- Page 1 EXPAND SERIAL COMMAND FUNCTIONAL SPECIFICATIONS PLC-XK2200 PLC-XK2600 PLC-XK3010 Ver. 1.00 SANYO Electric Co., Ltd DS Company Projector Division...
-
Page 2: Table Of Contents
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications CONTENTS – Overview .........................8 Serial Interface Specification ..................8 2.1 Transfer Specification....................8 2.2 Connection.........................8 Notes for communication....................9 Name Definition ......................9 Functional Execution Command Table..............10 Image Command Table..................10 PC Adjust Control Command Table ..............10 Input Control Command Table ................10 Screen Command Table ..................11 Lamp Command Table..................11... - Page 3 PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.4.8 CF_WBAL - Command ..................20 8.4.9 CF_COLTEMP Command ................20 8.4.10 CF_PROGV Command ..................20 8.4.11 CF_NZRED Command...................21 8.4.12 CF_IMAGE Command ...................21 8.4.13 CF_COLBOARD Command ................22 8.4.14 CF_IMAGEADJ Command ................22 PC Adjust Control Command ................23 8.5.1 CF_FSYNC Command ...................23 8.5.2...
- Page 4 PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications Sound Command ....................35 8.9.1 CF_VOLUME Command................35 8.9.2 CF_MUTE Command ..................35 8.9.3 CF_MIC Command..................35 8.9.4 CF_MICGAIN Command................35 8.9.5 CF_STANDBYMICOUT Command..............36 8.10 Setting Command ....................37 8.10.1 CF_LANG Command ..................37 8.10.2 CF_MENUPOSITION Command ..............37 8.10.3 CF_INPUTSEARCH Command ..............38 8.10.4 CF_AUTOSETUPPCADJ Command.............38...
- Page 5 PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.11.4 CF_FREEZE Command .................47 8.11.5 CF_VMUTE Command...................47 Status Read Command ....................48 Format ........................48 Transfer Example ....................48 Operation Condition .....................48 Image Status Read Command ................49 9.4.1 CR_BRIGHT Command .................49 9.4.2 CR_CONT Command..................49 9.4.3 CR_COLOR Command ..................49 9.4.4 CR_TINT Command ..................49...
- Page 6 PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.7.5 CR_SRCINP3 Command ................56 9.7.6 CR_SYSTEM Command ................57 9.7.7 CR_SYSLIST Command................58 9.7.8 CR_MODELIST Command ................58 Screen Status Read Command................59 9.8.1 CR_SCREEN Command................59 9.8.2 CR_VSCALE Command ................59 9.8.3 CR_VPOS Command..................59 9.8.4 CR_HSCALE Command ................59 9.8.5 CR_HPOS Command..................60 9.8.6...
- Page 7 PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.11.12 CR_STANDBYMODE Command ...............66 9.11.13 CR_PTIMEMODE Command ..............66 9.11.14 CR_PTIMER Command................67 9.11.15 CR_PTIME Command ................67 9.11.16 CR_CCAPTIONDISP Command ..............67 9.11.17 CR_CCAPTIONCOLOR Command ............67 9.11.18 CR_RCODE Command ................67 9.11.19 CR_SECURITY Command .................68 9.11.20 CR_KEYDIS Command ................68 9.11.21 CR_PJLOCKNOW Command..............68...
