DKU 6
Preparing for Installation
Required Clearance (a + b) (m)
Clearance (C) (m)
Floor Load Rating
2
(kg/m )
500 0.2
450 0.9
400 1.8
350 3.2
300 5.4
Adding Additional DKUs
Your disk array can consist of up to 6 DKUs. A minimum configuration
consists of one DKC and one DKU. The following diagram depicts the
order and placement of additional DKUs:
DKU 4
DKU 3
C=0 C=0.2 C=0.4
0 0
0.3 0
1.1 0.6
2.4 1.7
4.3 3.4
DKC
C=0.6 C=1.0
0 0
0 0
0.2 0
1.1 0.3
2.7 1.6
DKU 1 DKU 2
DKU 5
