- Page 1 • USER GUIDE • MANUEL D‘UTILISATION • BEDIENUNGSANLEITUNG • MANUAL DEL USUARIO • MANUALE DELL‘UTENTE RCP-8325 8 MEGA PIXELS | ROLLEI 3 x APOGON ZOOM | 2.5“ COLOUR LTPS-LCD | USB 2.0 FULL SPEED | SDHC 4 GB SUPPORT...
-
Page 2: Fcc Compliance And Advisory
Precautions Before using the camera, please ensure that you read and understand the safety precautions described below. Always ensure that the camera is operated correctly. Do not aim the camera directly into the sun or other intense light sources which could damage your eyesight. -
Page 3: Table Of Contents
Contents PRECAUTIONS ETTING MAGE IZE AND UALITY SING THE UNCTION CONTENTS SING THE LASH SING THE ACRO GETTING STARTED & B SING THE TIMER URST ECORDING OVIE LIPS SING ETTING THE OVIE NPACKING ECORDING UDIO LIPS ARTS OF THE AMERA LAYING UDIO LIPS... - Page 4 OTATING TILL MAGES HANGING THE MAGE HANGING THE MAGE WITH FFECTS OPYING THE ILES DPOF ETTING THE HOOSING A TARTUP MAGE MAKING CONNECTIONS ONNECTING THE AMERA TO A ONNECTING THE AMERA TO A SING THE EADER ONNECTING THE AMERA TO A USB C OMPUTER WITH THE ABLE...
-
Page 5: Getting Started
Getting Started Using This Menu Getting Started This section contains information you should know before using this camera. Basic Operation This section explains all recording features of this camera. Basic Recording This section explains how to record still images, movies, and audio files. Other Recording Functions This section explains common operations about recording images. - Page 6 Unpacking Camera USB Cable AV Cable Soft Case(*) Strap 2 x AA Batteries Software Installation Quick Start Guide Battery Charger(*) CD-ROM Actual accessories may be different. Items marked with (*) are available as optional accessories. Note that the shape of the charger plug depends on the area where you purchased the camera.
-
Page 7: Parts Of The Camera
Parts of the Camera 1. Flash ( page 23) 2. Self-timer Lamp 3. Lens 4. Microphone 5. Zoom Button ( page 22) Thumbnail ( page 34) Playback Zoom page 33) 6. Playback Button page 13) 7. Menu Button ( page 15) 8. - Page 8 15. Strap Ring 16. Shutter Button page 19, 26) 17. Power Button ( page 12) 18. Speaker 19. USB/AV Terminal page 18, 45) 21. Battery Cover ( page 5) 22. Tripod Socket...
-
Page 9: Inserting The Batteries
Inserting the Batteries The camera is powered by two AA-size alkaline batteries or rechargeable Ni-MH batteries. Open the battery cover. Slide the battery cover in the direction indicated by the arrow. Insert the batteries. Insert two AA-size batteries with the positive (+) and negative (-) poles matching the directions indicated inside the battery room. -
Page 10: Card
Inserting the Memory Card You can use SD Card with this digital camera. The memory card slot is located beneath the battery cover, adjacent to the battery compartment. Open the battery cover. Slide the battery cover in the direction indicated by the arrow. -
Page 11: Language
Setting the Display Language / Date & Time When using the camera for the first time after purchasing, be sure to choose a language and set the date & time before using the camera. Setting the Display Language Turn the power on, and set the camera to the Setup Menu ( page 16). - Page 12 Apply the setting. After adjusting the settings, press the SET or the MENU button to apply the setting. If the batteries are removed for longer than 48 hours, the Date and Time will need to be re-set.
-
Page 13: Using The Lcd Monitor
Using the LCD Monitor The LCD monitor is used to compose images while recording, adjust settings and replay images. The following indicators may appear on the LCD monitor while recording or playing back images. REC mode Recording mode ( page 13) Shake warning ( page 19) Flash (... - Page 14 PLAYBACK mode Playback mode ( page 13) Battery ( page 5) Captured date & time Protect ( page 37) Voice memo ( page 28) Voice memo control ( page 28) File number / Total DPOF ( page 42) Storage media Resolution ( page 21) Recording info (...
