Page 1 user’s guide version 2.3 Web Tools www.hp.com...
Page 2: Safety Notices
Safety notices fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or Any servicing, adjustment, maintenance, or repair must be consequential damages in connection with the furnishing, performed only by authorized service-trained personnel.
Page 3: Table Of Contents
CONTENTS Revision History ..........7 Preface .
Page 4 Using Web Tools ....... . 25 Fabric View ..........25 Fabric Events View .
Page 5 Glossary ........97 Index .
Page 6 Web Tools User’s Guide...
Page 7: Revision History
Revision History July 2001 First release.
Page 8 Web Tools User’s Guide...
Page 9: Preface
PREFACE Web Tools is supported for switches on Fabric OS a2.4.1 or later. About This Guide This guide provides the following information: Chapter 1 Overview of Web Tools and a summary of the Introducing Web Tools information available through Web Tools. Chapter 2 System requirements and instructions for Installing Web Tools...
Page 10: Related Publications
Related Publications Related product information can be found in the following publications. Those publications with part numbers are provided as printed copies with your product. The HP Surestore FC Switch 6164 Documentation CD contains all publications listed in the table below and is also provided with your product.
Page 11: Getting Software Updates
Getting Software Updates Firmware and software updates are found on the HP web site located at: http://www.hp.com New switch firmware can be installed from the following host operating systems: • UNIX • Windows NT • Windows 2000 • Windows 98 •...
Page 12 Web Tools User’s Guide...
Page 13: Introducing Web Tools
INTRODUCING WEB TOOLS Web Tools runs on Fabric OS and provides a graphical interface that allows the administrator to monitor and manage entire fabrics and individual switches and ports from a standard workstation. Web Tools provides the following information and capabilities: •...
Page 14: Views Available In Web Tools
• Monitoring of and the ability to manage individual switches: – Summary information about each switch – Access to event logs for individual switches – Switch configuration and administration – Ability to upgrade Fabric OS and license key administration – Report capability for switch configuration information •...
Page 15: Information Accessible From Fabric View
Switch status is calculated approximately once per second; however Note the initial calculation does not occur until 30–60 seconds after the switch is booted. It is calculated from the state of data structures in the switch, and stored as the variable “switchStatus”. For all statuses that are based on errors per time interval, any errors will cause the status to show faulty until the entire sample interval has passed.
Page 16: Information Accessible From Switch View
Switch Events View Displays the error log for the switch. Click the Events icon on the switch panel to access, or access through Switch View (see “Switch Events View” page 16). Telnet Interface Provides an interface for using Telnet commands for switch diagnostics, troubleshooting, and fabric management.
Page 17 Administrative Provides an interface for performing functions such as upgrading firmware Interface versions or reconfiguring a switch. Click Admin in Switch View to access, or access through Fabric View (see “Initial Display Upon Launching Web Tools (Fabric View)” page 14). Performance View Graphically portrays real-time data throughput for each port and displays total switch bandwidth utilization.
Page 18 Web Tools User’s Guide...
Page 19: Installing Web Tools
INSTALLING WEB TOOLS This chapter provides requirements and instructions for installing Web Tools. Requirements The switch, the workstation and browser must meet specific requirements for correct installation and operation of Web Tools. Switch Requirements Web Tools 2.3 can manage switches that meet the following requirements: •...
Page 20: Workstation Requirements
Workstation Requirements The following items are required the correct installation and operation of Web Tools: • One of the following operating systems: – Windows 95, 98, or 2000 – Windows NT 4.0 • Adequate RAM (required for Windows operating systems only): –...
Page 21: Installing A Web Browser
Installing a Web Browser If not already installed, install one of the following browsers: • Netscape Communicator 4.51 or later (available at http://www.netscape.com • Internet Explorer 4.01 or later (available at http://www.microsoft.com Configuring the Web Browser Correct operation of Web Tools with either Netscape Communicator or Internet Explorer requires specific browser settings.
Page 22 To remove cached files from Internet Explorer: 1. Select View>Internet Options if using Internet Explorer 4.x, or from the Tools >Internet Options if using 5.x. 2. Select the General tab and click Delete Files... (under “Temporary Internet Files”). 3. Click OK, then exit and relaunch the browser. You must also specify the appropriate settings for browser refresh frequency.
