idaire.com ...3-5 Controls ..7 Controls ....8 Warming Drawer Controls ..9-10 Control Pad Features ....Setting Oven Controls .... 12-23 Self Cleaning ......24-26 Adjusting Oven Temperature ..27 Care & Cleaning ..... 28-30 Before Call Solutions to Common Problems ...... - Page 2 ¸¸¸¸¸¸7¸¸:¸ ¸ : L: Welcome&Congratulations Congratulations on your purchase of a new range! At Electrolux Home Products, we are very proud of our product and are completely committed to providing you with the best service possible, Your satisfaction is our number one priority. We know you'll enjoy your new range and Thank You for choosing our product.
- Page 3 l, porta.t Sa ety lnstructions Read all instructions before using this appliance: Save these instructions for future reference, This manual contains important safety symbo!s and instruct!ons. P!ease pay attention to these symbols and fo!!ow aHinstructions g!ven_ This symbol will help alert you to situations that may cause serious bodily harm, death or property damage. This symbol will help alert you to situations that may cause bodily injury or property damage.
- Page 4 • Glazed Cooking Utensils--Only certain types of glass, glass/ Do Not Leave Children Alone--Children should not be left ceramic, ceramic, earthenware, or other glazed utensils are alone or unattended in the area where appliance is in use. suitable for cooktop service without breaking due to the They should never be allowed to sit or stand on any part of the sudden change in temperature.
- Page 5 Grounding instructions Grounding type wall receptacle Avoid fire hazard or electrical shock. Do not use an adapter plug, an extension cord, or remove grounding prong from electrical power cord. Failure to follow this warning can cause serious injury, fire or death. This appliance is equipped with a 3-prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle.
- Page 6 Features Glance ......7y_oo77777777:_ ....Your Gas Range Features include: Electronic Oven Control with Kitchen Timer. Warming Drawer Control & Indicator Light (some models). Left Front Burner Valve & Knob. Left Rear Burner Valve & Knob. Center Burner Valve & Knob (some models). Right Rear Burner Valve &...
- Page 7 Oven Vent Location OVEN VENT The oven vent is located below the backguard (See Fig. 1). When the oven is on, warm air is released through this vent. This venting is necessary for proper air circulation in the oven and good baking results. DO NOT BLOCK THE VENT. Removing &...
- Page 8 Setting Surface Controls Do not place plastic Your range may be equipped with different sized surface burners. The ability to heat items such as salt and pepper food quicker and in larger volumes increases as the burner size increases. The shakers, spoon holders or plastic Simmer burner (some models) is best used for simmering...
-
Page 9: Controls
Arranging Warming Drawer Rack Positions The rack can be used in 2 ways: Always use pot holders or • In the upright position to allow low profile food items to be placed both oven mitts when removing food from the under and on top of the rack (for example, rolls or biscuits on top of the rack Warming Drawer as cookware and plates and a casserole dish underneath). - Page 10 Removing&Replacing the Warming Drawer Pull up with finger Electrical Shock Hazard can occur and result in serious injury or death. Disconnect appliance from electric power before cleaning and servicing the Warming Drawer. Left Glide To Remove and Replace the Warming Drawer (some models) To Remove the Warming Drawer:...
- Page 11 READ THE iNSTRUCTiONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various features and functions of the oven as described below. Detailed instructions for each feature and function follow later in this Use & Care Manual. OVEN LIGHT--Use TIMERON/...
-
Page 12: Controls
• Even-Cook. • Convection Oven Speed Oven Timer clean light on/off Clean Bake Start Broil Bake Keep time time warm Clear Max× Clock Speed Favorite clean Lock bake setting /off Controls Setting the Clock The CLOCK @ pad is used to set the clock. The clock may be set for 12 or 24 hour time of day operation. - Page 13 Setting Continuous Bake or 12 Hour Energy Saving The TIMER ON/OFF _ and CLEAN ___ pads control the Continuous Bake or 12 Hour Energy Saving features. The oven control has a factory preset built-in 12 Hour Energy Saving feature that will shut off the oven if the oven control is left on for more than 11 hours and 59 minutes, The oven can be programmed to override this feature for Continuous Baking, INSTRUCTIONS PRESS...
- Page 14 Setting Oven Lockout Feature The _ pad controls the Oven Lockout feature. The Oven Lockout feature automatically locks the oven door, prevents the Warmer Drawer and most oven controls from being turned ON. It does not disable the clock, Kitchen Timer or the interior oven light.
-
Page 15: Setting Oven Controls
Setting Oven Controls Even-Cook- • Convection Oven Speed Oven Timer clean ight on/of! Clean Bake Start Broil Bake Keep time time warm Clear Maxx Clock Speed Favorite clean Lock bake setting Controls Setting Silent Control Operation The START TIME @ and CLEAN _ pads control the Silent Control operation feature. - Page 16 Setti.g Oven Controls Even-Cook- Convection Oven Speed Oven Timer clean light on/off Clean Bake Start Broil Bake Keep time time warm Maxx Clock Speed Favorite Clear clean Lock bake setting Controls Setting Bake The BAKE q pad controls normal baking. The oven can be programmed to bake at any temperature from 170°F to 550°F (The sample shown below is for 350°F).
