Canon XF300 Instructions

Canon XF Plugin for Avid Media Access
Instructions
This plugin was created to allow you to easily link the clips you recorded using the camcorder to your Avid non-linear
editing system. The plugin uses Avid Media Access (AMA) architecture to link the clips in the camcorder or on a CF
card directly into a bin in Avid Media Composer or NewsCutter (collectively referred to as 'editing software'). Refer
also to the instruction manuals of the editing software used.
Preparations
This plugin is compatible with Media Composer, version 4.0.5 or later* and NewsCutter, version 8.0.5 or later*.
Complete the following preparations before using this plugin.
* As of May 2010, clips that were recorded using the 50 Mbps (4:2:2), 1280x720, 24P video configuration are not supported. Also, clips recorded
using the 25 Mbps (4:2:0), 1440x1080, 30P video configuration will be treated as 60i clips. To edit a video project as a 30p project, please use
clips recorded using the 50 Mbps (4:2:2), 30P or 35 Mbps (4:2:2), 30P video configurations.
1.
When using Media Composer 4.x.x or NewsCutter 8.x.x only Download and install the following plugin offered by
Avid: Avid AMA MXF Plug-in.
For details, refer to Avid's Web page.
2.
Start up the editing software and check the AMA settings. Make sure that the Enable AMA Volume
Management option is checked.
Linking clips directly from the camcorder or from a CF card
Using AMA architecture, you can link clips to the editing software directly from a CF card inserted into a card reader
connected to your computer. You can also connect the camcorder to the computer using a USB cable to link clips
directly from the camcorder.
For details about linking media with AMA, refer to the instruction manuals of the editing software used.
1.
Start up the editing software.
2.
Connect the camcorder or the CF card to the computer.
• CF card: Connect a commercially available card reader compatible with CompactFlash memory cards to the
computer and insert the CF card into the card reader.
• Camcorder:
Power the camcorder using the compact power adapter.
Turn on the camcorder and set in MEDIA mode.
Connect the camcorder to the computer using a USB cable. Use the optional IFC-400PCU USB cable or
similar mini-B USB cable.
• The editing software will automatically scan the CF card or the camcorder and link the clips into a bin (based
on the software's AMA settings). The Bin window will open and show the linked clips.
3.
Continue the editing operation in the editing software.
Consult the software's guides and help files as necessary.
4.
When you finish editing the clips, use the Safely Remove Hardware function to terminate the connection to
the hardware.
5.
Disconnect the card reader or camcorder form the computer and remove the CF card.
1
Windows
Version 1.0
