200712159 93-2768 RV Series Inverter-Charger Owner's Manual_Eng.qxd
Inverter/Chargers
Invert:
Charge:
Quiet Mobile Power
Congratulations! You've purchased the most advanced, feature-rich Inverter/Charger designed for recreational vehicle applications. Tripp Lite
RV Inverter/Chargers are the quiet alternative to gas generators—with no fumes, fuel or noise to deal with! You get AC electricity anywhere
and anytime you need it: rolling down the highway, dry camping in majestic back country or parked overnight at a money-saving non-electric
site. RV Inverter/Chargers provide your equipment with utility- or generator-supplied AC electricity (filtered through premium ISOBAR
protection) whenever available. In addition, your RV Inverter/Charger automatically powers your RV's 12V system and recharges your connected
battery bank—doing what traditional RV converter/chargers do. Whenever power blackouts, brownouts or high voltages occur, your RV
Inverter/Charger immediately and automatically switches over to inverting battery output to power connected AC equipment.
Better for Your Equipment
Better for Your Batteries
Better for You
Safety
Feature Identification
Operation
Configuration
Battery Selection
Mounting
Owner's Manual
PowerVerter
®
DC-to-AC
Input
Output
12 VDC
120V, 60 Hz. AC
120V, 60 Hz. AC
12 VDC
Contents
2
3
4-5
5-7
7-8
8
* Inverter/Chargers are moisture-resistant, not waterproof.
Copyright © 2008. PowerVerter
®
is a registered trademark of Tripp Lite. All rights reserved.
2/29/2008
1:55 PM
Page 1
1111 W. 35th Street, Chicago, IL 60609 USA
Premium Protection Levels
• Built-In ISOBAR
®
Surge Protection
• Automatic Overload Protection
Ideal Output for All Loads
• Frequency-Controlled Output
• Automatic Load Switching
• Balanced Load Sharing
Faster Battery Recharge
• High-Amp, 3-Stage Battery Charger (adjustable)
Critical Battery Protection
• Battery Charge Conserver (Load Sense)
• Battery Temperature Sensing
• High-Efficiency DC-to-AC Inversion
Quiet, Simple, Maintenance-Free Operation
• Multi-Function Lights & Switches
• Automatic Generator Starting
• Dead Battery Startup
• Ignition Interlock & In/Out Swap Protection
• Moisture-Resistant Construction*
Battery Connection
AC Input/Output Connection
Service/Maintenance
Troubleshooting
Warranty/Warranty Registration
Customer Support: (773) 869-1234
www.tripplite.com
®
9
10
10
11
11
surge
