- Page 3 NOTE: The screws and nuts required to attach a part are listed immediately following that part. Membrane, Switch 3181783 Black 3181784 White 3181785 Almond 3181889 Bracket, Mounting Membrane Switch 3181705 Microcomputer 3179117 Screw (2) 3183705 Retainer, Bracket 3182939 Screw 3182985 Clip, (3) Retainer 3182162 Hinge, Vent Door...
-
Page 4: Accessory Parts
242831 242832 Yellow 12 Ga. 150~c Rating 242828 Black 242829 PAINT,TOUCH UP (1/2 oz.) 72017 White 72107 Almond 72110 Harvest Gold 72112 Toast 72113 Platinum 72032 Black 261869 Citrine White PAINT PRESSURIZED SPRAY (13 oz.) 350930 White 350956 Almond 261890 Harvest Gold 285365 Toast... - Page 6 NOTE: The screws and nuts required to attach a part are listed immediately following that part. 3177545 Bracket, Conduit 3177739 Cabinet, Back 300890 Screw (14) 3178138 Cabinet, Top 300890 Screw (5) 3183748 Top, Module 300890 Screw (8) Side, Cabinet 3177440 Right Hand 3177438 Left Hand...
- Page 7 4168874 Screw 3183752 Bracket, Control 3177991 Screw 4173179 Retainer, Insulation 300890 Screw (2) FOLLOWING PARTS NOT ILLUSTRATED INSULATION 3177862 Insulation, Wrap 3177872 Insulation, Back...
- Page 9 NOTE: The screws and nuts required to attach a part are listed immediately following that part. 3178512 Mounting Plate 4173193 Screw (3) 4173194 Lockwasher (3) 4173237 Nut(Left Hand) 4173236 3182088 Motor 4173238 E-Ring 4173185 Bracket Guard 4173230 Flatwasher 3179790 Gasket, Foam...
- Page 11 NOTE: The screws and nuts required to attach a part are listed immediately following that part. 3183748 Top, Module 300890 Screw (8) 3181699 Tube, Vent 3179117 Screw (3) 3177471 Liner, Oven 3177572 Side, Module (R.H. & L.H.) 300890 Screw (4) 311255 Bulb, Oven Light 3150505...
- Page 12 3177872 Insulation, Back...
- Page 14 NOTE: The screws and nuts required to attach a part are listed immediately following that part. 3177599 Liner, Door 3178001 Screw, Black (2) 3178584 Gasket, Window 3179693 Spacer, Window 3177831 Latch, Strike 300890 Screw (2) 3177718 Insulation Retainer 300890 Screw (4) 4163855 Bracket, Glass Mounting 300890...
- Page 16 NOTE: The screws and nuts required to attach a part are listed immediately following that part. Liner, Oven 3177471 Self Clean 3177472 Convection 661415 Element, Broil 3147563 Grill, Broiler 3147845 Pan, Broiler 3180865 Rack, Offset 3180864 Rack, Oven 661416 Element, Bake 3179117 Screw (2) 4167277...
- Page 18 NOTE: The screws and nuts required to attach a part are listed immediately following that part. 3183748 Module, Top 258076 Block, Terminal 308043 Screw 3183784 Switch, Latch 98106 Screw 3178185 Insulator, Switch 3177662 Guard, Latch 3177991 Screw Handle, Latch 3177969 Upper Oven 3181963 Lower Over...
- Page 20 3183655 Harness Wire (Door Switch Upper Light) 3183656 Harness Wire (Door Switch Lower Light) 3183359 Harness Wire (Lower Oven) 3184221 Harness Wire (Upper Oven) 3179668 Standoff, Wire 300890 Screw (4) 4159037 Clamp, Wire 3183976 Harness, Wire Latch Assy. Upper Oven 3183361 Harness, Wire Latch Assy.