-
Page 8: Overview
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications Overview 1.1 This Functional Specification defines communication functions for PLC-XK2200/2600/XK3010. 1.2 Compatible to Firmware Ver. 1.x of the projector. 1.3 Most commands can be used to control projector remotely from PC by RS-232C. Therefore, the commands are defined as Expand Serial Commands. -
Page 9: Notes For Communication
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications Notes for communication 1. Expand Serial Command is defined as one command / one line that starts with “C” and ends with carriage return (0x0D) 2. There are two types of commands: Functional Execution Command and Status Read Command. -
Page 10: Functional Execution Command Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 5. Functional Execution Command Table 5.1 Image Command Table Execute command Item CF_BRIGHT_%1[CR] Set Brightness value CF_CONT_%1[CR] Set Contrast value CF_COLOR_%1[CR] Set Color value CF_TINT_%1[CR] Set Tint value CF_IRIS_%1[CR] Set Iris value CF_SHARP_%1[CR] Set Sharpness value CF_GAMMA_%1[CR]... -
Page 11: Screen Command Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 5.4 Screen Command Table Execute command Item CF_SCREEN_%1[CR] Select Screen size CF_DZCENT_%1[CR] Cancel Digital Zoom mode CF_VSCALE_%1[CR] Set value of Vertical scale CF_VPOS_%1[CR] Set value of Vertical position CF_HSCALE_%1[CR] Set value of Horizontal scale CF_HPOS_%1[CR] Set value of Horizontal position CF_KEYSTONE_%1[CR]... -
Page 12: Setting Command Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 5.7 Setting Command Table Execute command Item CF_LANG_%1[CR] Select language for OSD CF_MENUPOSITION_%1[CR] Move menu position. CF_INPUTSEARCH_%1[CR] Set up Input search function CF_AUTOSETUPPCADJ_%1[CR] Set Auto PC in Auto Setup CF_AUTOSETUPKEYSTONE_%1[CR] Set Auto Keystone in Auto Setup CF_AUTOSETUP_%1[CR] Execute Auto Setup CF_BACKGND_%1[CR]... -
Page 13: Status Read Command Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 6. Status Read Command Table 6.1 Image Status Read Command Table Status read command Item CR_BRIGHT[CR] Get Brightness value CR_CONT[CR] Get Contrast value CR_COLOR[CR] Get Color value CR_TINT[CR] Get Tint value CR_IRIS[CR] Get Iris value CR_SHARP[CR] Get Sharpness value... -
Page 14: Screen Status Read Command Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 6.5 Screen Status Read Command Table Status read command Item CR_SCREEN[CR] Get selected screen size CR_VSCALE[CR] Get setting status of Vertical Scale CR_VPOS[CR] Get setting status of Vertical Position CR_HSCALE[CR] Get setting status of Horizontal Scale CR_HPOS[CR] Get setting status of Horizontal Position CR_KYSTNMODE[CR]... -
Page 15: Setting Status Read Command Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 6.8 Setting Status Read Command Table Status read command Item CR_LANG[CR] Get selected language CR_INPUTSEARCH[CR] Get setting status of Input search CR_AUTOSETUPPCADJ Get setting status of Auto PC in Auto setup CR_AUTOSETUPKEYSTONE Get setting status of Keystone in Auto setup CR_BACKGND[CR] Get setting status screen mode for the case of no signal... -
Page 16: Error Code Table
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 7. Error Code Table Error Code Contents -When the received data cannot be decoded -Parameter determination error (digit number error, including invalid value, etc.) The function is not available in the selected Mode Selected value is out of range (Not reflected) Command mismatched to Hardware (command for Optional function which is not installed) -
Page 17: Functional Execution Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8. Functional Execution Command 8.1 Format PC issues commands in format as below: Pattern1 : “CF_COMMAND” [CR] Pattern2 : “CF_COMMAND_”%1 [CR] CF_ : Header COMMAND : Character line %1 : Parameter (Character line) _ : Space (To separate COMMAND and Parameter) The projector decodes the received command and when it is ready to receive the next command, it returns the response. -