Page 23: Installing The Java Plug-In On The Workstation
Installing the Java Plug-in on the Workstation A Java Plug-in must be installed on the workstation for the correct operation of Web Tools. The required version depends on the operating system. Installing the Java Plug-in on Windows 2000 or NT Windows 95, 98, 2000 and NT workstations require Java Plug-in version 1.2.2-007 or later.
Page 24: Launching Web Tools
Launching Web Tools You can launch Web Tools once the Java Plug-in is installed on the client machine. To launch Web Tools: 1. Launch a web browser. 2. Enter the switch name or IP address in the Location/Address field (for example: http://switchname/) and press Enter. Web Tools launches, displaying the Fabric View.
Page 25: Using Web Tools
USING WEB TOOLS This chapter describes the views and interfaces available through Web Tools. Switches can be accessed through different methods, such as through Note the Front Panel, Telnet, SNMP, and the web, any of which can occur simultaneously. To verify that modifications are correctly applied, ensure that the switch is modified from only one connection at a time.
Page 26 To launch Web Tools and access Fabric View: 1. Launch a web browser. 2. Enter the switch name or IP address in the Location/Address field and press Enter. For example: http://switchname/. This switch is assumed to be the local domain. For information Note specific to a QuickLoop to be available, the QuickLoop switch must be the host domain.
Page 27 Name Server Table Click to open Name Server Table View (for information about this view, “Name Server Table View” page 34). Zone Admin Click to open Zone Administration View (for information about this view, “Zone Administration View” page 36). Summary/Detail View Toggle to view either the Summary or Detail version of Fabric View.
Page 28 Telnet Click to launch the Telnet interface for the switch (for information about this view, see “Telnet Interface” page 93). polled at: or Time of the last status check, or if currently unavailable, the time of the last unreachable since: successful status check.
Page 29: Fabric Events View
Following is a picture of Fabric View with the Summary View selected: Figure 2. Summary Version of Fabric View Fabric Events View The Fabric Events View provides a running log of events for all switches in the fabric. To access Fabric Events View: 1.
Page 30 Figure 3. Fabric Events View To sort the events by a particular column, click the column header. Note To resize a column, drag the column divider. Following is a description of the columns in the Fabric Events view: Switch Name of switch Num...
Page 31: Fabric Topology View
Fabric Topology View The Fabric Topology View summarizes the physical configuration of the fabric from the perspective of the “local domain” (the domain of the switch entered as a URL in the web browser). This includes information about the “destination domains” (all other domains in the fabric) and the paths between each destination domain and the local domain.
Page 32 The window can be scrolled downwards to display information about the individual paths between the local switch and each of the other switches in the fabric. Figure 5. Fabric Topology View, Scrolled Downwards Following is a description of the fields in the Fabric Topology View: View Fabric Topology Lists the switch in the domain that is assumed to from Switch [switch...
Page 33 Active Paths: This line is followed by information about each destination domain, including information about each of the paths between that domain and the local domain. Destination The ID of the destination domain that is Domain ID: described in the lines following the ID. This information and the two lines following it display for each destination domain in the fabric.
Page 34: Name Server Table View
Name Server Table View The Name Server Table View provides the name server entries listed in the Simple Name Server database. This includes all name server entries for the fabric, not only those that are local to the local domain. Each row in the table represents a different device.
Page 35 The following fields are included in the Name Server Table View: Auto Refresh Check to enable Auto Refresh or uncheck to disable. Auto Refresh If Auto Refresh is checked, enter the number of Interval seconds for the refresh interval. Refresh Click to refresh the window immediately.
Page 36: Zone Administration View
Zone Administration View Administrative privileges are required to access this view. If a switch or device is added or removed from the network, it is necessary to save the changes and relaunch the Zone Administration view for the changes to take effect.
Page 37 Mixed Level Zoning by physical domain/port number, WWN, or Zoning AL_PA. With mixed level zoning, any object can be selected to be a member of a zone, alias, or configuration file. This mode is supported for backward compatibility with previous switches. For more information about using Zoning, see the Zoning User’s Guide.