-
Page 15: Tatus
Changing the LCD Status Press the SET/DISP button changes the LCD status as shown below: REC mode (A) OSD on (B) Guide line (C) OSD off Use the “Guide line” to compose images easily before shooting images. PLAYBACK mode (D) Full OSD (E) Basic OSD You cannot change the LCD status in the following situation: 。... -
Page 16: Turning The Power On And Off
Basic Operation Turning the Power On and Off Press the POWER button ( ) to turn on the camera in the REC mode. The power turns on, the lens extends and the LED lights in green. Press the PLAYBACK button ( ) to turn on the camera in the PLAYBACK mode. -
Page 17: Rec Mode And
Changing the Mode You can record images and voices in the REC mode. And using the PLAYBACK mode to replay, delete, or edit images on the LCD monitor. Switching between REC mode and PLAYBACK mode In REC mode, press the PLAYBACK button ( ) to switch to the PLAY mode. - Page 18 Display Title Description Q Mode Allows beginners to take pictures easily. Landscape Used for the wide scenic views. Portrait Blurring the background to focus on the subject. Snow Used for the beach or snow scenes. Fireworks Slow shutter speed to take fireworks exploding. Night Scene Shooting the subject while keeping the background night scenery.
-
Page 19: Using The Menus
Using the Menus When a menu is displayed, the four-way control and the SET button are used to make the desired settings. REC menu Turn the power on, and set the camera to the REC mode page 13). Open the REC menu. Press the MENU button ( ) to display the menu. -
Page 20: Mode
Effect Off / B&W / Sepia / Negative / Red / Green / Blue Date Stamp Off / Date / Date & Time Digital Zoom Off / On REC menu list (Movie) Menu Item Available Setting Page Movie Size Metering White Balance Auto / Setup menu... - Page 21 Press the MENU ( ) button to close the menu. Setup menu list Menu Item Functions [Shutter]: Sets the shutter sound on and off. [Start-up]: Sets a type of the start-up sound. [Beep]: Sounds Sets the operation sound on and off. [Volume]: Adjusts the volume of the shutter sound, start-up sound, beep and playback sound.
- Page 22 Menu Item Functions [Reset]: Reset file numbering each time the memory card is changed. Resetting the file number is useful for avoiding the file name duplication when images are downloaded to a computer page 46). You can review images on a television with a supplied AV cable page 44).
-
Page 23: Recording Still Images
Basic Recording Recording Still Images Turn the power on, and set the camera to the REC mode page 13). Compose the subject on the monitor. Aim the focus area ( ) to the subject that you want to take. Half press the shutter button to focus the image. The focus area ( ) becomes green while in focus, then shutter speed ( ), aperture value ( ) and ISO value ( ) are displayed. - Page 24 Using the Q mode The Q mode provides a simplified camera interface. Larger icons and fewer controls make it easier to take pictures anytime, especially for the beginners and elder users. You can use only the basic settings in the Q mode: Flash: Auto / Red eye / Force on / Slow sync / Force off Macro: Off / On...
