- Page 1 DIGIPAK PRO.V4 USER MANUAL...
-
Page 2: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS 1. Read Instructions – All the safety and operating instructions should be 14. Servicing – The user should not attempt any service to the appliance read before this product is operated. beyond that described in the operating instructions. All other servicing 2. - Page 3 INFORMATION Thank you for purchasing Stanton’s newest innovation in professional tabletop CD players. The C.324 offers up hot new features and sleek design with unmatched reliability, engineered to bring ultimate performance and control to even the most discerning artist. Designed for DJs who want to play and scratch CDs just like vinyl, our flagship tabletop CD player features a large touch-sensitive jog wheel, making it possible to mix, scratch, and beat juggle just like using a turntable.
- Page 4 CONTROL OVERVIEW M.212 Channel Gain - Adjusts the pre-fader volume for cleaner sound. Mic Input - Insert your ¼” microphone plug here. Reduce the channel gain if you notice the level indicators flashing Headphone Input - Insert your ¼” headphone plugs here. red.
- Page 5 CONTROL OVERVIEW M.212 18. Fader Start Control Jacks - Connect these jacks to the Fader input jacks of the CD player using the 3.5mm stereo mini cord. 19. Master Output - Unbalanced RCA connectors controlled by the Master level. 20. Line Inputs - Unbalanced RCA jacks for connecting stereo audio from line level sources such as CD players, HiFi VCRs, cassette decks, DAT machines, laser discs, tuners, even synthesizers or other mixing consoles.
- Page 6 SPECIFICATION M.212 INPUT / OUTPUT IMPEDANCE & SENSITIVITY: (MASTER 0 DBV OUTPUT PHONO 47K OHM /-50dBV (3.16mV) +/-2dB MASTER 1K OHM PHONES 33 OHM / 0dBV (1V) ±2dB MAX. OUTPUT (THD=1% , Maximum gain, EQ flat) MASTER MORE THAN +18dBV (8.0V) at load=100K OHM PHONES MORE THAN +4dBV (1.6V) at load=32 OHM CHANNEL BALANCE...
-
Page 7: Control Overview
CONTROL OVERVIEW C.324 12 13 TIME – Switches the time value displayed on the LCD between FX TIME ENCODER – This multi-function encoder controls various elapsed track time, remaining track time, and the total remaining time parameters of the unit, depending on the selected mode: FX Time, for the entire disc. - Page 8 CONTROL OVERVIEW C.324 14. FX SELECT – These six buttons refer to each of the individual DSP after the disc has been ejected. The sampler pitch can be adjusted by effects. Press once to engage (illuminated) and press again to disengage. turning the TIME KNOB, or by pressing the button down and rotating Use the TIME KNOB, RATIO KNOB, MINUS BUTTON, and PLUS the JOG WHEEL simultaneously.
-
Page 9: Lcd Display
CONTROL OVERVIEW C.324 36. AUDIO OUT – This analog output signal requires a pair of RCA cables (left and right) to be connected to a line level input. 37. DIGITAL OUT – This digital output signal requires one S/PDIF (75Ohm, coaxial) cable to be connected to a S/PDIF input on your mixer or computer. -
Page 10: Updating Firmware
Release MODE to go back to the normal playback mode. See "Jog Wheel Sensitivity "on page 11 for information. Updating The Firmware Firmware updates may, as necessary, become available from Stanton’s BURNING website (www.stantondj.com) as downloadable ISO files, which are When burning CD-Rs or CD-RWs for the C.324, it is strongly... - Page 11 OPERATING INSTRUCTIONS C.324 STARTING PLAYBACK Once the PITCH BEND + button is released the pitch will return to the pitch set by the PITCH SLIDER. Press the PLAY/PAUSE button during the pause or cue mode to start playback. The PLAY/PAUSE button illuminates with a solid green light The jog wheel can also be used to temporarily bend the pitch of the music during playback.
-
Page 12: Using Samples
OPERATING INSTRUCTIONS C.324 LOOPS Clearing the Pads Press the CLEAR button (#27). While it is flashing, press the pad(s) you Creating Loops wish to clear and those will also flash red. Press CLEAR once more to Engage playback by pressing the PLAY/PAUSE button, causing it to complete the process, and the pad lights will now turn off, letting you illuminate solid green (not flashing). - Page 13 OPERATING INSTRUCTIONS C.324 To record a BPM synchronized real-time sequence: SAMPLE mode LED on Program several sample cues by pressing the pads. CUE point Mode: (Sampler Off) Ensure that the SAMPLER button is not lit. Program several cues and ensure that the SAMPLER button is off; Hit the RECORD button.
- Page 14 OPERATING INSTRUCTIONS C.324 JOG WHEEL SENSITIVITY FADER START The touch sensitivity of the jog wheel can be adjusted to fit the needs and By connecting the CD player to a mixing board that has the fader start feel of different users. When adjusting the sensitivity, be conscious of feature, the crossfader will engage playback or cue mode depending on its extreme settings which may affect your performance.
-
Page 15: Specifications
SPECIFICATIONS C.324 APPLICATION Model C.324 POWER SUPPLY AC 100V, 50/60Hz (For Japan) AC 110V, 60Hz (For Taiwan) AC 120V, 60Hz (For U.S.A., Canada, Mexico) AC 220V, 50Hz (For United Arab Emirates, Chile, Argentina) AC 220V, 60Hz (For Philippines) AC 230V, 50Hz (For Europe, New Zealand, South Africa, Singapore, Israel) AC 240V, 50Hz (For Australia, U.K.) POWER CONSUMPTION: DIMENSIONS... -
Page 16: Warranty And Return Policy
Stanton’s liability for any claim, whether based on breach of contract, negligence, infringement of any rights of any party, or product liability, and relating to the merchandise shall not exceed the price received by Stanton from your purchase of such merchandise. In no event will Stanton be liable for any special, incidental or consequential damages (including loss of use, loss of profit and claims of third parties) however caused, whether by the negligence of Stanton or otherwise.