Page 38: Alias Tab
Alias Tab You can use the Alias tab to create and manage aliases for devices in the fabric. An alias can have one or more members, including switches, ports, WWNs, and QuickLoop AL_PAs. Figure 7. Alias Tab in the Zone Administration View Following is a description of the fields on the Alias tab: Alias Name To modify an existing alias, select an alias name.
Page 39 Delete Alias Click to delete the alias selected in the Alias Name field. Deleting an alias automatically removes it from all zones. Rename Alias Click to rename the alias selected in the Alias Name field. A dialog box appears in which you can edit the alias name.
Page 40: Zone Tab
Cancel Click to cancel all changes made since changes were last applied, and to exit the Zone Administration View. Changes cannot be cancelled once they are applied. Done Click to apply all changes made since the Zone Administration View was opened and to exit the Zone Administration View.
Page 41 Following is a description of the fields on the Zone tab: Zone Name To modify an existing zone, select a zone name. Create Zone Click to create a new zone. A dialog box appears in which you can enter the name of the new zone. All names must be unique and contain no spaces.
Page 42: Quickloop Tab
Cancel Click to cancel all changes since the changes were last applied and to exit Zone Administration. Changes cannot be cancelled once they are applied. Done Click to apply all changes made since the Zone Administration View was opened and to exit the Zone Administration View.
Page 43 Following is a description of the fields on the QuickLoop tab: QuickLoop Name To modify an existing QuickLoop, select a QuickLoop name. Create Qloop Click to create a new QuickLoop. A dialog box appears in which you can enter the name of the new QuickLoop.
Page 44: Config Tab
Cancel Click to cancel all changes since the changes were last applied and to exit Zone Administration. Changes cannot be cancelled once they are applied. Done Click to apply all changes made since the Zone Administration View was opened and to exit the Zone Administration View.
Page 45 Following is a description of the fields on the Config tab: Config Name To modify an existing configuration, select a configuration name. Create Cfg Click to create a new configuration. A dialog box appears in which you can enter the name of the new configuration.
Page 46: Switch View
Cancel Click to cancel all changes since they were last applied and to exit the Zone Administration View. Changes cannot be cancelled once applied. Done Click to apply all changes made since the Zone Administration View was opened and to exit the Zone Administration View.
Page 47 3. Click the Switch icon. Figure 11. Switch View Following is a description of the items and information available in Switch View: Port icons The letters in the Port icon indicate the Gigabit Interface Converter (GBIC) type, as follows: • blank No GBIC present •...
Page 48 LED Status The color indicates the status of the port. Indicators (round light • No light No device attached next to each • Steady yellow Receiving light, but not port) online; check cable connections • Slowly flashing yellow Disabled (diagnostics or portDisable command) LED Status •...
Page 49 Telnet Click to launch a Telnet session. Fabric Watch Click to access Fabric Watch. (optional software) The background color of the button indicates the overall status of the fans: • Green Healthy • Yellow Marginal (mix of good and faulty readings) •...
Page 50 Temp Click to display temperature readings from all switch thermo sensors. The background color of the button indicates the overall temperature status: • Green Healthy • Yellow Marginal (mix of good and faulty readings) • Red Down (more than two faulty readings) •...
Page 51: Switch Events View
Switch Events View The Switch Events View displays a running log of events for the selected switch. To access Switch Events View: 1. Launch a web browser. 2. Enter the switch name or IP address in the Location/Address field and press Enter.
Page 52: Port Information View
Following is a description of the columns in Switch Events View: Switch Name of switch. Num... Event number. Time Time of event. Count Number of back-to-back occurrences of same event. Level Severity level of event: panic (switch reboots) critical error warning information debug...
Page 53 4. Click a Port icon. Figure 13. Port Information View The following tabs are available in Port Information View, and are described on the pages listed: • “PortStats Tab” page 56 • “GBIC Tab” page 58 • “Loop Tab” page 61 Using Web Tools...
Page 54 Following is a description of the fields that are visible in Port Information View regardless of which tab is selected: Port WWN Worldwide name (WWN) of this port. Port Module The GBIC type, as follows: • -- No GBIC present •...
Page 55 Port Status • TPort_Flt Port is marked faulty (defective GBIC, cable, or device). • Diag_Flt Port failed diagnostics. • Online Port is up and running. • Lock_Ref Port is locking to reference signal. Removing a cable from an E_Port Note temporarily generates errors, causing the status to show as faulty.
