Extron electronics Hideaway HSA 200C Series Specification Sheet

Hideaway HSA 200C Series
®
Compact, Fixed Configuration, Tilt-Up HSA - Hideaway Surface Access Enclosures with Circular Bezel

CoMMon features

Durable pneumatic movement and mechanical latching mechanism
•
• Compact size with circular bezel
• Top surface available in black anodized or brushed aluminum finishes
• HSA 200CE includes built-in Extender video and audio line driver
• One female 15-pin HD connector and 3.5 mm mini stereo audio jack
• Two CAT 6 RJ-45 network/data/phone connectors; unswitched AC outlet
• Versions available with US, Australia, UK, Central Europe, Switzerland, France,
Israel, or India power outlets
• Available Universal AC power receptacle accepts US, UK, Israel, Central
Europe, France, Australia, India, Swiss, Italy, and Denmark AC plug types
• UL/CUL listed and CE compliant
• Installation router guide available upon request
• Brushed brass and polished aluminum finishes available by special order,
requires 11-14 week lead time
desCriPtion
The Extron Hideaway HSA 200C and HSA 200CE provide compact, tilt-up, architectural
solutions for inconspicuous computer-video interface connector access. The HSA 200CE
provides a built-in Extron Extender line driver, which allows computer video signals to be output
on five BNC pigtails and driven over long cable runs without degradation of the signal. The
Extender also converts unbalanced audio to a balanced signal.
The HSA 200C/200CE circular bezel enclosures are designed for easy mounting into virtually
any table surface and are ergonomically designed, keeping installation time and effort at a
minimum. Once installed, the HSA 200C and HSA 200CE products fit flush with the tabletop,
storing connectors out of sight.
Both models offer one female 15-pin HD connector, one unswitched AC outlet, two
bezel-mounted CAT 6 RJ-45 network/data/phone connectors, and audio on 3.5 mm stereo
jack connectors on its faceplate. The circular bezel allows the Hideaway to be mounted at
unique angles and to be installed in three easy steps. A standard circular hole saw can be used
to make the six-inch hole.
Europe Europe Dubai Dubai
+31.33.453.4040 / +800.3987.6673 +31.33.453.4040 / +800.3987.6673 +971.4.2991800 +971.4.2991800
+31.33.453.4050 FAX +31.33.453.4050 FAX +971.4.2991880 FAX +971.4.2991880 FAX
The HSA 200C and HSA 200CE include an RJ-45 connection kit for each front panel RJ-
45 jack. Inside the kit, there is one set of icons for labeling, one blank filler plate, and an
assortment of colored bezels. This offers the option of labeling and color-coding the RJ-45
connectors as they pertain to their assigned function, or covering the connector when it is
not needed. The Hideaway HSA 200C and HSA 200CE ship standard in a black anodized or
brushed aluminum finish.*
Versions are available with discrete US, Australia, UK, Central Europe, Switzerland, France,
Israel, or India power outlets, as well as a universal receptacle ideal for use in hotels and
conference centers.
*Polished aluminum finish and brushed brass finish are also available. These models are built to order and
require a longer lead time. Call an Extron Customer Support Representative for more information.
Extron
HSA 200CE
Hideaway Surface
Access Enclosure
with Extender
Line Driver
Asia Asia China China
+65.6383.4400 / +800.7339.8766 +65.6383.4400 / +800.7339.8766 +86.21.3760.1568 / +400.883.1568 +86.21.3760.1568 / +400.883.1568
+65.6383.4664 FAX +65.6383.4664 FAX +86.21.3760.1566 FAX +86.21.3760.1566 FAX
h i d e A w A y s u r f A c e A c c e s s e n c l o s u r e s
®
Mounted
through a table
or lectern
Japan Japan
+81.3.3511.7655 +81.3.3511.7655
+81.3.3511.7656 FAX +81.3.3511.7656 FAX
Continued