Page 18: Image Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.4 Image Command 8.4.1 CF_BRIGHT Command Command "CF_BRIGHT_%1”[CR] "000~063” --------------- Directly select Brightness setting value "UP” ----------------------- Current Brightness setting value + 1 "DN” ----------------------- Current Brightness setting value – 1 Set Brightness value of user control Projector does not save the value set with this command so that it resets when Details projector turning into Standby status or ALL is OFF. -
Page 19: Cf_Iris Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.4.5 CF_IRIS Command Command “CF_IRIS_%1 [CR] “ON”-------------------Set Iris to On “OFF” ”----------------Set Iris to Off Set Iris. Projector does not save the value set with this command so that it resets when Details projector turning into Standby status or ALL is OFF. -
Page 20: Cf_Wbal - Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.4.8 CF_WBAL - Command Command “CF_WBAL-%1_%2”[CR] “R” --------------------- Red “G” --------------------- Green “B” --------------------- Blue “000~063” ----------- Directly select Color value specified by White Balance%1 “UP” ------------------- Current Color value set by White Balance%1 + 1 “DN”... -
Page 21: Cf_Nzred Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.4.11 CF_NZRED Command Command “CF_NZRED_%1”[CR] “OFF” ------- Cancel Noise Reduction “L1” --------- Noise Reduction for moving image “L2” --------- Noise Reduction for still image “UP” --------------- The same operation as pressing Up key or Left key “DN”... -
Page 22: Cf_Colboard Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.4.13 CF_COLBOARD Command Command “CF_COLBOARD_%1”[CR] “RED” --------------Select Red “BLUE” ------------ Select Blue “YELLOW” ------- Select Yellow “GREEN” --------- Select Green Select Color of Colorboard mode. Image mode is automatically switched to Colorboard mode by receiving this command. -
Page 23: Pc Adjust Control Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.5 PC Adjust Control Command 8.5.1 CF_FSYNC Command Command “CF_FSYNC_%1”[CR] “0000~0031” --------------- Directly select Fine Sync setting value “UP” -------------------------- Current Fine Sync setting value + 1 “DN” -------------------------- Current Fine Sync setting value - 1 Set Fine Sync value of PC signal Projector does not save the value set with this command so that it resets when Details... -
Page 24: Cf_H - Pos Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.5.4 CF_H – POS Command Command “CF_H-POS_%1”[CR] “0000~nnnn” --- Directly select Horizontal Position setting value “nnnn” shows maximum value, it is current Total Dots value - Display Dots value “UP” -------------- Current Horizontal Position setting value + 1 “DN”... -
Page 25: Cf_Dline Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.5.7 CF_DLINE Command Command “CF_DLINE_%1”[CR] “0100”~”nnnn” --- Directly select Display Line setting value “nnnn” shows maximum value, it is current Total Line value – Vertical Position value “UP” -------------- Current Display Line setting value + 1 “DN”... -
Page 26: Input Control Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.6 Input Control Command 8.6.1 CF_INPUT Command Command “CF_INPUT_%1”[CR] “CONPUTER1” ----- Select Computer1 Input “COMPUTER2” ----- Select Computer2 Input “VIDEO” -------------- Select Video Input “UP” --------------- The same operation as pressing Up key or Left key “DN”... -
Page 27: Cf_Input1 Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.6.3 CF_INPUT1 Command Command “CF_INPUT1_%1_”[CR] “ANALOG” ---------- Select Analog RGB Input “YPBPR” ------------ Select Component “Sÿ VIDEO” -------- Select S-Video Input “SCART” ------------- Select SCART Select Computer 1 input and source specified by %1 at the same time. Details This command is available in normal Power ON status. -
Page 28: Cf_Input_%1_%2 Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.6.6 CF_INPUT_%1_%2 Command Command “CF_INPUT_%1_%2”[CR] “COMPUTER1” ------ Select Computer1 Input “COMPUTER2” ------ Select Computer2 Input “VIDEO” ---------------- Select Analog Input “S-VIDEO” ------------- Select S-video Input When %1 is COMPUTER1 “ANALOG” ----------Select Analog RGB Input “YPBPR”... -
