WITH GRIDDLE/HOTPLATE COOKTOP
Description
Parts List ...........................................................
WVOC-2H(F)(S)G Hood Section
Cabinet .........................................................
Hood Electrical and Vacuum .............................
WVOC-2H(F)(S)G Convection Oven Section
Cabinet Components ........................................
Electrical Components .....................................
WVOC-2H(F)(S)G Cooktop Components .................. 8
Ansul© Fire Detection & Suppression .......................
PL505
p/n
Rev. D
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
PARTS LIST
PL505
WVOC-2HFG
WVOC-2HSG
VENTLESS CONVECTION OVEN
CONTENTS
PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
telephone: 775-689-5703
fax: 775-689-5976
www.wellsbloomfield.com
505
page
2
4
5
6
7
9
08
0602 cps
Advertisement
Related Manuals for Wells PL505
Summary of Contents for Wells PL505
-
Page 1: Parts List
WELLS BLOOMFIELD, LLC 2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439 telephone: 775-689-5703 fax: 775-689-5976 www.wellsbloomfield.com PARTS LIST PL505 WVOC-2HFG WVOC-2HSG VENTLESS CONVECTION OVEN WITH GRIDDLE/HOTPLATE COOKTOP CONTENTS Description page Parts List ………………………………………………….. WVOC-2H(F)(S)G Hood Section Cabinet …………………………………………………... - Page 2 PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION OPTIONAL ACCESSORIES MECHANICAL MECHANICAL 20804 SET, CASTER, (2 FIXED, 2 SWIVEL) 500356 KNOB, BLACK (NOTE: GRAY OBS) 51968 CLAMP, ELEM CTR SMALL GRIDDLE 21375 SUPPORT, OVEN RACK (M4200) 500984 SPACER, LATCH STRIKE PLATE 51969 CLAMP, ELEM END SMALL GRIDDLE 21376...
- Page 3 PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION ELECTRICAL ANSUL© COMPONENTS HARDWARE 50131 TERMINAL BLOCK 3P 85A NOTE: Provided for reference only 51053 NUT, 8-32 KEPS SS (pk 100) All servicing of the fire detection and suppression 50293 ELEM, SPIRAL HOTPLATE 240V 51038 RETAINER TRADEMARK (pk 10) system must be performed by an authorized Ansul...
- Page 4 WVOC-2H... CABINET AND HOOD SECTION COMPONENTS INTERNAL BRACKETS FIRE DAMPER ASSY LABEL, CONTROL 280ºF (ref. 301187) PANEL 502782 GASKET, SILICONE 15-1/4” 502772 (2 pl) GASKET, SILICONE 18-1/2” 502773 (2 pl) ASSY, FILTER PACK 22619 PREFILTER 22618 HOUSING, LIGHT SOCKET 505098 CAGE, BULB, APPLIANCE PRE-FILTER...
- Page 5 WVOC-2H... HOOD ELECTRICAL AND VACUUM COMPONENTS FITTING, 1/2” CONDUIT ASSY, BLOWER STRAIGHT 57748 240V 502584 VACUUM SWITCH 502593 VACUUM SWITCH 502590 VACUUM SWITCH 502592 ASSY, VAC TUBE MANIFOLD 502588 VACUUM SWITCH 502591 ref Ansul® 77284 ref Ansul® 77284 SWITCH, POWER 8528-40 BUZZER, 240V SWITCH, FILTER...
- Page 6 WVOC-2H... CONVECTION OVEN CABINET COMPONENTS SUPPORT, CLIP, RACK OVEN RACK SUPPORT BUSHING, TOP 21375 63889 HINGE 505619 B I N PIN, HINGE 505610 DOOR STRIKER 505616 DOOR LATCH 505615 OVEN RACK 21376 ASSEMBLY, DOOR COMPLETE 504444 GUARD, PROX. SWITCH 65647 BRACKET PROX.
- Page 7 WVOC-2H... CONVECTION OVEN ELECTRICAL COMPONENTS ELEMENT, COVER, GASKET 2.5” SPACING INNER 63836 63866 (208V) 63800 (240V) FUSE HOLDER THERMO, HPA-EE ELEMENT, HI-LIMIT 65180 54769 PROBE, TEMP 4” SPACING OC-1 504712 63872 (208V) 63783 (240V) GASKET, ELEMENT 63834 FUSE SC-10 54871 (pk 4) WHEEL, BLOWER RELAY, E-SAFE 63797...
- Page 8 WVOC-2H... COOKTOP COMPONENTS ELEMENT, SOLID 208/240V 503973 ELEMENT, SPIRAL 240V 2400W 50293 SOLID ELEMENT HOLD-DOWN 501451 ELEMENT 240V 2250W 50496 JUMPER, ELEMENT SHORT 52054 ELEMENT CLAMP INSULATION, FIBREGLAS LONG 51968 1"x24"x48" 57407 ELEMENT CLAMP SHORT 51969 CLIP, INSULATION RETAINING 53474 (pk 12) ADAPTER, BAYONET 68746...
- Page 9 WVOC-2H... FIRE DETECTION AND SUPPRESSION SYSTEM COMPONENTS FOR USE ONLY BY AUTHORIZED ANSUL© SERVICE PERSONNEL Refer to Ansul© part no. 418078-05 ref. NOZZLE 290 R-102 Restaurant Fire Suppression ANSUL© p/n 419342 System Design, Installation, Recharge and Maintenance ref. ADAPTER, QUICK-SEAL 3/8” ANSUL©...
-