-
Page 25: Setting Image Size Andq
Setting Image Size and Quality You can select lower image resolution and quality to decrease the image size to capture more images. Choose a suitable setting according to the desired image quality and purpose. For details, see page 15. Resolution Values Image Size Print Size 3264 x 2448... -
Page 26: Using The Zoom Function
Using the Zoom Function Your camera has a combination of optical and digital zoom functions that allows you to zoom in on far away subjects or zoom out for a wide angle shot. The optical zoom is achieved by mechanically adjusting the lens of the camera. The digital zoom enlarges or shrinks the image using a software process. -
Page 27: Using The Flash
Using the Flash The flash is not only for taking pictures when there is insufficient light, but also when the subject is in shade or in backlight conditions. Press the flash button to cycle your camera through the various flash modes. The flash will not activate when continuous shooting or movie recording. -
Page 28: Using The Macro
Using the Macro Your camera is equipped with a macro function that allows you to focus on very close subjects. In macro mode you can focus on subjects 15 cm from the lens when in the maximum wide angle setting and 40 cm in the maximum telephoto setting. Turn the power on, and set the camera to the REC mode ( page 13). -
Page 29: Using The Self - Timer & B
Using the Self-timer & Burst Use the self-timer to set a delay from the time the shutter button is pressed to the time the image is shot. Use the burst to record continuous still images shooting. Turn the power on, and set the camera to the REC mode ( page 13). -
Page 30: Recording Movie Clips
Recording Movie Clips Turn the power on, and set the camera to the Movie mode page 13). Compose the subject on the monitor. Aim the focus area ( ) to the subject that you want to take. The LCD monitor displays the available recording time ( ). -
Page 31: Recording Audio Clips
Recording Audio Clips Turn the power on, and set the camera to the Voice REC mode page 13). Press the shutter button ( ) to start recording. The voices are recorded from the microphone ( ) of the camera. Be careful to avoid touching the microphone while recording. -
Page 32: Recording A Voice Memo
Recording a Voice Memo You can add a voice memo to the still images after you record it. Turn the power on, and set the camera to the PLAYBACK mode ( page 13). Press to select a still image that you want to add a voice memo. If the image already has the voice memo recorded, the appears on... -
Page 33: Other Recording Functions
Other Recording Functions Setting the Metering There are 3 different light metering options available on your camera. Option Description Light is measured from the entire shooting screen, but gives more importance to the values near the center. Selects an exposure based on readings from multiple points in the subject area. -
Page 34: Setting The Iso
Setting the ISO With the initial settings, the ISO sensitivity is automatically set according to the brightness of the subject. Option Description Auto Sets the ISO sensitivity automatically. ISO 50 Sets the sensitivity to ISO 50 equivalent. ISO 100 Sets the sensitivity to ISO 100 equivalent. ISO 200 Sets the sensitivity to ISO 200 equivalent. -
Page 35: Setting The Sharpness
Setting the Sharpness You can select whether you want the image to have sharp or soft outlines. Option Description The edges of the image are emphasized. The edges will become sharp, but noise may occur in the recording image. The edges of the image are sharp. This is suitable for printing. The edges of the image are softened. -
Page 36: Playback
Playback Playing Back Images Turn the power on, and set the camera to the PLAYBACK mode ( page 13). The latest recorded image appears on the LCD monitor. If there are no images stored, a message [No image] appears. Press the four-way control ( ). -
Page 37: Magnifying & Trimming
Magnifying & Trimming Still Images Turn the power on, and set the camera to the PLAYBACK mode ( page 13). Select an image. Press ( ) to select the image that you want to magnify or trimming. Only still images can be magnified and trimmed. -
Page 38: Viewing In Thumbnail
Viewing in Thumbnail Turn the power on, and set the camera to the PLAYBACK mode page 13). Press the zoom button [W], a thumbnail screen is displayed. Use the four-way control to select the desired image, and press [T] or the SET button to show the selected image in full screen. -
Page 39: Deleting Files
Deleting Files Deleting a Single File Turn the power on, and set the camera to the PLAYBACK mode page 13). Open the menu. Press the MENU button ( ), then use the four-way control ( ) to select Delete ( ) and press the SET button ( ). -
Page 40: Deleting Multiple Files
