Adding 1 Drive to the
C1100 Series Jukebox
This upgrade requires code to be downloaded to the controller PCA and the drives.
BEFORE starting this upgrade, obtain the following:
*
The downloadable code required for this upgrade. FTP this code
from hpgrsg.gr.hp.com (15.38.89.10
Further download instructions are available at that address.
* A PC with a SCSI interface and appropriate cables
* A utility to download the code - DOWNLD2 or HP TOOLSET (Version 1.95ce
or later) from CoComp
Important! Read This First
)
using an "anonymous" login.
HP Part No. C1156-90000
Printed in USA June, 1996
Edition 1 0696
Advertisement
Related Manuals for HP Surestore 40fx - Optical Jukebox
Summary of Contents for HP Surestore 40fx - Optical Jukebox
- Page 1 Adding 1 Drive to the C1100 Series Jukebox Important! Read This First This upgrade requires code to be downloaded to the controller PCA and the drives. BEFORE starting this upgrade, obtain the following: The downloadable code required for this upgrade. FTP this code from hpgrsg.gr.hp.com (15.38.89.10 using an "anonymous"...
- Page 2 Hewlett-Packard Company, 1996...
-
Page 3: Esd Precautions
Adding 1 Drive to the C1100 Series Jukebox ESD Precautions The optical disk jukebox contains very sensitive electrical components. It is EXTREMELY IMPOR- TANT that you follow the proper procedures for preventing ESD (Electrostatic Discharge). Use wrist- grounding straps, anti-static mats, and anti-static work stations when removing and replacing the major assemblies. -
Page 4: Before You Begin
Before You Begin Caution Do NOT switch off power to the jukebox until you are sure the . Switching off the jukebox when the SCSI bus is inactive SCSI bus is active can cause data loss and/or indeterminate bus states. When doing this upgrade, be sure that disk cartridges are not If you need to remove moved from their original slot locations. - Page 5 Installing the 1-Drive Upgrade Caution Wear a grounding strap when working inside the outer shell of this jukebox. 1. Remove the jukebox cover by removing the four T-25 screws on that hold the cover to the rear panel. 2. Slide the cover toward the rear of the unit. Slots on the bottom of the cover will slide off their rests.
- Page 6 3. Remove the access panel (Figure 2). a. Remove the 8 T-15 screws on the top, bottom and sides of the access panel. Remove the access panel *********** Removing the Access Panel ************ Figure 2: Removing the access panel 4. Pull the picker up to the top of the chassis and insert a T-25 screw in the service hole, which holds the picker at the top of the chassis (Figure 3).
- Page 7 5. Remove the 3 cartridge “stop" screws (T-15). Figure 4: Cartridge “stop” screws Accessing Components in the Front Bezel 6. Remove the two T-25 screws that secure the front bezel to the chassis. These screws are located behind the bezel as shown in Figure 5. Figure 5: Front bezel mounting screws...
- Page 8 7. Rotate the front bezel out and disconnect the front panel cable and the mailslot sensor cable. NOTE A tab on the top of the mailslot sensor cable must be released before the cable can be unhooked. Insert a small screwdriver and push this tab down (see inset in Figure 6).
- Page 9 Figure 7: Front RFI shield Figure 8: Drive DIP switch settings 9. Check the DIP switches on the rear of the drive. Make sure they are set to the positions shown in the diagram. The right-end switch on the rearmost DIP switch is set to the ON position. All others are set OFF.
- Page 10 12. Connect the drive power, SCSI, and drive interface cables to the new drive. Connect the cables to the bottom drive first, then the top drive. Use the end connector on the SCSI cable to go to the top drive. Use either power connector on the drives.
- Page 11 20. Label the jukebox as shown in Figures 10 and 11. Do not cover the serial number. Select the appropriate label — Use the C1115 label when upgrading a C1100 (single-ended interface) jukebox. Use a C1116 label when upgrading a C1101 (differential interface) jukebox. Figure 10: Location of the product label Figure 11: Adding the upgrade label 21.