Page 29: Cf_System Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.6.7 CF_SYSTEM Command Command “CF_SYSTEM_%1”[CR] “VGA1” ------------- Select VGA1 “XGA1” ------------- Select XGA1 “WXGA3” ------------ Select WXGA3 “1080I” --------------- Select 1080I Input is “1035I” --------------- Select 1035I Computer “720P” ---------------- Select 720P ”575P”... -
Page 30: Screen Control Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.7 Screen Control Command 8.7.1 CF_SCREEN Command Command “CF_SCREEN_%1”[CR] “NORMAL” ---------------------- Select Normal mode “FULL” --------------------------- Select Full screen mode “WIDE” -------------------------- Select Wide (16:9) mode “ZOOM” -------------------------- Select Zoom mode “TRUE” -------------------------- Select True mode Input is “CUSTOM”... -
Page 31: Cf_Vscale Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.7.3 CF_VSCALE Command Command “CF_VSCALE_%1”[CR] “032” --------- +32 “031” --------- +31 ÿ “002” --------- +2 “001” --------- +1 “000” --------- +0 “-01” ---------- -1 “-02” ---------- -2 ÿ “-31” ---------- -31 “-32” ---------- -32 “UP”... -
Page 32: Cf_Hscale Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.7.5 CF_HSCALE Command Command “CF_HSCALE_%1”[CR] “032” --------- +32 “031” --------- +31 ÿ “002” --------- +2 “001” --------- +1 “000” --------- +0 “-01” ---------- -1 “-02” ---------- -2 ÿ “-31” ---------- -31 “-32” ---------- -32 “UP”... -
Page 33: Cf_Keystone Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.7.7 CF_KEYSTONE Command Command “CF_KEYSTONE_%1”[CR] “UP” ------------- Correct Keystone distortion to reduce upper part of image “FUP” ----------- Correct Keystone distortion to reduce upper part by 2steps “DN” ------------- Correct Keystone distortion to reduce lower part of image “FDN”... -
Page 34: Lamp Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.8 Lamp Command 8.8.1 CF_LAMPH Command Command “CF_LAMPH_%1”[CR] “RST” Reset total lamp running time Details This command is available in normal Power ON status. Acceptable “000”[CR] Response Unacceptable “Error Code”[CR] 8.8.2 CF_LAMPMODE Command Command “CF_LAMPMODE_%1”[CR] “HIGH”... -
Page 35: Sound Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.9 Sound Command 8.9.1 CF_VOLUME Command Command “CF_VOLUME_%1”[CR] “000-063” -------------------------- Directly select Volume setting value “UP” --------------------------------- Current Volume setting value +1 “DN” --------------------------------- Current Volume setting value -1 Control Volume value The same operation of Volume Up/Down as projector and RC, and directly select Volume setting value. -
Page 36: Cf_Standbymicout Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.9.5 CF_STANDBYMICOUT Command Command “CF_STANDBYMICOUT_%1”[CR] “ON” ----------------------------- Set Standby MIC out to ON “OFF” ---------------------------- Set Standby MIC out to OFF Control Standby MIC out ON/OFF Details This command is available in normal Power ON status. Acceptable “000”[CR] Response... -
Page 37: Setting Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10 Setting Command 8.10.1 CF_LANG Command Command “CF_LANG_%1”[CR] “ENG” --------------------------- Select English “DEU” --------------------------- Select German “FRA” --------------------------- Select French “ITA” ----------------------------- Select Italian “ESP” ---------------------------- Select Spanish “POR” --------------------------- Select Portuguese “NED”... -
Page 38: Cf_Inputsearch Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.3 CF_INPUTSEARCH Command Command “CF_INPUTSEARCH_%1”[CR] “OFF” ------------------------- Set Input search operation to OFF “ON1” ------------------------- Set Input search operation to On1 “ON2” ------------------------- Set Input search operation to On2 Set Input search operation mode. The status set by this command is stored in EEPROM and its setting is effective after ALL is OFF Details... -
Page 39: Cf_Backgnd Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.7 CF_BACKGND Command Command “CF_BACKGND_%1” [CR] “BLUE” -------------------- Select Blue Back “USER” ------------------- Select User “BLACK” ------------------ Select Black Back “UP” ----------------------- The same operation as pressing Up key or Left key “DN”... -