- Page 17 Setting Timed Bake pads control the Timed Bake feature. The automatic timer of the Timed Bake feature The BAKE O and BAKE TIME _ will turn the oven OFF after cooking for the desired amount of time you selected. iNSTRUCTiONS PRESS DISPLAY To program the oven to begin...
- Page 18 Sett Setting Delayed Start The BAKE , BAKE TiME _ and START TiME _ pads control the Delayed Start. The automatic timer of the Delayed Start will turn the oven ON and OFF at the time you select in advance. INSTRUCTIONS PRESS DISPLAY...
- Page 19 Setting Broil The 10 pad controls the Broil feature. When broiling, heat radiates downward from the oven broiler for even coverage. The Broil feature is preset to start broiling at 550°F however, the Broil feature temperature may be set at any temperature between 400°F and 550°F.
- Page 20 Benefits of Speed Bake Cooking System: --Some foods may cook up to 25 to 30% faster, saving time and energy. --Multiple rack baking. --No special pans or bakeware needed. Setting SpeedBake The Speed Bake pad controls the convection baking features. Use SpeedBake when cooking speed is desired.
- Page 21 Using the Favorite Settings Feature FAVORITE SETTING pad is used to record and recall your favorite recipe settings, This feature may store and recall from 1 to 3 different settings. The Favorite Setting feature may be used with Bake or a Timed Bake, This feature will not work with any other function including a Delay Start (Delayed Timed Bake) setting..
- Page 22 To Set the Sabbath Feature (for use on the Jewish Sabbath & Holidays) The _ BAKE TiME and _ START TiME pads are used to set the Sabbath feature. The Sabbath feature may only be used with the pad. The oven temperature may be set higher or lower after setting the Sabbath feature (the oven temperature adjustment feature should be used only during Jewish Holidays), however the display will not visibly show and no audible tones will be provided when a change occurs.
- Page 23 Setting the Sabbath Feature (cont'd) It is recommended that any oven temperature change with the Sabbath feature activated be followed with 2 presses of the START pad. This will insure the oven remains ON even if the attempt to set the oven temperature was lower or higher than the oven control can accept.
-
Page 24: Self Cleaning
During theSelf-Cleaning Self-Cleaning Oven cycle, t heoutside oftherange can A Self-Cleaning oven cleans itself with high temperatures (well above cooking become veryhottothetouch.DONOT temperatures) which eliminate soils completely or reduces them to a fine leave small c hildren unattended n ear t he powdered ash you can wipe away with a damp cloth. - Page 25 Self..Cleanin The SPEED CLEAN _, CLEAN _ and MAXX CLEAN _,_), pads are used to start a Self-Cleaning cycle. When used with START TIME _ pad, a delayed Self-Cleaning cycle may also be programmed. This feature allows for any Self- Cleaning cycle times from 2 hours (using Speed Clean), 3 hours (using Clean) to 4 hours (using Maxx Clean).
- Page 26 iNSTRUCTiONS PRESS DISPLAY When the Self-Clean cycle is done: The time of day,"Hot, DOOR LOCKED" and "CLEAN" icon will remain in the display (See Fig. 7). Once the oven has cooled down for approximately 1 HOUR, and the "DOOR LOCKED" icon is no longer displayed, the oven Fig.7 door can then be opened.
- Page 27 Thetemperature i ntheovenhasbeenpre-set a tthefactory. W hen firstusing theoven,be Note: The oven temperature suretofollowrecipe timesandtemperatures. Ifyouthinktheovenistoohotor toocool,the adjustments made with this temperature i ntheovencanbeadjusted. Before adjusting, testa recipe byusinga feature will not change the temperature s etting thatis higher o r lower t hantherecommended temperature. Thebaking Self-Clean cycle results should helpyoutodecidehowmuchofanadjustment is needed.
- Page 28 Surfaces How to Clean Glass, Painted For general cleaning, use a soft cloth, clean with mild dish detergent & water or a 50/50 solution Plastic Body Parts & of vinegar & water. Follow by rinsing the area with clean water; dry & polish with a soft cloth. Control Knobs Glass cleaners may be used if sprayed...
- Page 29 Cleaning the Cooktop The cooktop is designed to make cleaning easier. Since the four burners are sealed, cleanups are easy when spillovers are cleaned up immediately. To clean, wipe with a dean, damp cloth and wipe dry. DO NOT attempt to clean the cooktop when the cooktop or burner heads are still hot.
- Page 30 Removing and Replacing the Lift-Off Oven Door The door is heavy. For safe, temporary storage, lay the door flat with the inside of the door facing down. Door Hinge To Remove Oven Door: locations with oven door Open oven door completely (horizontal with floor- See Fig. 1). fully open Pull the door hinge locks on both left and right door hinges down from the...
-
Page 31: Care & Cleaning