Page 56: Portstats Tab
PortStats Tab The PortStats tab provides information about transmission speed, reception speed, and the volume of traffic through the selected port. Figure 14. PortStats Tab in the Port Information View Following is a description of the fields on the PortStats tab: 4-Byte Word Transmitted Number of four-byte words transmitted.
Page 57 Mcast Frames Transmitted Number of multicast frames transmitted. Time R_RDY Priority Number of times R_RDY has priority over frames to be sent. Time BB_Credit Zero Number of times BB_Credit went to zero. Encd Errs Inside Frames Number of encoding errors inside frames. Frames with CRC Errs Number of frames with CRC errors.
Page 58: Gbic Tab
GBIC Tab The GBIC tab provides information about the GBIC installed in the selected port. The information displayed depends on the type of GBIC installed: • Standard GBIC Module type (short wave, long wave, etc.). • Serial ID GBIC Module type, plus extended information about capabilities, interfaces, and manufacturer.
Page 59 Following is a description of the fields on the GBIC tab: Identifier Indicates the type of serial transceiver, which can be GBIC or on-board. Connector Indicates the external connector type, which can be one of the following: • SC • BNC/TNC •...
Page 60 Encoding Indicates the serial encoding mechanism, which can be 8B10B, 4B5B, NRZ, or Manchester. Baud Rate Nominal baud rate in units of 100 Megabyte. BR Max Upper limit at which GBIC meets its specifications (in units of 1 percent above nominal baud rate). BR Min Lower limit at which GBIC meets its specifications (in units of 1 percent below nominal baud rate).
Page 61: Loop Tab
Loop Tab The Loop tab provides information about any loop on the port, including the following: • Loop statistics • Local AL_PA statistics • QuickLoop looplet statistics (if the port is a member of the QuickLoop) • QuickLoop statistics (if the port is a member of the QuickLoop) If the port is not a loop-enabled port, the following information displays: “Not an L_Port.
Page 62 NL Tenancies Displays the number of times NL_Port opens loop tenancy. Number of QL/Zone Inits Displays number of times looplet has caused Caused QuickLoop to be initialized. Number of Successful Displays number of times looplet has QL/Zones Inits successfully initialized. Number of Failed Displays number of times looplet failed to QL/Zone Inits...
Page 63 Click to open the LIP dialog box, which allows you to initialize the loop (requires password). For more information, see “LIP Dialog Box” page Bypass Click to open the Bypass dialog box, which allows you to bypass a specified looplet (requires password).
Page 64 Following is a description of the fields in the Loop Diagnostics dialog box: Start Click to start the Loop Diagnostics on the specified port. Stop Click to stop (abort) Loop Diagnostics on the specified port. Close Click to close the Loop Diagnostics function. LIP Dialog Box You can use the LIP (Loop Initialization Process) option to initialize a loop port.
Page 65 Following is a description of the fields in the Bypass dialog box: AL_PA to Bypass Specify the AL_PA number to bypass. Do not bypass the last AL_PA on the loop, as this will put it into a loopback state, requiring a reboot to return it to an L-Port state.
Page 66: Fabric Watch View (Optional Software)
Fabric Watch View (Optional Software) You can use Fabric Watch View to monitor fabric elements for potential problem conditions. For detailed information about Fabric Watch, see the Fabric Watch User’s Guide. To access Fabric Watch View: 1. Launch a web browser. 2.
Page 67 the Custom option and specify the type of notification (Syslog, SNMP_Trap, or Port log lock) for each type of event. Figure 21. Alarm Notifications Tab in the Fabric Watch View Using Web Tools...
Page 68: Configure Thresholds
Configure Thresholds You can use the Configure Thresholds tab to view and configure Fabric Watch thresholds for the Fabric Watch class currently selected in the organizational tree on the left side of the window. Figure 22. Configure Threshold Tab with the Environment Class Selected in the Fabric Watch View Web Tools User’s Guide...
Page 69 The Configure Threshold display changes according to the class and area selected in the organizational tree. However, the Configure Thresholds tab always contains the following buttons: Default Click to return settings to default values. Apply Click to apply the values specified in the current display.
