WARNING:
Please read this entire manual before installation
and use of this pellet fuel-burning room heater.
Failure to follow these instructions could result in
property damage, bodily injury or even death.
Contact local building or fi re offi cials about
restrictions and installation inspection
requirements in your area.
IMPORTANT: Save these Instructions.
Owners & Installation Manual
918-625
FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4
GF45
FOR YOUR SAFETY:
Do not store or use gasoline or other fl ammable
vapours and liquids in the vicinity of this or any other
appliance.
Installation and service must be performed by an
authorized installer or service agency.
11/29/06
Advertisement
Table of Contents
Related Manuals for FPI Dell-Point GF45
Summary of Contents for FPI Dell-Point GF45
- Page 1 Contact local building or fi re offi cials about authorized installer or service agency. restrictions and installation inspection requirements in your area. IMPORTANT: Save these Instructions. Owners & Installation Manual 918-625 FPI FIREPLACE PRODUCTS INTERNATIONAL, LTD. 6988 Venture St., Delta, BC, Canada V4G 1H4 11/29/06...
- Page 2 GF45 TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art stove by FPI. Thank-you for purchasing a FPI FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY LABEL MAINTENANCE Safety Label ..............4 Clinker Prevention ............17 Maintenance Schedules ..........18 Tools Required ............19 INSTALLATION Maintenance of the Combustion Chamber ....19 Maintenance of the Burn-pot ........20 Important: Save these Instructions ........5 Maintenance of the Ash-extraction System ....20 Before You Start ............5 Maintenance on the Combustion Fan ......21 Important Safety Information ........5... -
Page 4: Safety Label
The safety label is located on the back panel of the stove. NOTE: FPI units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Installation
fi xed on the stove. If the stove is installed by an uncertifi ed installer, FPI will not be held 3. You can use the wall behind the stove to pass the chimney system... -
Page 6: Chimney Installation
INSTALLATION CHIMNEY INSTALLATION Important: Always use an approved 3” (76mm) PL type vent system which is approved for venting while burning corn. Using a different size vent will result in poor performance or eventual malfunction of your appliance which is not covered under warranty. Never exceed 3" diameter pipe. -
Page 7: Clearances
INSTALLATION CLEARANCES Floor Protector of 0.84k factor minimum Alcove Ceiling height is 60" (324mm) is required beneath the Hearth. (measured from bottom of the unit.) (Please check with local authorities and regulations.) UNIT DIMENSIONS Greenfi re GF45 BioEnergy Stove... -
Page 8: Vent Termination Requirements
4. If the unit is incorrectly vented or the air to fuel mixture is out of balance, a slight discoloration of the exterior of the house might occur. Since these factors are beyond the control of FPI we grant no guarantee against such incidents. -
Page 9: Horizontal Termination
INSTALLATION HORIZONTAL TERMINATION Top View Side View Greenfi re GF45 BioEnergy Stove... -
Page 10: Outside Vertical Termination
INSTALLATION OUTSIDE VERTICAL TERMINATION Side View Greenfi re GF45 BioEnergy Stove... -
Page 11: Vertical Termination
INSTALLATION VERTICAL TERMINATION Top View Side View Diagram 6 Greenfi re GF45 BioEnergy Stove... -
Page 12: Existing Class "A" Chimney
INSTALLATION EXISTING CLASS "A" CHIMNEY Diagram 7 Greenfi re GF45 BioEnergy Stove... -
Page 13: Existing Masonry Chimney
INSTALLATION EXISTING MASONRY CHIMNEY Diagram 8 Greenfi re GF45 BioEnergy Stove... -
Page 14: Optional Greenkey Installation
INSTALLATION OPTIONAL GREENKEY OPTIONAL 12 VOLT INSTALLATION BATTERY INSTALLATION This battery back-up will ensure uninterupted operation of your stove in the event of unexpected loss of electrical power. Note that this does The Greenkey is needed in order to burn Corn or Wheat, without it you not replace the regular 120 volt power supply to the stove. -
