Page 2: Table Of Contents
Load Capacity Charts ..........16 Decals ..............18 Transport and Lifting Instructions ......22 Specifications ............23 Contact us: Copyright © 1995 by Genie Industries First Edition: Ninth Printing, February 2009 Internet: http://www.genielift.com "Genie" and "Superlift Contractor" are e-mail: techpub@genieind.com registered trademarks of Genie Industries in the U.S.A. -
Page 3: Safety
You read, understand and obey employer's safety rules and worksite regulations. You read, understand and obey all applicable governmental regulations. You are properly trained to safely operate the machine. Part No. 33547 Genie Superlift Contractor... - Page 4 Prior to use, check the work area for drop-offs, holes, bumps, debris, unstable or slippery surfaces Do not cause a horizontal force or side load to the or other possible hazardous conditions. machine by raising or lowering a fixed or overhanging load. Genie Superlift Contractor Part No. 33547...
- Page 5 Do not use the machine as a ground for welding. Lifting Hazards Use proper lifting techniques to load or tip the machine. Use proper lifting techniques when installing or removing the load handling attachments. Part No. 33547 Genie Superlift Contractor...
- Page 6 (if equipped) will allow the load to drop 1 to machine. 3 feet / 30 to 91 cm before locking the columns. Maintain proper lubrication on the winch. See Genie Maintain a firm grasp on the stabilizer when the Superlift Contractor Parts and Service Manual for lock plates are released.
- Page 7 First Edition • Ninth Printing Operator's Manual SAFETY RULES Decal Legend Genie product decals use symbols, color coding and signal words to identify the following: Safety alert symbol—used to alert personnel to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
-
Page 8: Legend
23 Transport wheel Standard forks 15 Leg 24 Mast brace Load handling attachment 16 Hold-down bar retaining pin 25 Loading wheels/steer 17 Leg retaining pin handles Adjustable forks 18 Stabilizer (if equipped) Snap pin Genie Superlift Contractor Part No. 33547... -
Page 9: Pre-Operation Inspection
3 Always perform function tests prior to use. 4 Inspect the workplace. 5 Only use the machine as it was intended. Part No. 33547 Genie Superlift Contractor... - Page 10 Legs Stabilizers and latch plates (if equipped) Mast columns Carriage hold-down bar Cable anchor Cable and pulleys Wheels and casters Load handling attachments Nuts, bolts and other fasteners Cable (kinks, frays, abrasions) Genie Superlift Contractor Part No. 33547...
-
Page 11: Function Tests
3 Always perform function tests prior to use. Know and understand the function tests before going on to the next section. 4 Inspect the workplace. 5 Only use the machine as it was intended. Part No. 33547 Genie Superlift Contractor... - Page 12 2 Adjust to the desired position and insert the 2 Remove the leg retainer pin and lower the leg to retaining pins. the down position. Insert the pin through the leg and base. Genie Superlift Contractor Part No. 33547...
- Page 13 1 Adjust the forks to a width of 23 inches / 58.4 cm. 2 Place the load platform on the adjustable forks. Pipe Cradle 1 Attach the pipe cradles to the forks. Be sure the fasteners are tightened. Part No. 33547 Genie Superlift Contractor...
- Page 14 3 Fully lower the carriage. After lowering to the desired position, turn the winch handles toward the mast (raise the load) turn to set the brake. Genie Superlift Contractor Part No. 33547...
-
Page 15: Workplace Inspection
It is the operator's responsibility to read and remember the workplace hazards, then watch for and avoid them while moving, setting up and operating the machine. Part No. 33547 Genie Superlift Contractor... -
Page 16: Operating Instructions
3 Always perform function tests prior to use. 4 Inspect the workplace. 5 Only use the machine as it was intended. Genie Superlift Contractor Part No. 33547... - Page 17 Select a safe storage location - firm level surface, lowering to the desired position, turn the winch weather protected, clear of obstruction and traffic. handles toward the mast (raise the load) turn to set the brake. Part No. 33547 Genie Superlift Contractor...
-
Page 18: Load Capacity Charts
Load Center Zone See the chart on the next page for maximum load centers for standard forks and adjustable forks. Genie Superlift Contractor Part No. 33547... - Page 19 107 cm boom. measure to the load center 32 in 42 in 18 in 24 in 107 cm 46 cm 61 cm 81 cm Load Capacity Chart Load Center inches Model SLC-6 SLC-12 SLC-18 SLC-24 Part No. 33547 Genie Superlift Contractor...
-
Page 20: Decals
Caution - Bodily Injury Hazard 32938 Label - Use This Winch 97547 Danger - Electrocution Hazard 32939 Warning - Brake Lock 33468 Warning - No Riders 33545 Warning - Machine Safety & Setup (before serial number 9596-5288) Genie Superlift Contractor Part No. 33547... - Page 21 97547 52984 33468 97529 40513 32716 or 33454 33468 Serial Plate 32938 32885 32939 32770 32717 52675 31072 52992 52992 or or 52993 52993 or or 52994 52994 or or 52995 52995 Serial Plate Part No. 33547 Genie Superlift Contractor...
- Page 22 Cosmetic - SLC-18 97543 Warning - Load Center Chart 52995 Cosmetic - SLC-24 97545 Warning - Lock Brake 82487 Label - Read The Manual 97546 Notice - Two-Speed Shift 82964 Warning - No Riders Genie Superlift Contractor Part No. 33547...
- Page 23 First Edition • Ninth Printing Operator's Manual DECALS Shading indicates decal is on the other side of the machine. Part No. 33547 Genie Superlift Contractor...
-
Page 24: Transport And Lifting Instructions
4 Adjust the loading wheels to the desired of the rear mast column. position. Be sure the pin is properly inserted. Always place the lifting hook through the lifting bracket so that it points away from the machine. Genie Superlift Contractor Part No. 33547... -
Page 25: Specifications
24 ft 0 in 2.26 m 3.94 m 5.64 m 7.32 m Boom 6 ft 8 in 12 ft 2 in 17 ft 9 in 23 ft 3 in 2.03 m 3.71 m 5.41 m 7.09 m Part No. 33547 Genie Superlift Contractor... - Page 26 Genie North America Phone 425.881.1800 Toll Free USA and Canada 800.536.1800 425.883.3475 Genie Australia Pty Ltd. Phone + 61 7 3375 1660 Fax + 61 7 3375 1002 Genie China Genie Scandinavia Phone + 86 21 53852570 Phone + 46 31 575100...
