5. Wait a few moments for the utility to load.
NOTE:
When accessing the SMU for the first time, a window is displayed requiring input of a
user-defined username and password.
6.
One of the following happens:
• If key components of the system are unconfigured, a prompt to go to the Wizard tab is
displayed. (For more information, see "Wizards" on page 69.)
• If the system is partially configured, the Configure tab is displayed. (For more information,
see "Configure" on page 25.)
• If the system is configured, the View tab is displayed. (For more information, see
"Diagnose" on page 77.)
Changing the management port IP address through the
MSA1510i controller display panel
When the MSA1510i is initially installed and powered on, an IP address is automatically assigned to
the primary management port (usually MA0). Depending on your network configuration, this default IP
address may not be accessible by the network servers.
To change the IP address of the MSA1510i management port to be in the same LAN segment as the
network servers, do the following:
1. Access the controller LCD panel management menu. Press the right (>) navigation button on the
front of the active controller (usually the front-right controller.) Network Settings should be displayed
and blinking.
LCD panel navigation buttons work as follows:
Navigation button
Right (>)
Up/Down (^/v)
Left (<)
16 Overview
In the menu
Select a blinking menu option.
Scroll through the menu options.
Not applicable.
Within a menu option
When changing IP address
settings, move to the next digit.
Change/Toggle a setting.
Accept the displayed setting and
return to the initial management
menu display.
