2. Select a setting from the Brightness list.
Brightness presents the following items for selection.
Brightness
Dark
Slightly Dark
Standard
Slightly Bright
Light
3. Select Adj. Pale Color Recognizable as needed.
When Adj. Pale Color Recognizable is selected, yellow or cyan lines or
Note
other portions of images that are difficult to see when printed in white
space can become easier to see.
4. Click the OK button.

■ Media Detailed Settings

You can use the printer operation panel to perform suitable settings for ink drying time of each
media and other features. You can also so some of these settings in the Media Detailed
Settings dialog box. If the appearance of your printouts is not satisfactory, perform the settings
on this screen to make adjustments and improve the printing results.
To open the Media Detailed Settings dialog box, in the Custom Properties dialog box click
the Media Detailed Settings button.
The settings in the Media Detailed Settings dialog box are temporary; after
Note
the print job finishes the settings of the printer operation panel are restored.
The procedures for performing the settings for each item in the Media Detailed Settings dialog
box are described below.
Drying Time
You can set the time that the printer waits before it ejects another sheet (time between
pages), or the time between the printer waits each time it prints a line (time between scans)
for each type of media.
1. If the ink on the media is difficult to dry, in the Media Detailed Settings dialog box select
a time for from the Between Pages list under Drying Time to set the drying time
between pages.
Setting Up a Print Job
Setting Details
Prints a printout much darker than normal.
Prints a printout slightly darker than normal.
Prints the printout with normal brightness.
Prints a printout slightly brighter than normal.
Prints a printout much brighter than normal.
3-7