Deleting Multiple Files Turn the power on, and set the camera to the thumbnail screen ( page 34). Open the menu. Press the MENU button, then Press to select to select Delete ) and press the SET button. Press to select [Select], and then press the SET button. The frame of the selected image turns green. -
Page 41: Protecting A Single File
Protecting a Single File Turn the power on, and set the camera to the PLAYBACK mode page 13). Open the menu. Press the MENU button, then use the four-way control to select Protect ) and press the SET button. Press to select [SINGLE], and then press the SET button. -
Page 42: Protecting Multiple Files
Protecting Multiple Files Turn the power on, and set the camera to the thumbnail screen ( page 34). Open the menu. Press the MENU button, then Press to select to select Protect ) and press the SET button. Press to select [Select], and then press the SET button. The frame of the selected image turns green. -
Page 43: Editing Images
Editing Images Rotating Still Images Turn the power on, and set the camera to the PLAYBACK mode page 13). Press to select the image you want to rotate. Open the menu. Press the MENU button, then use the four-way control to select Rotate ( and press the SET button. -
Page 44: Changing The Image With Effects
Changing the Image with Effects Turn the power on, and set the camera to the PLAYBACK mode page 13). Press to select the image you want to add the effect. Open the menu. Press the MENU button, then use the four-way control to select Effect ) and press the SET button. -
Page 45: Copying The Files
Copying the Files You may copy the data from the camera’s internal memory to the memory card for convenience. Be sure you have inserted a memory card into your digital camera. Set the camera to the PLAYBACK mode. page 13). Open the menu. -
Page 46: Setting The Dpof
Setting the DPOF The Digital Print Order Format (DPOF) setting allows you to select images on the memory card for printing and specify the number of print copies in advance using the camera. This is extremely convenient for sending the images to a photo developing service or for printing on a direct print function compatible printer. -
Page 47: Choosing A Startup Image
Choosing a Startup Image Turn the power on, and set the camera to the PLAYBACK mode page 13). Open the menu. Press the MENU button, then use the four-way control to select S.Image ) and press the SET button. Press to select the image you want, then press the SET button to apply the choice. -
Page 48: Making Connections
Making Connections Connecting the Camera to a TV You can display recorded images on a television with a supplied AV cable. Set the TV out to match the TV system that you are using ( page 18). Turn off the camera and the TV. Use the supplied AV cable to connect the camera to the TV set. -
Page 49: Connecting The Camera To Apc
Connecting the Camera to a PC There are two ways to download files from the camera’s internal memory or memory card to a computer: Inserting the memory card into a card reader Connecting the camera to a computer using the supplied USB cable Using the Card Reader Eject the memory card from the camera and insert it in a card reader that is... -
Page 50: Appendix
Appendix About the Folder & File Name Your digital camera automatically creates a directory of folders in the internal memory or memory card that it uses to organize still images, movie clips and other information. Folder Structure Folder name begins with a 3-digit number from 100 to 999 and followed by “DICAM”, each folder holds up to 9999 files. -
Page 51: Troubleshooting
Troubleshooting Problem Cause Solution Power does not turn on. Battery is inserted in the wrong Reload battery in the correct direction. direction. Batteries are dead. Replace or recharge batteries. The battery compartment door Make sure the battery is open. compartment door is securely closed. -
Page 52: Specifications
Specifications Sensor 8 Mega Pixels CCD, Size : 1/2.5 inch Lens Focal Length : f = 6.2 ( W ) ~ 18.6 ( T ) mm , 3X optical zoom, 4X digital zoom LCD monitor 2.5” LCD monitor Focus Range Normal: 80cm ~ Infinity ( from the tip of barrier ) Macro: (W) 15 cm ~ 1 m / (T) 40 cm~ 1 m ( from the tip of barrier ) Aperture... -
Page 53: Function Available List
Function Available List Still Capture Mode Function One time AF Focus Continuous AF Infinity Fixed 2 sec. 1/15~ Shutter Speed 1/2000 1/2000 1/2000 1/2000 1/2000 1/2000 1/2000 fixed. 1/2000 1/2000 1/2000 1/2000 1/2000 1/2000 Macro Auto Red eye Flash Force on Slow sync Force off 16:9... - Page 54 Still Capture Mode Function Auto +0.3 ~ +2.0 Exposure -0.3 ~ -2.0 Drive 2 sec. Mode 10 sec. Double Burst Highlight Hard Normal Sharpness Soft B&W Sepia Effect Negative Green Blue Date Date Stamp Date & Time Digital Zoom...
- Page 55 : Factory setting : Default : Available : Not available. : Setting is retained even after mode switch or power off. (*): Set to [OFF] after power off.
