11: Split Screen Operation
SPLIT SCREEN OPERA TION Split Screen Operation This television includes a two tuner split screen feature. This allows watching two (2) live broadcasts at the same time with or without an external video source (VCR). Note: The Remote Control must be programmed with suppfied codes to operate the VCR and Cable Box. -
Page 12: Roller Guide Menu
ROLLER GUIDE MENU Roller Guide Menu_M ROLLER GUIDE MENU SELECTIONS [o 1 AUDIO LOCK TIMER LC_A_N_;_J LOCK SET UP PI(TURE AUDIO Basic Navigation Procedure Press the ACTION button in the middle of the large blue button on the remote control to display the Roller Guide Menu Note: Be carefa/ to press the ACTlON button in the midd/e of the button, ff you do... -
Page 13: Roller Guide Menu Chart
ROLLER GUIDE MENU CHART Roller Guide Menu Chart SET UP _SET UP LANGUAGES Select English, Spanish, or French menu. £3 MODE - Select Cable or TV (Antenna). See Installation section in Manual. ANTENNA - Select ANT 1 or ANT 2. See PROG. - Page 14 ROLLER GUIDE MENU CHART Roller Guide Menu Chart (Cont.) SURROUND SPATIALIZER ® Three dimensonal! surround sound with two speakers. £3 AUDIO SOURCE TV - speakers operate normally. EXT & VAO (Variable Audio Output) - SPEAKERS TV speakers off - audio adjustable by TV. EXT &...
- Page 15 ROLLER GUIDE MENU CHART Roller Guide Menu Chart (Cont.) COLOR TEMP - Adjust white balance to COOL (blue), WARM (red) or NORMAL. SCAN MODE - Picture adjustment when switching between video games and DTV OTHER ADJ. picture, if needed. (Adjustments) COLOR MATRIX - Select HD OR SD to automatically...
-
Page 16: Special Features
SPECIAL FEATURES Special Features SET UP Menu Languages In SET UP Menu, select IDIOMA / LANGUE to change menu language to ENGLISH, ESPAI_IOL (Spanish) or FRAN(_AIS (French). MODE ENGLISH ,m,_ImJ_L_r_q Prog Chan (Program Channels) In SET UP menu under PROG CHAN select: _3 MODE to select TV (antenna)or CABLE modedependingon the signal source. -
Page 17: Closed Caption
SPECIAL FEATURES (Closed Caption) This television contains a built-in decoder that displays (Closed Caption) text across the screen (white or colored letters on black background). It allows the viewer to read the dialogue of a television program or other information. The program viewed must include Closed Captioning for the feature to work. -
Page 18: Convergence
SPECIAL FEA TURES Convergence In SET UP menu, select CONVERGENCE under OTHER ADJ. only after moving the PTV to adjust for the effects of the earth's magnetic field on the projection tubes. CONVERGENCE Note: Convergence seldom needs adjusting, except when moving the TV Use the navigation buttons to align the horizontal... -
Page 19: Sleep Timer
SPECIAL FEATURES TIMER Sleep in TIMER menu, select SLEEP to turn TV off in 30, 60 or 90 minutes. Select NO to turn off timer. HOW LONG? Timer 1 and Timer 2 In TIMER menu, select one or both timers to turn the television on and off at selected times, on selected channels, and on selected days. -
Page 20: Picture Adjustments
SPECIAL FEATURES PICTURE Other Adjustments In PICTURE menu under OTHER ADJ., select: COLOR TEMP (temperature) to increase or decrease WARM (red) and COOL (blue) colors to suit personal preferences. SCAN MODE select TV or GAME to do picture adjustment when switching between video games and DTV picture, if needed. -
Page 21: Favorite Channels And Captions
SPECIAL FEATURES CHANNELS Favorites In CHANNELS menu under FAVORITES select: CHANNEL SCAN FAV to enter up to 16 favorite channels CHANNEL SCAN ALL to scan all channels when using the CH up/down buttons. CHANNEL SCAN FAVOI_IITES ENTER CHANNEL FAVORITE CHANNELS Caption In CHANNELS menu under CAPTION... -
Page 22: Lock
SPECIAL FEATURES LOCK Mode To use LOCK options: ENTER CODE FIRST - Use the numeric keypad to enter a four-digit secret code. After entering your secret code for the first time, the onscreen display will change to CHANGE CODE. Note: Use a code that is easy to remember or record it in a safe place. -
Page 23: Digital Tv Set-Top Box (Dtv-Stb) Connection
DIGITAL TV- (DTV-STB) SET-TOP CONNECTION Digital TV - Set-Top Box (DTV-STB) Connection Use this diagram to connect the Panasonic DTV-STB (Digital TV-Set-Top Box) to the back of your TV. DTV TERMINALS ON BACK OF TV OTV TERMINALS ON BACK OF DTV-STB... -
Page 24: Glossary
SDTV-compatible TV models process and display the standard definition output with the use of a Panasonic DTV-STB at 480 lines, interlaced or progressive scan. When DTV programming is available, you can view it in the standard format, 4:3 aspect ratio. -
Page 25: Frequently Asked Questions About Digital Tv
FREQUENTLY ASKED QUESTIONS ABOUT DIGITAL TV Frequently Asked Questions About Digital What is digital TV (DTV)? In April, 1997, the FCC (Federal Communications Commission) announced that, by 2006, all television broadcasting will be digital. Digital TV broadcasting delivers crystal-clear pictures, approaching the quality of 35mm movies and CD (compact disc) sound. -
Page 26: Troubleshooting Chart
TROUBLESHOOTING CHART Troubleshooting Chart Before calling for service, determine the symptoms and follow suggested solutions. Adiust Antenna Location and Connection Snowy Video Noisy Audio Adjust Antenna Location and Connection Check Antenna Lead-in Wire Noisy Audio Multiple Image Move TV from Electrical Appliances, Lights, Vehicles, and Medical Equipment Noisy Audio Interference...