Page 70 Watched checkbox Check or uncheck to specify whether you want this area watched (not available for all areas). The columns for the Power Supply and Current areas contain the following item: “Send alarms Use this text box to specify whether you want to be when”...
Page 71 The thresholds for the Port class are displayed in the following figure: Figure 24. Configure Threshold Tab with the Port Class Selected in Fabric Watch View Using Web Tools...
Page 72: Current Settings Tab
Current Settings Tab The Current Settings tab allows you to view the current Fabric Watch threshold parameters for the area selected in the Fabric Watch tree. Figure 25. Current Settings Tab in the Fabric Watch View Performance View The Performance View graphically displays throughput (megabytes per second) for each port and also for the entire switch.
Page 73 3. Click the Switch icon. The Switch View displays. 4. Click the Performance icon. Figure 26. Performance View In addition to the port graphs, a graph for the entire switch is provided at the bottom of the window. Resizing the window changes the size and shape of all the individual graphs.
Page 74: Administrative Interface
Administrative Interface The Administrative Interface provides access to the administrative functions though the following tabs: • “Switch Admin Tab” page 76 • “User Admin Tab” page 78 • “Firmware Upgrade Tab” page 80 • “Reboot Switch Tab” page 81 • “SNMP Admin Tab”...
Page 75 3. Click the Admin icon on the switch panel. Figure 27. The Enter Network Password Dialog 4. Enter your user name and password. The logon account must have administrative privileges. 5. Click OK. The Administrative Interface displays, with the Switch Admin tab selected by default.
Page 76: Switch Admin Tab
Switch Admin Tab You can use the Switch Admin tab to change IP information, enable/disable a switch, change the domain, change the switch name, see which ports are enabled, and enable/disable individual ports. Figure 28. Switch Admin Tab Web Tools User’s Guide...
Page 77 Following is a description of the fields on the Switch Admin tab: Switch Name Displays or sets the switch name. To change the name, enter new name in this field. Domain ID Displays or sets the switch domain ID. Domain IDs must be unique within a fabric.
Page 78: User Admin Tab
Port Disabled If the box is checked, the port is disabled. To enable the port, uncheck the box. Commit Click to apply changes made. Configuration Changes Reset Click to reset all fields to values present when Switch Administration was launched. User Admin Tab You can use the User Admin tab to rename accounts or change passwords.
Page 79 Following is a description of the fields on the User Admin tab: Access Level Access level required – Admin or User. Change User Name Enter new user name. Change Password Enter new password. Verify Password Re-enter password to verify. Commit User Click to apply changes made.
Page 80: Firmware Upgrade Tab
Firmware Upgrade Tab You can use the Firmware Upgrade tab to download firmware upgrades. Figure 30. Firmware Upgrade Tab Following is a description of the fields on the Firmware Upgrade tab: Host Name or Host IP Displays or sets host name or host IP address.
Page 81: Reboot Switch Tab
Password Required for FTP Enter a password if FTP was selected as the protocol. Download Firmware Click to download firmware. Reset Click to reset all fields to values present when Firmware Upgrade was launched. Reboot Switch Tab You can use the Reboot Switch tab to reboot or fast boot the switch or to disable Power On Self Test (POST) for future reboots.
Page 82: Snmp Admin Tab
Following is a description of the fields on the Reboot Switch tab: Disable POST Check to disable POST for future reboots, or uncheck to enable POST. Commit Change Click to save settings. Reboot Switch Click to reboot the switch. Fastboot Switch Click to perform a fast reboot.
Page 83 Following is a description of the fields on the SNMP Admin tab: System Description Displays or sets system description. Default is Fibre Channel Switch. System Location Displays or sets location of switch. Default is End User Premise. System Contact Displays or sets contact information for switch. Default is Field Support.
Page 84: License Admin Tab
License Admin Tab You can use the License Admin tab to view a list of installed license keys and features or to add or remove licenses. Figure 33. License Admin Tab Following is a description of the fields on the License Admin tab: License Key Enter license key to be added or removed.
Page 85: Remote Switch Tab (Optional Software)
Remote Switch Tab (Optional Software) You can use the Remote Switch feature to configure a pair of switches to operate over an extended WAN interface so that they can communicate across an ATM network by using a compatible Fibre Channel to ATM gateway.
