Summary of Contents for Philips PB9011
- Page 1 Philips Consumer Lifestyle A division of Philips Electronics North America Corporation P.O. Box 10313 Stamford, CT 06904 Phone: 1-888-PHILIPS (744-5477) Meet Philips at the Internet http://www.philips.com/welcome © 2011 Koninklijke Philips Electronics N.V. All rights reserved. PB9011_37_UM_V2.0...
- Page 2 PB9011 Register your product and get support at www.philips.com/welcome EN User manual ES Manual del usuario FR Mode d’emploi...
- Page 3 Canada English: This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.This Class B digital apparatus complies with Canadian ICES-003. Français: Cet appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de Classe B prescrites dans...
-
Page 4: Table Of Contents
Contents Important Important Safety Instructions Hearing safety Trademark notice Your portable Blu-ray disc player What’s in the box Overview of the main unit Overview of the second screen Overview of remote control Get started Mount the unit in your car Connect power Connect the second screen Prepare the remote control... - Page 5 Use at home Connect power from household source Connect a TV Update software Update software via USB Specifications Troubleshooting 10 Notice Disposal of your old product and batteries...
- Page 6 Register online at www.philips.com/welcome today to get the very most from your purchase. Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below,so don't miss out. Register online at www.philips.com/welcome to ensure: *Product Safety Notification *Additional Benefits By registering your product, you'll receive notification - directly...
- Page 7 ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD- UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE Philips is not liable for any damage to or loss of any programs, LAW, ANY IMPLIED WARRANTY MERCHANTABILITY OR...
-
Page 8: Important
1 Important Important Safety Instructions a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 9: Hearing Safety
m Unplug this apparatus during lightning storms or when unused for long periods of time. n Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. -
Page 10: Trademark Notice
• Sound can be deceiving. Over time your hearing ‘comfort level’ adapts to higher volumes of sound. So after prolonged listening, what sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there. - Page 11 Manufactured under license from Dolby Laboratories. ‘Dolby’ and the double D symbol are trademarks of Dolby Laboratories. Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks, & DTS 2.0+ Digital Out and the DTS logos are trademarks of DTS, Inc.
-
Page 12: Your Portable Blu-Ray Disc Player
2 Your portable Blu-ray disc player Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips. com/welcome. What’s in the box Check and identify the contents of your package: •... -
Page 13: Overview Of The Main Unit
Overview of the main unit a DISC/POP-UP • Blu-ray disc: Access or exit the pop-up menu. • DVD: Access or exit the disc menu. • Pause play. -
Page 14: Audio Out
• Start or resume play. d OPEN • Open the disc cover. • Skip to the previous or next title, chapter, or track. f OPTIONS • Access options for the current activity or selection. g HOME • Access or exit the home menu. •... -
Page 15: Overview Of The Second Screen
q OFF•POWER•ON • Power on/off this player. r Power indicator Overview of the second screen a b c d a 12V DC IN • Power supply socket. b AUDIO IN • Audio input jack. c VIDEO IN • Video input jack. •... -
Page 16: Overview Of Remote Control
Overview of remote control a Color buttons • Blu-ray disc: Select tasks or options. • Access the home menu. c TOP MENU • Blu-ray disc: Display the top menu. • DVD: Display the title menu. - Page 17 d OK • Confirm an entry or selection. • Navigate the menus. OPTIONS • Access options for the current activity or selection. • Pause play. • Skip to the previous or next title, chapter, or track. • Search backward or forward. j AUDIO •...
-
Page 18: Get Started
3 Get started Mount the unit in your car To use the player in your car, attach the main unit and the second screen to the back of the front seat headrests. Pull the strap through the loops on the back of the main unit. Hold the buckle with the marked arrow facing you, then attach the buckle to the strap. -
Page 19: Connect The Second Screen
Connect the car adaptor to the DC IN jack on the main unit and the second screen first, then connect it to the car cigarette lighter socket. Connect the second screen Caution • Turn off your player before you connect the second screen. VIDEO IN AUDIO IN VIDEO OUT... -
Page 20: Prepare The Remote Control
Prepare the remote control Press and push the battery compartment to slide it open (see “1” in the illustration). Insert two AAA batteries with correct polarity (+/-) as indicated. Push and slide back the battery compartment (see “3” in the illustration). -
Page 21: Use Your Portable Blu-Ray Disc Player
4 Use your portable Blu-ray disc player Turn on To turn on this player, slide the OFF•POWER•ON switch to the ON position. » The power indicator turns on (green). Select OSD language You can choose a different language for the on-screen display text. Press »... -
Page 22: Play A Disc
Setup Language OSD Language English Subtitle anguage English Standard DivX Subtitles » [OSD language]: Select menu display language. » [Subtitle language]: Select video subtitle language. » [DivX subtitles]: Select DivX video subtitle language. Press to select an option and then press OK. •... -
Page 23: Play Media Files Via Usb
Close the disc cover. » The player starts playing automatically. Play media files via USB To play picture, music, and video files from a USB storage device, Connect the USB storage device to the (USB) jack. Press , and select USB. »... -
Page 24: Basic Play Control
Press to select a media file and press OK to play. Basic play control Follow the instructions to control your player. Button Action Start or resume play. Pause play. Press repeatedly to step forward frame by frame. Stop play. Skip to the previous or next track, chapter or file. -
Page 25: Video, Audio And Picture Options
Video, audio and picture options You can specify options for video or picture play from a disc or a USB storage device. Video options Access more options during video play. • [Audio]: Select an audio language. • [Subtitle]: Select a subtitle language. •... - Page 26 Press » The options menu is displayed. Press to select , and press OK. » A new window is displayed. Press to highlight a field: • [Time] • [Title] • [Chapter] • [Angle] To skip to a specific time, press repeatedly until preferred time is displayed, and then press OK.
