Sony RM-V111T Operating Instructions

RM-V111T
Remote Commander
Operating Instructions
Mode d'emploi
(au verso)
Sony Corporation © 2001 Printed in Malaysia
English
About this Remote Commander Installing the Batteries
You can set up this Remote Commander to operate the following Open the battery compartment and insert two R6 (size AA) batteries
components of almost all major brands including Sony. (not supplied).
Be sure to line up the + and – on the batteries with the + and – on the
Position Factory setting Component that can be preset
battery compartment.
TV Sony TV TV
1
VCR Sony VHS VCR (VTR3) VCR
Specifications
Operable distance
Approx. 7 m (23 ft) (varies depending on the component of each
manufacturer)
Power requirements
When to replace the batteries
Two R6 (size AA) batteries (not supplied)
Under normal conditions, batteries will last up to six months. If the
Battery life
Remote Commander does not operate properly, the batteries might
Approx. 6 months (varies depending on frequency of use)
be worn out. Replace the batteries with new ones.
Dimensions
Notes
Approx. 51.8 195 31 mm (w/h/d) (2 1 / 7 3 / 1 1 / in.)
8 4 4
• Replace both batteries with new ones.
Mass
• Do not take more than 20 minutes to replace the batteries; otherwise, your
Approx. 100 g (3.5 oz.) (not including batteries)
setting of the code numbers will be erased.
Design and specifications are subject to change without notice.
Notes on Batteries
• Do not mix old batteries with new ones or mix different types of
batteries together.
• If the electrolyte inside the battery should leak, wipe the
contaminated area of the battery compartment with a cloth and
replace the old batteries with new ones. To prevent the electrolyte
from leaking, remove the batteries when you plan not to use the
Commander for a long period of time.
3-230-683-11(2)
Setting the Component Codes
To use this Remote Commander with a Sony brand component that
is already preset at the factory (see the table on the left), you can skip
this procedure.
If you are using other brand's component or if you cannot operate
even a Sony brand component, follow this procedure.
Setting by Entering the Code Number
See the supplied "Component Code Numbers" and find the code for
your component.
1
Press the S (Set) button.
2
Press the button of the component that you want to set up.
3
Enter the three-digit component code in the "Component
Code Numbers" table.
For example, to set a Philips' TV, press -86.
2
4
Press the t button.
5
Aim this Commander to your component and check if you can
operate it using this Commander.
Go through the same procedure for each component you want to set
up.
If you cannot operate your component...
• First, try repeating these set up procedures using the other codes
listed for your component (see "Component Code Numbers").
• If — after trying all the codes listed for your component — you still
cannot get the Commander to work properly, try the search
method described under "Setting by Searching for the Correct
Code".
Note
Be sure to proceed to each next step in the above procedure within 10 seconds;
otherwise, the setting mode will be canceled.
Tip
You can write down the code number on the label inside the battery
compartment lid.
Operating a Component
1
Press the button of the desired component on the
Setting by Searching for the Correct Code
Commander.
If you've tried all the code numbers listed for your component and
you still cannot get the Commander to work (or if your component
was not listed), try the following.
2
Point the Commander directly to your component and press
1
Turn on the component you wish to set up using its power
the button for the desired function.
switch.
See "Remote Button Descriptions" for details.
2
Press the S (Set) button.
Notes on using the Commander
• Using this Commander will not add new functions to your components. The
3 functions of the Commander are limited to the functions of the component
Press the button of the component that you want to set up.
itself. For example, if your TV does not have a mute function, the % button
on this Commander will not function with your TV.
• Do not forcibly remove or tear off the corner protector.
4
Aim the Commander to your component, and press and release
the PROGR+ button. Then press and release the 1 button.
Troubleshooting
5
Repeat step 4 until the correct code number is found.
Each time you press the PROGR+ button and then the 1 button, a If you're having problems setting up or using the Remote
new code number will be transmitted.
Commander:
Keep trying until your component operates as follows: • When setting up the Commander, carefully go through the
• TV, VCR or satellite tuner : the power turns off. procedures described under "Setting the Component Codes". If the
• TV without a power switch: the Channel + function works. code that's listed first for your component doesn't work, try all the
codes for your component — in the order in which they're listed. If
Be patient as you do this; it may take up to about 120 tries for a
all the codes fail to work (or if your component is not listed), try
TV, and about 60 tries for VCR until the correct code number is
using the procedures under "Setting by Searching for the Correct
located.
Code".
• Check that you're aiming the Commander directly at the
6
When the correct code is found, press the t button.
component, and that there are no obstructions between the
Commander and the component.
• Make sure the batteries you're using are not worn out, and that
7
Turn on the component again, and check that the Commander
they're inserted correctly.
can control the other functions of your component such as
• Check that the button of the TV or VCR is pressed to choose your
channel and volume control.
desired component.
• Check that the component has infrared remote capability. For
If the component does not operate properly, repeat steps 2 to 6 and
example, if your component didn't come with a remote control, it
search for another code.
probably isn't capable of being controlled by the Remote
If you still cannot get the Commander to work properly, see
Commander.
"Troubleshooting".
• Should any problem persist, reset the Commander to the factory
setting by pressing the 1, t and 2– buttons simultaneously.
Note
Be sure to proceed to each next step in the above procedure within 10 seconds;
If you have any questions or problems concerning the Remote
otherwise setting mode will be canceled.
Commander that are not covered in this manual, please call the
telephone number in the warranty.
Remote Button Descriptions
General
1 0
1 To set up the Commander.
2 2 Component select buttons. To
switch to the operations of each
3 qa
component, press the button on
4 which that component is
assigned.
qs
8 Volume up: +
5 qd Volume down: –
9 To mute the volume on TV.
6
0 To turn on and off the power of
7
the selected component.
8 qf
9 qg
Operating a TV, VCR
3 TV: To change the input mode. qa TV: To turn on.
VCR: To switch the signals To return from Teletext to TV.
supplied to the TV. VCR: To change the input
4 TV: To switch to Teletext. mode.
VCR: To expose the on-screen qs To change the programme.
display. Also to turn on the power.
5 TV/VCR: To select double-digit qd TV/VCR: To select a number
numbers. Works in the same between 20 and 29.
way as your TV's commander qf Programme up: +
or VCR's commander. Programme down: –
6 and 7 qg To operate JUMP, FLASHBACK
TV: N, x, m, M : or CHANNEL RETURN function
Fastext buttons. on the TV depending on the
VCR: N: To play.
setting of the TV's
x: To stop. manufacturer.
m: To rewind.
M: To fast-forward.
zREC: To record,
press N while
pressing z.
