3. Remove the burned-out bulb.
4. Replace bulb, using a tissue or wearing clean cotton gloves
to handle the bulb. Do not touch bulb with bare fingers.
5. Replace bulb cover and mounting screw.
6. Plug in microwave oven or reconnect power.
5. Lift up the bulb cover.
The microwave oven light is a 10W low-voltage
halogen capsule
bulb. It will automatically come on when the door is opened and
when the oven is operating. See "Assistance
or Service" section
to reorder.
To Replace:
1. Unplug microwave oven or disconnect
power.
2. Pull the vent grille out.
6.
A. Bulb cover
Remove the burned-out bulb by squeezing the wire clip
together, pulling to the right and lifting.
7. Replace bulb, using tissue or wearing clean cotton gloves to
handle bulb. Do not touch bulb with bare fingers.
8. Close bulb cover.
9. Replace charcoal odor filter.
10. Slide the top of the vent grille into place. Push the bottom
until it snaps into place.
3. Open the door.
11. Plug in microwave oven or reconnect power.
4. Remove charcoal odor filter. (See "Replacing Filters" section.)
TROUBLESHOOTING
Try the solutions suggested here first in order to avoid the cost of an unnecessary service call.
Nothing will operate
Has a household fuse blown, or has the circuit breaker
tripped?
Replace the fuse or reset the circuit breaker. If the problem
continues, call an electrician.
•
Is the appliance wired properly?
See Installation Instructions.
Oven will not operate
•
Is the door completely closed?
Firmly close door.
Is a spacer (on some models) attached to the inside of the
door?
Remove spacer, then firmly close door.
Is the electronic
oven control set correctly?
See "Microwave
Oven Control" section.
On some models, is the Control
Lock set?
See "Control Lock" section.
On some models, is the Demo Mode activated?
See "Demo Mode" section.
msthe magnetron working properly?
Try to heat 1 cup (250 mL) of cold water for 2 minutes at
100% cooking power. If water does not heat, call for service.
See "Assistance
or Service" section.
Oven makes humming
noise
•
This is normal and occurs when the power supply switches
the magnetron on and off.
Oven door looks wavy
•
This is normal and will not affect performance.
Turntable will not operate
•
Has the tape been removed from turntable hub?
See "Turntable" section.
•
is the turntable
properly in place?
Make sure turntable is correct side up and is sitting securely
on the turntable support.
Is the turntable support operating properly?
Remove turntable.
Remove and clean turntable support and
rollers. Replace turntable support. Replace turntable. Place
1 cup (250 mL) of water on the turntable, then restart
microwave oven. If it still is not working, call for service. See
"Assistance
or Service" section. Do not operate the
microwave oven without turntable and turntable support
working properly.
Turntable alternates rotation directions
•
This is normal and depends on motor rotation at the
beginning of the cycle.
Display shows messages
Is the display showing an "Oven Status" screen, with a
letter/number
code and instruction to inform KitchenAid?
The oven has detected an internal problem. It has run a self-
checking program and displayed the error. Call for service.
See "Assistance
or Service" section.
17