- Page 27 Audio options • [REPEAT]: Repeat one, repeat folder or turn repeat off. • [REPEAT A-B]: Repeat a certain section of a track. • [SHUFFLE]: Plays audio tracks in a random order, or to cancel random play. Picture options Access more options during a slideshow. •...
-
Page 28: Change Settings
5 Change settings You can change the settings of this player in the setup menu. Note • You cannot change a menu option that is grayed out. • To return to the previous menu, press • To exit the menu, press General Setup General... -
Page 29: Audio
Audio Setup Audio Down Sampling HDMI Output Dynamic Range [Down Sampling]: Selects the output sampling rate for better sound quality. • [On] - for discs recorded at sampling rate of 48 kHz. • [Off] - for discs recorded at sampling rate of 96 kHz. [HDMI Output]: Select HDMI audio format. -
Page 30: Picture
[Subtitle Setup]: Set font size, font color. [Aspect Ratio]: select display aspect ratio. Note • If the player is connected to TV via HDMI cable, [LCD Settings] and [LCD Backlight] cannot be changed. Picture Setup Picture Transition Mode Random Slide Interval Time 5 Seconds [Transition mode]: Set the transition mode between two slides. -
Page 31: Set The Second Screen
Note • Rated DVDs above the level you set in [Parental control] require a password to be played. • The ratings are country-dependent. To allow all discs to play, select ‘8’. • Some discs have ratings printed on them but are not recorded with ratings. This function has no effect on such discs. -
Page 32: Use At Home
6 Use at home Connect power from household source Caution • Risk of product damage! Ensure that the power supply voltage corresponds to the voltage pointed on the back or the underside of the player. • Risk of electric shock! When you unplug the AC adaptor, always pull the plug from the socket. - Page 33 Use an HDMI cable Connect the HDMI cable (not supplied) to the HDMI jack of this player and the HDMI jack of your TV. Turn on the player and your TV. Find the HDMI input source on your TV (For details, refer to the user manual of your TV).
-
Page 34: Update Software
Select [General] > [Version], and press OK. » The software version information is displayed . Update software via USB Check the latest software version on www.philips.com/support. • Search for your model and click on “Software and drivers”. Download the software into a USB storage device. -
Page 35: Specifications
8 Specifications Note • Specifications are subject to change without notice Region code This player can play discs with the following region codes. Country USA, Canada Playable media • BD-Video • DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer) • VCD/SVCD •... - Page 36 • Constant bit rate: • MP3: 112 kbps - 320 kpbs • WMA: 64 kpbs - 160 kpbs • Compatibility: Hi-Speed USB (2.0) • Class support: USB Mass Storage Class (UMS) • File system: FAT16, FAT32 Laser Specification • Laser Type (Diode): AlGaInN (BD), AlGaInP (DVD/CD) •...
-
Page 37: Troubleshooting
If you still have a problem, register your player and get support at www.philips.com/welcome. If you contact Philips, you will be asked for the model and serial number of this player. The model number and serial number are on the back of this player. - Page 38 • Make sure that the HDMI cable is not faulty. If it is faulty, replace with a new HDMI cable. • If this player is connected to an unauthorized display device with an HDMI cable, the audio and video signals may not be output. Distorted picture •...
- Page 39 Play Cannot play a disc. • Clean the disc. • Make sure that the disc is correctly loaded. • Make sure that this player supports the disc. See “Product specifications”. • Make sure that this player supports the region code of the DVD or •...
-
Page 40: Notice
This offer is valid up to three years after product purchase to anyone in receipt of this information. To obtain source code, please contact open. source@philips.com. If you prefer not to use email or if you do not receive confirmation receipt within a week after mailing to this email address, please write to “Open Source Team, Philips Intellectual Property &... - Page 41 Environmental information All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specialized company.
