Introducing the Switch

This chapter provides the following information:
•
•

Overview

The FC Entry Switch 8B and FC Switch 8B are eight-port Fibre Channel fabric switches that
support link speeds up to 2 Gbps. Both switches include Fabric OS version 3.0.1b or later, and are
compatible with the entire HP installed base of Fibre Channel hubs, bridges, and switches. Each
product can operate in a fabric containing multiple switches or as the only switch in a fabric.
The switch has an air-cooled chassis, and can be set up as a stand-alone unit or mounted in a 1U,
19-inch rack. It includes the following features:
•
•
•
•
•
•
Installation and Reference Guide
Overview on page 1-1

Monitoring and Managing the Switch

Eight optical ports, with the following characteristics:
-
Two LEDs (light-emitting diodes), one to indicate port status and one to indicate link
speed
-
Automatic negotiation to the highest common speed of all devices connected to the
port.
-
SFP (small form factor pluggable) interface
-
Universal and self-configuring
-
Capable of becoming an F_Port (fabric enabled), FL_Port (fabric loop enabled), or
E_Port (expansion port)
One serial port with an RS-232 connector
One 10/100 Mbps Ethernet port with an RJ-45 connector and two LEDs, one to indicate
port status and one to indicate link speed
A switch status LED on the SFP media side and fan side, indicating the overall status of
the switch
One power supply
Five fan assemblies
on page 1-3
Chapter
1
1-1
