Toshiba Tecra 700CS Specification Sheet

TECRA 700 SERIES Product Specifications
PROCESSOR
Intel SL-Enh. Pentium 120Mhz (2.9v/3.3v)
Integrated Coprocessor
Processor Cache
PCI BUS SYSTEM ARCHITECTURE
STORAGE
Removeable HDD (2.5" IDE)
Modular FDD (3.5" 1.44MB)
FDD Dimensions
FDD Weight
Modular CD-ROM: Toshiba XM-1202B
5.25"Quad-speed (4x)
Interface
Average Access Time
Sustained Transfer Rate
Supported Disc formats
MEMORY: 16Mbit SYNCHRONOUS DRAM, 3.3V
Standard
Maximum
Speed (100MHz)
Data width
BIOS (256KB FLASH EPROM, 120ns)
PnP 1.0a SUPPORT
DISPLAY
Type
Size
Dot Pitch
Contrast Ratio
VIDEO
VRAM: 4Mbit DRAM, 5V
Speed
Controller Chip
Bus Type
Graphics Accelerator
Color Palette
Internal Resolution
Virtual Display Mode
1
External Resolution
2
Refresh Rate(Vert./Hor.)
KEYBOARD
82 keys, 3mm Travel
12 dedicated function keys
Cursor control (8 Keys, Inverted "T")
Numeric keypad (Integrated Overlay)
Integrated Pointing Device
1.
SVGA color requires Windows driver included by Toshiba. Simultaneous viewing not provided at resolutions greater than 800 x 600 x 256colors.
2.
Refresh rate taken @ 1024x768 Non-Interlaced.
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 700.doc Rev. 30 02/07/00 nmm.
700CS
1.2 Billion Bytes: PA1214U-S2A
Yes
Yes
16KB: (8KB code; 8KB data)
Yes
1.2 billion bytes=1.13GB (12msec)
Integrated/Swappable with CD
5.1"L x 3.7"W x .6"H
Weight: .29 lbs
Optional/Swappable with FDD
.ATAPI (Enhanced IDE)
210 ms
684 KB/sec
CD-DA, CD-ROM, CD-ROM XA, Audio CD, Photo-CD, Multisession,
CD-Bridge, CD-I, CD-I Ready, ISO 9660 compliant Disc
8MB
40MB
10ns
64 bit
Yes
Yes
Dual Scan Color Passive Matrix
11.3" (9"W x 6.75"H)
.28mm x .28mm
25:1 (typ); 15:1 (min)
1 MB
60ns
C&T CT65548
PCI Bus Architecture w/burst mode
BitBLT support
226,981 colors
800 x 600 x 256 colors
640 x 480 x 256 colors
N/A
640 x 480 16.7M colors/16.7M colors
800 x 600 64K colors/64K colors
1024 x 768 256 colors/256K
70Hz/58Hz
Yes
Yes
Yes
Yes
AccuPoint
Colors/Palette
700CT
1.2 Billion Bytes: PA1214U-T2A
Yes
Yes
16KB: (8KB code; 8KB data)
Yes
1.2 billion bytes=1.13GB (12msec)
Integrated/Swappable with CD
5.1"L x 3.7"W x .6"H
Weight: .29 lbs
Optional/Swappable with FDD
.ATAPI (Enhanced IDE)
210 ms
684 KB/sec
16MB
48MB
10ns
64 bit
Yes
Yes
TFT Active Matrix Color
11.3" (9"W x 6.75"H)
.28mm x .28mm
100:1 (min)
1 MB
60ns
C&T CT65548
PCI Bus Architecture w/burst mode
BitBLT support
262,144 colors
800 x 600 x 64K colors
640 x 480 x 64K colors
1024 x 768 x 256 colors
Colors/Palette
16.7M colors/16.7M colors
64K colors/64K colors
256 colors/256K
70Hz/58Hz
Yes
Yes
Yes
Yes
AccuPoint
Page 1 of 2
