Blade Control Handle
Recoil Starter
Figure 7
SECTION 5: OPERATING YOUR LAWN MOWER
1. Pour fresh, clean gasoline into the mower's gas
tank until the tank is full. Do not use gasoline
that is more than 30 days old.
2. Make sure to connect the mower's spark plug
wire before trying to start the engine.
3. Add engine oil to the oil fill on the mower engine.
Check the dipstick and add more if necessary.
Remember that the oil level has to touch the fill
line.
4. Locate the primer decal near the primer bulb on
the engine, and read its instruction. Using your
thumb, press the primer bulb slowly as many
times as the decal advises.
WARNING: Keep hands and feet away
from chute area on the cutting deck. The
operation of any lawn mower can result in
foreign objects being thrown into the
eyes, which can result in severe eye
damage. Always wear safety glasses or
eye shields.
NOTE: For shipping purposes your mower is set with
the wheels in a low cutting height position. For best
results raise the cutting position until it is determine
which height is best for your lawn. See the adjustment
section for details.
Gas and Oil Fill-Up
Service the engine with gasoline and oil as instructed in
the separate engine manual packed with your mower.
Read instructions carefully.
Drive Clutch
Control
Cutting Height
Adjustment Lever
Towards Better Mower Performance
9
Engine Controls
See the separate engine manual for the location and
function of the controls on the engine.
Stopping Engine
•
Release blade control handle to stop the engine
and the blade.
•
Disconnect spark plug wire and ground it to the
post on the engine.
5. Hold control handle down and pull rope firmly to
start the engine.
6. Set cutting height adjustment lever to middle
setting and mow a single pass on your lawn;
then adjust to desired height for a closer cut.
7. To mulch insert the mulch plug/cover on the
mower.
8. Before storing the lawn mower for the winter,
use stabilizer-treated fuel and run the tank dry.
9. Thirty days before start of the new season,
check the air filter, spark plug and blade on the
lawn mower, and replace if needed.
Never fill fuel tank indoors with engine
running or until the engine has been
allowed to cool for at least two minutes
after running.
Before Starting Your Mower
•
Attach spark plug wire to spark plug. Make certain
the metal cap on the end of the spark plug wire is
fastened securely over the metal tip on the spark
plug.
•
Check for proper drive clutch operation using the
NEUTRAL ADJUSTMENT TEST.
Neutral Adjustment Test
To perform the neutral adjustment test answer the
following questions.
•
With the drive clutch control released, push mower
forward and pull it backward. Does it move freely?
