Panasonic Palmcoder PV-L557 Service Manual

ORDER No.MKW9703M310
B15 (U.S.A.)
B4 (CANADA, PUERTO RICO)
ServiceManual
Compact VHS Camcorder
Panasonic°[ [ T
Palmcor,dcp°!1
I PV-L557
Consists of PV-L557D / PV-A17
VML457
Consists of VML457 / PV-A17
Models : PV-L557D
VML457
Model: PV-A17
ITEM SPECIFICATION MODEL
1 2
Power Source : Compact VHS Camcorder : DC 6V O (_
Consumption : Compact VHS Camcorder : 6V DC 10W (Max. 13W) O --
6V DC lOW -- (_
Head : 2 rotary heads plus flying erase head. helical scanning system
VkJeo Recording Signal - to - Noise Ratio : SP : more than 43dR, SLP : More than 41dB
System Horizontal Resolution (Color / Monochrome) Recording : more than 300 lines, O O
Playback : more than 230 lines
Audio Head : Normal Mono : 1 stationary head
MIC Input Level (M3 type) - 70dB (_) O
Frequency Responce : Normal Mono : SP : 100Hz - 8kHz, SLP : 100Hz - 5kHz
Signal - to - Noise Ratio : SP : more than 42dB, SLP : more than 40dB
EIA Standard (525 lines, 60 fields) NTSC color signal O (_)
SP : 1 - 5 / 16 i.p.s. (33.35mm / sec), SLP : 7 / 16 i.p.s. (11.125mm / sec)
Record / Playback Time : SP : Max. 40min, SLP : Max. 120min, with TC-40 Tape (_) O
FF Time : Less than 8min. 14sec. (TC-40 Tape)
REW Time : Less than 8min. 19sec. (TC-40 Tape)
r
Tape width 0.5inch (12.7mm) high density tape !O
Designs and Specifications are subject to change without notice.
(Please see reverse side.)
Video Signal
Tape Speed
Tape Format
1. PV-L557D (CompactVHS Camcorder)
2. VML457 (CompactVHS Camcorder)
Panasonic/Uu ar.
[© l"'--" '--" "° I
All rights reserved. Unauthodzed copying and distribution
® is a violation of law.
