Eureka 4500 Series Owner's Manual

Household type
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Upright Vacuum Cleaner

Household Type
Owner's Guide
4500 Series
Index
Important Safeguards ........... 2
Service Information ............... 4
Assembly ........................... 5-6
Use ........................................ 7
Thermal Cut Off .............. 4 & 7
Accessories ........................... 8
Cyclonic Cassette ................. 9
Brush Roll ........................... 10
Brush Roll Belt ............... 10-11
Hose Blockage ............... 12-13
Filters .................................. 14
HEPA Filter .......................... 14
Light Bulb ............................ 15
Problem Solving .................. 16
Customer Order Form ......... 17
Warranty .............................. 19
IMPORTANT
Do not return this
product to the store.
For assembly problems or
questions contact: Eureka's
Customer Service Division toll
free at 1-800-282-2886*, 7 a.m.
to 8 p.m., Central Standard
Time, Monday through
Saturday.
For replacement of broken
or missing items to be
shipped direct to you, call
1-800-438-7352*, 8 a.m. to
4:45 p.m., Central Standard
Time, Monday through Friday.
*En Mexico llame al 5670-6169
www.eureka.com

Advertisement

Table of Contents
loading

Related Manuals for Eureka 4500 Series

Summary of Contents for Eureka 4500 Series

  • Page 1: Table Of Contents

    Upright Vacuum Cleaner Household Type Owner’s Guide 4500 Series Index Important Safeguards ... 2 Service Information ... 4 Assembly ... 5-6 Use ... 7 Thermal Cut Off ... 4 & 7 Accessories ... 8 Cyclonic Cassette ... 9 Brush Roll ... 10 Brush Roll Belt ...

  • Page 2: Important Safeguards

    • Do not use outdoors or on wet surfaces. • Do not leave vacuum cleaner when plugged in. Turn off the switch and unplug the electrical cord when not in use and before servicing. • Do not allow to be used as a toy. Close attention is necessary when used by or near children.
  • Page 3 CONSEILS DE SÉCURITÉ Lors de l’utilisation d’un appareil électrique, quelques précautions élémentaires doivent être observées, incluant les suivantes: LISEZ TOUTES LES INSTRUCTIONS AVANT D’UTILISER VOTRE ASPIRATEUR. AVERTISSEMENT Pour réduire le risque de feu, de choc électrique, ou de blessure: • Ne pas utiliser à...

  • Page 4: Service Information

    If you prefer, you can write to The Eureka Company, Service Division, 807 North Main Street, Bloomington, Illinois 61701, USA. In Canada write to The Eureka Company, 866 Langs Drive, Cambridge, Ontario N3H 2N7. Refer to The Eureka Limited Warranty for complete service information.

  • Page 5: Assembly

    HOW TO ASSEMBLE CAUTION: Moving parts, make sure on/off switch is in off position before plugging in. CAUTION: Assemble the cleaner before using. NOTE: Features may vary by model yet all parts assemble the same. Step A Attach Handle CAUTION: Do not catch cord under handle. Groove Electrical Cord...

  • Page 6: Use

    Step C Check Cyclonic Cassette Make sure that the cyclonic cassette is fully seated in the vacuum. Place thumbs on cyclonic cassette (marked by arrows above) and push firmly. NOTE: Do not lift cleaner by cassette handle, use carrying handle on the back of cleaner. See illustration in Step D.

  • Page 7: Motor Filter

    Check the HEPA filter frequently. Replace twice a year or as needed. Latch Obtain replacement filters from a local dealer or order them from The Eureka Company, Bloomington, IL. Filter Retainer 2 and To remove HEPA Filter 1. Push down latch and pull HEPA filter back.
  • Page 8 How To Use Accessories NOTE: Do not place cleaner on furniture or steps as the brush roll may cause damage. Place cleaner on floor with the handle in storage position while using accessories. 1. Remove hose from rear of cleaner. 2.

  • Page 9: Cyclonic Cassette

    NOTE: Turn off the switch and unplug the electrical cord before changing the Cassette Micron Filter. Never operate the vacuum cleaner without the cyclonic cassette or the filter. Remove cyclonic cassette by pushing up lever (1), unhooking (2) by swinging outward from vacuum body.

  • Page 10: Brush Roll

    HOW TO MAINTAIN (continued) Brush Roll The brush roll turns as it sweeps and combs the carpet nap. Remove hair and threads from the brush roll so it continues brushing the carpet. To maintain the most efficient cleaning, the bristles must touch the carpet. To test the bristle length, hold a ruler against the underneath side of the cleaner.

  • Page 11: Brush Roll Belt

    Left side view 6. Place belt around brush roll. 7. Align left end cap with square in base. Push end cap into place; see left side view. Use GENUINE EUREKA replacement belt, 54312. Look for the product symbol. (continued) 8. Pull right side of brush roll to stretch belt. Secure right end cap into base.

  • Page 12: Hose Blockage

    How to Check and Clear Hose Blockages Low suction or poor pickup may be due to a blockage in the vacuum cleaner. 1. Remove hose and check suction at end of hose - if little or no suction, check cyclonic cassette. Empty if needed. If no improvement proceed to Step 2.
  • Page 13 How to Check and Clear Blockages in Base 1. Remove the attachment hose from the lower hose retainer and look into the hose retainer for any obstructions. Proceed to Step 2 to check for any other blockages. Upright Position Operating Position Handle Release 3.

  • Page 14: Filters

    Check the HEPA filter frequently. Replace twice a year or as needed. Latch Obtain replacement filters from a local dealer or order them from The Eureka Company, Bloomington, IL. Filter Retainer 2 and To remove HEPA Filter 1. Push down latch and pull HEPA filter back.
  • Page 15 How To Change Light Bulb NOTE: Turn off the power switch and disconnect the electrical cord before changing light bulb. 1. Remove two screws from lens cover. 2. Pull lens cover from cleaner. 3. Support socket with one hand and push light bulb into socket;...

  • Page 16: Light Bulb

    PROBLEM SOLVING NOTE: Turn off the switch and unplug the electrical cord before servicing. PROBLEM Motor will not start. Motor suddenly stops. Does not clean the carpet or floor. No suction at the end of the hose. Headlight not working. Noise from the brush roll area.

  • Page 17: Order Form

    Method of payment (no C.O.D. orders) Check or money order (payable to The Eureka Company). Do not send currency. Charge to my Visa (13/15 digits) Acct. number Signature (full name as shown on acct.)

  • Page 19: Warranty

    This Warranty Covers Your Eureka cleaner is warranted to be free from all defects in material and workmanship in normal household use for a period of two years. The warranty is granted only to the original purchaser and members of his or her immediate household. The warranty is subject to the following provisions.
  • Page 20 1 dusting brush 1 cleaner connected to handle by cord 1 hose adapter w/hose 1 upholstery brush Thank you for selecting a Eureka cleaner. Don’t Forget to Use Genuine Eureka Filters and Belts ©1999 White Consolidated Industries, Inc. Printed in U.S.A.