Page 86: Quickloop Admin Tab (Optional Software)
Following is a description of the fields on the Remote Switch tab: Remote Switch Enabled Check to enable the Remote Switch feature, or uncheck to disable it. Commit Remote Click to apply changes made. Switch Change Reset Click to reset all fields to values present when Remote Switch was launched.
Page 87 You can use the QuickLoop Admin tab to modify a QuickLoop or set up a partner switch. Figure 35. QuickLoop Admin Tab Following is a description of the fields on the QuickLoop Admin tab: Enable Switch for Check to enable the switch for QuickLoop, or QuickLoop Mode uncheck to disable the switch for QuickLoop.
Page 88 QuickLoop Ports If checked, indicates a port is currently bypassed. Bypassed Current QuickLoop Displays the current partner switch WWN, domain Partner ID, and switch name of a dual-switch QuickLoop. Select a QuickLoop Select a switch from the list of switch names Partner for this currently in the fabric as the partner switch of a Switch...
Page 89: Config Admin Tab
Config Admin Tab You can use the Config Admin tab to upload the switch configuration file for archiving, or to download a new configuration file from the host. Figure 36. Config Admin Tab Using Web Tools...
Page 90 Following is a description of the fields on the Config Admin tab: Host Name or Host Specify the host name or host IP address. Remote User Specify the remote user name. Name Configuration File Specify the name of the configuration file to be Name uploaded or downloaded.
Page 91: Extended Fabric Tab (Optional Software)
Figure 37. Switch Information Report Extended Fabric Tab (Optional Software) The Extended Fabric feature allows you to configure ports for a long distance link of up to 100 km. For detailed information on this feature, see the Distributed Fabrics User’s Guide. Using Web Tools...
Page 92 You can use the Extended Fabric tab to specify which ports you want to be configured for distance and at what level. Figure 38. Extended Fabric Tab Following is a description of the fields on the Extended Fabric tab: Port No Port Number.
Page 93: Telnet Interface
Configure selected Select the long distance level to be supported for the port(s) to be long selected ports. There are three levels: distance level • No long distance • 50 km • 100 km Commit Click to apply configuration for Extended Fabrics. Configuration Changes Reset...
Page 94 3. Click the Telnet icon on the switch panel. If a Telnet session is already active, the following message displays: Figure 39. Telnet Session in Use Message 4. If this message displays and you want to abort the active session, click Abort Session.
Page 95 7. Click OK. Figure 41. Telnet Interface Using Web Tools...
Page 96 Web Tools User’s Guide...
Page 97 GLOSSARY 8b/10b encoding Encoding scheme that converts each 8-bit data byte into a 10-bit transmission character. Used to balance ones and zeros in high speed transports. Address identifier Value used to identify source or destination of a frame. AL_PA Arbitrated Loop Physical Address. Unique 8-bit value assigned during loop initialization to each port in an arbitrated loop.
Page 98 Asynchronous Transfer Mode. Transport for transmitting data over LANs or WANs that transmit fixed-length units of data. Provides any-to-any connectivity and allows nodes to transmit simultaneously. AW_TOV Arbitration Wait Timeout Value. The minimum time an arbitrating L_Port waits for a response before beginning loop initialization. Bandwidth The total transmission capacity of a link, cable, or system.
Page 99 Class 3 A connectionless frame switching service between two ports, without notification of delivery or non-delivery. Can also be used to provide a multicast connection between originator and recipients, with notification of delivery or non-delivery. Class 4 Connection-oriented service that provides a virtual circuit between two ports, including notification of delivery or non-delivery.
Page 100 CT_IU Common transport information unit. An information unit that conforms to the Fibre Channel Common Transport (FC_CT) protocol. Current Fill Word The fill word currently selected by the LPSM (loop port state machine). See also Fill Word. Cut-through Switching technique that allows selection of a transmission route for a frame as soon as destination address is received.
Page 101 Enabled The currently enabled zone configuration. Only one configuration can be configuration enabled at a time. See also Defined configuration, Zone configuration. End-to-end flow Governs flow of Class 1 and 2 frames between N_Ports. See also control Buffer-to-buffer flow control, EE_Credit. Error As applies to fibre channel, a missing or corrupted frame, time-out, loss of synchronization, or loss of signal.