Page 40: Cf_Logo Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.9 CF_LOGO Command Command “CF_LOGO_%1_%2”[CR] “0000”-”9999” ----------------- Set LOGO PIN CODE directly “OFF” ---------------------------- Disable Logo function “DFLT” --------------------------- Display Default Logo “USER” -------------------------- Display Captured Logo “UP” ----------------------- The same operation as pressing Up key or Left key “DN”... -
Page 41: Cf_P-Mane Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.11 CF_P-MANE Command Command “CF_Pÿ MANE_%1”[CR] “OFF” --------------------------------- Set Power Management to OFF “READY” ----------------------------- Set Power Management to Ready “SHUTDOWN” --------------------- Set Power Management to Shut Down mode “UP” ----------------------- The same operation as pressing Up key or Left key “DN”... -
Page 42: Cf_Ptimemode Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.15 CF_PTIMEMODE Command Command “CF_PTIMEMODE_%1”[CR] “COUNTUP” ---------------- Select Count up “COUNTDN” ---------------- Select Countdown Set operation mode of P-timer. The status set by this command is stored in EEPROM and its setting is effective Details after ALL is OFF This command is available in normal Power ON status. -
Page 43: Cf_Ccaptioncolor Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.19 CF_CCAPTIONCOLOR Command Command “CF_CCAPTIONCOLOR_%1”[CR] “COLOR” ------- Select Color “WHITE” -------- Select White Select color of Closed caption. The status set with this command is stored in EEPROM and its setting is effective even after ALL is OFF. -
Page 44: Cf_Pjpincode Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.22 CF_PJPINCODE Command Command “CF_PJPINCODE_%1”[CR] “0000” – “9999” ---------Set PJ PIN CODE directly Set PJ PIN CODE to release PJ LOCK. PIN CODE cannot be changed by this command. -When PJ LOCK is in operation PIN CODE is correct ------------------------- Command is valid (Acceptable) PIN CODE is incorrect ----------------------- Command is invalid(Error Code”102”) PIN CODE is out of %1 range ------------- Command is invalid (Error Code “? “) -
Page 45: Cf_Delayctrl Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.10.25 CF_DELAYCTRL Command Command “CF_DELAYCTRL_%1”[CR] “ON” --------------------------- Set Video delay control On “OFF” -------------------------- Set Video delay control Off Set Video delay control. Details The status set by this command is stored in EEPROM and its setting is effective even after ALL is OFF. -
Page 46: Other Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.11 Other Command 8.11.1 CF_KEYENU Command Command “CF_KEYENU_%1”[CR] “RIGHT” ------------------------- Shift Pointer on OSD Menu to right “LEFT” --------------------------- Shift Pointer on OSD Menu to left “UP” ------------------------------ Shift Pointer on OSD Menu to right “DN”... -
Page 47: Cf_Freeze Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 8.11.4 CF_FREEZE Command Command “CF_FREEZE_%1”[CR] “ON” ------------------------ Set Freeze to ON “OFF” ----------------------- Set Freeze to OFF “UP” --------------- The same operation as pressing Up key or Left key “DN” --------------- The same operation as pressing Down key or Right key Set/Cancel Freeze setting. -
Page 48: Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9. Status Read Command 9.1 Format PC issues commands in format as below: “CR_Command” [CR] Command : Character Line When projector receives the appropriate command, it returns a character line as the required data “000ÿ... -
Page 49: Image Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.4 Image Status Read Command 9.4.1 CR_BRIGHT Command Command “CR_BRIGHT”[CR] Details Get Brightness value of user control Acceptable “000_ÿ ÿ A ”[CR] Response “000”~“063” Unacceptable “Error Code”[CR] 9.4.2 CR_CONT Command Command “CR_CONT”[CR] Details Get Contrast value of user control Acceptable... -
Page 50: Cr_Sharp Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.4.6 CR_SHARP Command Command “CR_SHARP”[CR] Details Get Sharpness value of user control Acceptable “000_%a”[CR] Response “000”~“015” Unacceptable “Error Code”[CR] 9.4.7 CR_GAMMA Command Command "CR_GAMMA”[CR] Details Get Gamma value of user control Acceptable “000_%a”[CR] Response “000”~“015”... -