Page 15: Operating Instructions
OPERATING INSTRUCTIONS CONTROL PANEL FUNCTIONS Select Fuel Start Button This button is used to select the This button is used to ignite the appropriate fuel type that is going stove. to be burned. Stop Button Prime Stove Stove goes into shut down mode This button is used only to prime the which takes 120 minutes. -
Page 16: Starting Procedures
Failure to start your fi re properly can lead to frustrations and continued As FPI does not have any control on quality or even the type of fuel mar- re-light attempts. keted, they assume no responsibility from any faulty operation related to the type of fuel employed. -
Page 17: Burning Corn Or Wheat: Primed Hopper
OPERATING INSTRUCTIONS Burning Corn or Wheat: Primed Hopper 2) When FAN displays on the screen, gradually increase the combustion air to digital reading of “12” by pressing the "+" button. The default NOTE: If the hopper is empty, follow steps 1 to 8 to Prime Stove. is 10, it ranges from 1 - 20. -
Page 18: Maintenance Schedules
MAINTENANCE MAINTENANCE IMPORTANT NOTE: Always disconnect the power to your stove before doing any maintenace or repairs. Only a qualifi ed technician should take care of any electrical problems. Maintenance Schedule Using Wood Pellets COMPONENTS OF STOVE EACH START UP WEEKLY MONTHLY ANNUALLY... -
Page 19: Tools Required
MAINTENANCE Before each start-up, always check the level of ashes in the ash pan and remove if necessary. “Be sure to CONVECTION dispose of in a metal container and remove to outside of SYSTEM the building.” Embers can stay hot for a long time after the fi... -
Page 20: Maintenance Of The Burn-Pot
MAINTENANCE Maintenance Of The Ash-extraction System Step 1: Refer to Diagram 15 to determine the condition of the three stainless steel ash screws. Sugars released by corn or wheat can stick to the ash screws resulting in poor movement and ash removal. Check RING by removing the ash-extraction system or look inside the burn pot. -
Page 21: Maintenance On The Combustion Fan
(see Diagram 26). Give the piece of paper a little tug and if it slips out easily the gaskets need to be replaced. Use only approved gasket and adhesive obtainable from your FPI dealer. A proper high temperature gasket adhesive is also required. -
Page 22: Gf45 Technical Data
24-1/4" (616 mm) Weight Approximately 274 lb (124 kg) Type of Chimney All approved listed Pellet Vent. FPI recommends the use of corn venting for all applications. Diameter of the Chimney 3" (76 mm) of interior diameter Greenfi re GF45 BioEnergy Stove... -
Page 23: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING ERROR CODE PROBLEM SOLUTION System Cooling The thermodisc temperature has exceeded 250F. Temp Overshoot 1st Time; Hardware takes over and the unit goes Allow the unit to shutdown and unit will auto- into shutdown mode. matically restart. 2nd Time; When the unit is restarted, hardware Allow unit to shutdown. -
Page 24: Electrical Diagram (12 Volts)
TROUBLESHOOTING ELECTRICAL DIAGRAM (12 VOLTS) Pin 1 & 2 = purple wires (not used) Pin 15 = blue wire (speed control) Pin 3 & 4 = orange wires (safety) Pin 16 = red wire (Convection fan) Power supply Pin 5 & 6 = green wires (safety) Pin 17 = black wire (input) converts the AC Pin 7 = black wire (feed system) - Page 25 NOTES ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ Greenfi re GF45 BioEnergy Stove...
- Page 26 NOTES ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ Greenfi re GF45 BioEnergy Stove...
-
Page 27: Warranty
The warranty will commence on the purchase date of the appliance to the original purchaser. Any part or parts of this unit which in our judgement show evidence of such defects will be repaired or replaced at FPI’s option through an authorized distributor or agent provided that the replaced part is returned to FPI via the distributor or agent Transportation Prepaid. - Page 28 Printed in Canada © Copyright 2006, FPI Fireplace Products International Ltd. All rights reserved.
