Xerox DocuPrint 92C IPS Troubleshooting Manual page 30

CLEARING PAPER MISFEEDS AND JAMS
2-16
3. Raise the small green handle at the front of the fuser assembly.
4. Remove and discard any paper you find in this area.
Warning: Take care not to touch any parts in this area. They
!
may be hot enough to cause burns.
Caution: Do not use a sharp object to remove paper wrapped
around the fuser rolls. Attempting to do so could damage the
roller and require its replacement.
5. Return the small green handle to its original position.
6. Push down on the green release latch, and slide the fuser unit
back into the printer until it latches into the closed position.
7. Close the doors (left one first) and press the Continue button to
resume printing.
XEROX DOCUPRINT 92C IPS TROUBLESHOOTING GUIDE
