24V DRIVE, ULTRA HIGH SPEED LINE THERMAL PRINTER
4" MECHANISM
FTP-641MCL101/102
OVERVIEW
This thermal printer (driven by 24 VDC) provides ultra-high speed
printing for 4-inch wide paper (114 mm). This printer is small in size,
light weight, and has low power consumption. The print head is
designed with open construction for easy maintenance.
This printer is suitable for a variety of applications, such as POS
terminals, ticket machines, label printers, measuring devices and
medical equipment.
In addition to the interface board, a driving LSI (MCU + Gate Array) is
also available.
HIGHLIGHTS
• Ultra high speed printing
It can print at 100 mm/s (800 dotlines/s) by using Fujitsu
Components' unique head drive control system.
• Compact and lightweight
The printer has a low profile of only 28 mm, and a light weight of
approximately 290 g.
• Low power consumption
The peak current for head driving is approximately 6.0 A (at 50
mm/s printing speed, 50% printing ratio).
• Easy head access
Head-open construction makes head maintenance easy,
especially for head cleaning.
• Paper auto loading function
The thermal paper can be loaded without head-up lever operation.
• High resolution
8 dots/mm head provides clear print output.
• Selectable paper paths
Front or rear insertion types are available.
FTP-641MCL102 can print on paper thicknesses of up to 150 m.
FTP-641MCL101, 102
FTP-621CU102, FTP-633GA101
FTP-621DCL002
