Fax guide
The fax function lets you scan items and fax them to one or more recipients. You can send a fax from the printer by typing the
fax number, using a shortcut number, or using the address book.
Note: To place a two-second dialing pause within a fax number, press
The dial pause appears as a comma in the "Fax to" box. Use this feature if you need to dial an outside line first.
Sending a fax using the touch screen
1
Load an original document faceup, short edge first into the ADF or facedown on the scanner glass.
Note: Do not load postcards, photos, small items, transparencies, photo paper, or thin media (such as magazine clippings)
into the ADF. Place these items on the scanner glass.
2
If you are loading a document into the ADF, then adjust the paper guides.
3
From the home screen, touch Fax.
4
Enter the fax number or a shortcut using the touch screen or keypad.
To add recipients, touch Next Number and then enter the recipient's telephone number or shortcut number, or search the
address book.
Note: To place a dial pause within a fax number, press
feature if you need to dial an outside line first.
5
Touch Fax It.
Sending a fax using the computer
The printer driver fax option allows you to "print to fax," where the printer will send a queued document as a fax rather than
print it. The fax option functions as a normal fax machine, but is controlled through the printer driver instead of the printer
control panel.
1
With a document open, click File > Print.
2
Select the printer, and then navigate to:
Properties > Fax tab > Enable fax
3
Enter the recipient fax number(s) in the "Fax number(s)" field.
Fax numbers can be entered manually or by using the Phone Book feature.
4
If necessary, enter a prefix in the Dialing prefix field.
5
Select the appropriate paper size and page orientation.
6
If you want to include a cover page with the fax, then select Include cover page with fax, and enter the appropriate
information.
7
Click OK.
.
. The dial pause appears as a comma in the "Fax to" box. Use this
Fax guide
Page 1 of 4
Advertisement
Related Manuals for Lexmark Multifunction Laser
Summary of Contents for Lexmark Multifunction Laser
-
Page 1: Sending A Fax Using The Touch Screen
Fax guide Page 1 of 4 Fax guide The fax function lets you scan items and fax them to one or more recipients. You can send a fax from the printer by typing the fax number, using a shortcut number, or using the address book. Note: To place a two-second dialing pause within a fax number, press The dial pause appears as a comma in the "Fax to"... -
Page 2: Using Fax Shortcuts
Fax guide Page 2 of 4 Notes: • The Fax option is available for use only with the PostScript driver or the Universal Fax Driver. For information on installing these drivers, see the Software and Documentation CD. • The Fax option must be configured and enabled in the PostScript driver under Configuration tab before it can be used. •... - Page 3 Fax guide Page 3 of 4 Choose content type from Text, Text/Photo, Photo, or Graphics. • Text—Use when the content of the original document is mostly text or line art. • Graphics—Use when the original document is mostly business-type graphics such as pie charts, bar charts, and animations. •...
-
Page 4: Advanced Options
Fax guide Page 4 of 4 Scan Preview This option displays the first page of the image before it is included in the fax. When the first page is scanned, the scanning is paused and a preview image appears. Delayed Send This lets you send a fax at a later time or date.