Page 102 FC-PLDA The Fibre Channel Private Loop Direct Attach standard. Applies to operation of peripheral devices on private loops. FC-SW-2 The Fibre Channel Switch Fabric standard, second generation. Specifies tools and algorithms for interconnection and initialization of fibre channel switches. Fibre channel Protocol service that supports communication between fibre channel service transport providers.
Page 103 FS_RJT Fibre channel services reject. An indication that a request for fibre channel services could not be processed. Fibre Channel Service Protocol. The common protocol used for all fabric services, transparent to fabric type or topology. See also FS. FSPF Fabric Shortest Path First.
Page 104 Host Bus Adapter. Interface card between a server or workstation bus and the fibre channel network. Similar to a network interface card. Fibre channel wiring concentrator that collapses loop topology into physical star topology. Nodes are automatically added when active and removed when inactive.
Page 105 Link As applies to fibre channel, a physical connection between two ports, consisting of both transmit and receive fibres. See also Circuit. Link services Protocol for link-related actions. Loop Initialization Primitive. The signal used to begin initialization in a loop. Indicates either loop failure or resetting of a node.
Page 106 Multicast Transmission of data from a single source to a number of specified N_Ports. See also Broadcast, Unicast. Multimode Fibre-optic cabling specification allowing up to 500 meters between devices. N_Port Node Port. Port that can attach to a fibre channel port. See also NL_Port, Nx_Port.
Page 107 Ordered set A type of transmission word that occurs outside of frames, and is used to manage frame transport and differentiate fibre channel control information from data. See also Data word, Transmission word. Use 8b/10b mapping and begin with the K28.5 character. They include frame delimiters (which mark frame boundaries and describe frame contents), primitive signals (indicate events), and primitive sequences (indicate or initiate port states).
Page 108 Public loop An arbitrated loop attached to a switch. QuickLoop Can indicate either the product that allows private devices within loops to communicate over the fabric with other devices, or the set of actual devices or looplets connected in a loop by QuickLoop technology. All devices in a QuickLoop share a single AL_PA space and behave as if they are in one loop.
Page 109 SNMP Simple Network Management Protocol. Internet management protocol that does not rely on underlying communication protocols and can therefore be made available over other protocols, such as UDP/IP. Uses IP for network layer functions and UDP for transport layer functions, or TCP/IP for both. See also Community (SNMP).
Page 110 Transmission A 10-bit character encoded according to the rules of the 8b/10b algorithm. Character See also 8b/10b encoding, Transmission word. Transmission Word Group of four transmission characters, totaling 40 bits. Two types: data words and ordered sets. See also Data word, Ordered set, Transmission character. Trap (SNMP) Message sent by SNMP agent to inform SNMP management station of critical error.
Page 111 Zone Set of hosts and devices attached to same fabric and having access permission, including RSCNs and user data, to each other. Entities inside a zone are not visible to entities outside the same zone, even if the outside entities are in another zone. Equivalent to network term “virtual LAN”. Zone configuration A specified set of zones.
Page 112 Web Tools User’s Guide...
Page 113 INDEX administrative interface 16 Config Admin tab, administrative interface 89 Config Admin tab 89 Config Settings tab, Zone Administration Extended Fabric tab 91 View 44 Firmware Upgrade tab 80 Configure Thresholds tab, Fabric Watch License Admin tab 84 View 68 QuickLoop Admin tab 86 Current Settings tab, Fabric Watch Reboot Switch tab 81...
Page 114 fan, status of 16 PortStats tab, Port Information View 56 Fibre Channel Association 10 power supply, status of 16 Firmware Upgrade tab, administrative interface 80 QuickLoop Admin tab, administrative interface 86 GBIC tab, Port Information View 58 QuickLoop Settings tab, Zone Administration View 42 installing Java Plug-in 23...
Page 115 updates, software 11 User Admin tab, administrative interface 78 views administrative interface 16 Fabric 14 Fabric Events 15 Fabric Topology 15 Fabric Watch 16 Name Server Table 15 Performance 17 Port Information 16 Summary/Detail 15 Switch 15 Switch Events 16 Telnet interface 16 Zone Administration 15 Web 110...
Page 116 Web Tools User’s Guide...
