Optoma TS551 Datasheet

Projector Expert
TS551
− Multimedia Projector
Deliver Detail to Grab Your Audience
The Optoma TS551, a 2800-lumen SVGA projector with a robust 3500:1
contrast ratio, lets presenters deliver detailed and effective presentations
that impact audiences. Compact at less than five pounds, this projector
can be easily moved to wherever it's needed. Educators and business
users alike will appreciate the connectivity flexibility offered by the HDMI
connector and 3D-capability that supports delivery of emerging content
offerings from a broad range of input sources.
Features
 Brightness at 2800 ANSI lumens and 3500:1 high contrast ratio
 3D-capable
 Built-in closed captioning
 Power saving eco-friendly at <0.5W
 Logo capture feature
Specifications
Display Technology
Single 0.55" DC3 DMD DLP
®
Technology by Texas Instruments
Resolution
Native SVGA (800 x 600)
Maximum Resolution
UXGA (1600 x 1200)
Brightness (Typical)
2800 ANSI Lumens
Contrast Ratio
3500:1 (Full On/Full Off)
Lamp Life and Type
6500/6000/5000 Hours (Dynamic
Eco/Eco/Normal)
180W P-VIP
Throw Ratio
1.97 to 2.17 (Distance/Width)
Projection Distance
3.94' to 39.4' (1.2 to 12m)
Image Size (Diagonal)
30" to 300" (0.76 to 7.62m)
Aspect Ratio
4:3 Native, 16:9 and 16:10
Compatible
Remote Control
IR Remote with Laser Pointer
Audio
2-Watt Stereo Speaker
Displayable Colors
1.07 Billion
Offset
115% ±5%
Uniformity
85%
* Lamp life is dependent upon many factors, including lamp mode, display mode, usage, environmental conditions and more. Lamp brightness may decrease over time.
**3D content can be viewed with active LCD shutter glasses when the projector is connected to a computer with a compatible 3D graphics card.
Please visit www.optoma.com for more information.
© Copyright 2011 Optoma Technology, Inc. All specifications subject to change at any time. DLP
Keystone Correction
±40° Vertical
Computer Compatibility
UXGA, WXGA, SXGA+, SXGA, XGA,
SVGA, VGA Resized, VESA, PC and
Macintosh Compatible
Video Compatibility
NTSC, PAL, SECAM, SDTV (480i), EDTV
(480p), HDTV (720p, 1080i/p)
3D Compatibility**
120Hz Frame Sequential 3D for
Resolutions Up to 720p, 60Hz Field
Sequential 3D for Resolutions Up to 480i
Horizontal Scan Rate
15.3 to 91.1 KHz
Vertical Refresh Rate
24-85Hz, 120 Hz
Loop Through
Monitor: D-Sub 15-Pin VGA Output
Audio: Stereo Mini-Jack Output
(Functional in Both Normal and Standby
Modes)
Projection Lens
F= 2.4-2.66, f= 18.2-21.8mm,
1.1x Manual Zoom and Focus
User Controls
Complete On-Screen Menu Adjustments
in 23 Languages
I/O Connectors
HDMI, Two VGA-In, VGA-Out, S-Video,
Composite Video, Audio-In, Audio-Out,
RS-232 and USB Type B
Security
Kensington Lock, Security Bar and
®
Keypad Lock
Projection Method
Front, Rear, Ceiling Mount, Table Top
Pre-Launch Datasheet – TS551
Weight
4.9 lbs (2.2kg)
Dimensions (W x H x D)
11" x 9.06" x 3.03"
(279 x 230 x 76.96 mm)
Noise Level (STD/Bright)
28dB/30dB
Operating Temperature
41 to 104°F (5 to 40°C),
80% Max Humidity
Power Supply
AC Input 100-240V, 50-60Hz,
Auto-Switching
Power Consumption
255 Watts (Normal), 230 Watts
(ECO), <0.5 Watt
(Standby-Eco)
Standard Accessories
AC Power Cord, VGA to VGA
Cable, Remote Control,
Batteries for Remote, USB
Cable, Carrying Case, Lens
Cap, CD-ROM User's Manual,
Quick Start Card and Warranty
Card
Optional Accessories
Ceiling Mount, HDMI Cable,
VGA to Component Cable,
S-Video Cable, Composite
Video Cable, RS-232 Cable
and Panoview™ Series
Screens
Warranty
3-Year Optoma Express
Replacement Service,
1-Year on Lamp
UPC
796435 81 133 4
www.optoma.com
and the DLP logo are registered trademarks of Texas Instruments.
®