Page 51: Cr_Coltemp Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.4.11 CR_COLTEMP Command Command "CR_COLTEMP”[CR] Details Get Color Temp. setting value Acceptable “000_%a”[CR] “000” ------------------------------ Xlow “001” ------------------------------ Low “002” ------------------------------ Mid Response “003” ------------------------------ High “BLACK” -------------------- Blackboard(Green) mode selected “COLOR” ------------------- Colorboard selected “BLANK”... -
Page 52: Cr_Imggmd Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.4.15 CR_IMGGMD Command Command "CR_IMGGMD”[CR] Details Get Image Gamma setting status Acceptable “000_%a”[CR] “DYN” ------------ Dynamic “STD” ------------ Standard “REL” ------------ Real Response “CNM” ----------- Cinema “BKB” ------------ Blackboard “CLB” ------------ Colorboard Unacceptable “Error Code”[CR] 9.4.16 CR_COLBOARD Command... -
Page 53: Pc Adjust Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.5 PC Adjust Status Read Command 9.5.1 CR_FSYNC Command Command "CR_FSYNC”[CR] Details Get Fine Sync value Acceptable “000_%a”[CR] Response “0000”~“0031” Unacceptable “Error Code”[CR] 9.5.2 CR_TDOTS Command Command “CR_TDOTS”[CR] Details Get Total Dots value Acceptable “000_%a”[CR] “nnnn”~“mmmm”... -
Page 54: Cr_Ddots Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.5.6 CR_DDOTS Command Command “CR_DDOTS”[CR] Details Get Display Dots value Acceptable “000_%a”[CR] “0256”~“nnnn” Response (nnnn = Total Dots – Horizontal Position value) Unacceptable “Error Code”[CR] 9.5.7 CR_DLINE Command Command “CR_DLINE”[CR] Details Get Display Line value Acceptable “000_%a”[CR] “0100”~“nnnn”... -
Page 55: Video Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.6 Video Status Read Command 9.6.1 CR_SERSYS Command Command “CR_SERSYS”[CR] Get currently selected signal Details Returns auto-detected signal in Auto mode Only available for Video input. (N/A when Input is computer) Acceptable “000_%a”[CR] “1080I60”... -
Page 56: Input Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.7 Input Status Read Command 9.7.1 CR_INPUT Command Command “CR_INPUT”[CR] Details Get selected INPUT No. Acceptable “000_%1”[CR] Response Request data “1”-”3” Unacceptable “Error Code”[CR] 9.7.2 CR_SOURCE Command Command “CR_SOURCE”[CR] Details Get selected Source Acceptable “000_%1”[CR] “ANALOG”... -
Page 57: Cr_System Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.7.6 CR_SYSTEM Command Command “CR_SYSTEM”[CR] Details Get selected System Acceptable “000_%1”[CR] “VGA1” -------------- VGA1 is selected “VGA2” -------------- VGA2 is selected ÿ “XGA1”-------------- XGA1 is selected ÿ “WXGA3” --------- WXGA3 is selected “1080i”... -
Page 58: Cr_Syslist Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.7.7 CR_SYSLIST Command Command “CR_SYSLIST”[CR] Details Get selectable System titles Acceptable “000_%1_%2_..._%x” [CR] - When Input is PC-Analog “XGA1” ------------ XGA1is selectable “1080I ” ----------- 1080i is selectable Projector does not return Auto,Mode1-10 When there is no signal, it returns Error Code “101”... -
Page 59: Screen Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.8 Screen Status Read Command 9.8.1 CR_SCREEN Command Command “CR_SCREEN”[CR] Details Get selected on-screen image size Acceptable “000_%a”[CR] “NORMAL” --------------- Normal mode is selected “FULL” --------------------- Full mode is selected “WIDE” -------------------- Wide (16:9) mode is selected Input “ZOOM”... -
Page 60: Cr_Hpos Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.8.5 CR_HPOS Command Command “CR_HPOS”[CR] Details Get setting status of Horizontal Position Store Mode Acceptable “000_%1”[CR] Response “-15” ~ “015” Unacceptable “Error Code”[CR] 9.8.6 CR_ KYSTNMODE Command Command “CR_KYSTNMODE”[CR] Details Get setting status of Keystone Store Mode Acceptable “000_%a”[CR] “STR”... -
Page 61: Lamp Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.9 Lamp Status Read Command 9.9.1 CR_LAMPREPL Command Command “CR_LAMPREPL”[CR] Details Get information of Lamp Replacement time Acceptable “000_%1”[CR] “1Y” -------------------------- Over lamp replacement time “1N” -------------------------- Within lamp replacement time “1” means the number of lamps. Response (1 lamp model→... -
Page 62: Cr_Lampmsts Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.9.5 CR_LAMPMSTS Command Command “CR_LAMPSTS”[CR] Details Get Lighting status of lamp Acceptable “000_%1”[CR] “n**** ” A number of * should be among 1-4. First character shows how many lamps are incorporated in projector. -
Page 63: Sound Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.10 Sound Status Read Command 9.10.1 CR_VOLUME Command Command “CR_VOLUME”[CR] Details Get Volume value of user control Acceptable “000_%a”[CR] Response “000”~“063” Unacceptable “Error Code” [CR] 9.10.2 CR_MUTE Command Command “CR_MUTE”[CR] Details Get sound mute setting status Acceptable “000_%a”[CR] “ON”... -
Page 64: Setting Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.11 Setting Status Read Command 9.11.1 CR_LANG Command Command “CR_LANG”[CR] Details Get selected language Acceptable “000_%a”[CR] “ENG” -------------------------- English is selected “DEU” -------------------------- German is selected “FRA” -------------------------- French is selected “ITA” --------------------------- Italian is selected “ESP”... -
Page 65: Cr_Autosetupkeystone Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.11.4 CR_AUTOSETUPKEYSTONE Command Command “CR_AUTOSETUPKEYSTONE” [CR] Details Get Keystone setting status in Auto setup Acceptable “000_%a”[CR] “AUTO” -------------- Auto Keystone is Auto Response “MANUAL” ---------- Auto Keystone is Manual “OFF” ---------------- Auto Keystone is OFF Unacceptable “Error Code”[CR] 9.11.5 CR_BACKGND Command... -
Page 66: Cr_P-Manetime Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications Details Get Power management setting status Acceptable “000_%a”[CR] “OFF” -------------------------- Power Management is OFF Response “READY” ---------------------- Power Management is Ready “SHUTDOWN” ---- Power Management is set to Shut Down mode Unacceptable “Error Code”... -
Page 67: Cr_Ptimer Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.11.14 CR_PTIMER Command Command “CR_PTIMER”[CR] Details Get current status of P-timer Acceptable “000_%a”[CR] “ON” ------------------------ P-timer is in execution Response “STOP” --------------------- P-timer is paused “OFF” ----------------------- P-timer is inactive Unacceptable “Error code”[CR] 9.11.15 CR_PTIME Command Command “CR_PTIME”[CR]... -
Page 68: Cr_Security Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.11.19 CR_SECURITY Command Command “CR_SECURITY” [CR] Details Get Security Mode setting status Acceptable “000_%1[CR] “ON” ------------- PJ Lock setting on Menu is ON-1 or ON-2 Response “OFF” ------------PJ Lock setting on Menu is OFF Unacceptable “Error Code”... -
Page 69: Cr_Fancontrol Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.11.24 CR_FANCONTROL Command Command “CR_FANCONTROL”[CR] Details Get selected Fan control setting status Acceptable “000_%a”[CR] “OFF” ----------------------- Fan control is OFF Response “ON1” ----------------------- Fan control is ON1 “ON2” ----------------------- Fan control is ON2 Unacceptable “Error Code”... -
Page 70: Other Status Read Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.12 Other Status Read Command 9.12.1 CR_STATUS Command Command “CR_STATUS”(CR) Get status of Projector behavior. Details This command affects the same as ”CR0” of Basic Serial command, but this has an error code. Acceptable “000_%1”[CR] “00”= Power ON... -
Page 71: Cr_Tempwarn Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.12.5 CR_TEMPWARN Command Command “CR_TEMPWARN”[CR] Get the temperature inside a projector and its condition if it is abnormal temperature or close to abnormal temperature Details If there are several sensors installed, it is possible to get information from all the sensors at once. -
Page 72: Cr_Temp Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.12.6 CR_TEMP Command Command "CR_TEMP”[CR] Get current temperature inside a projector. Details If there are several sensors installed, it is possible to get information from all the sensors at once. Acceptable “000_%1_%2_%3”[CR] %1= Sensor 1 temperature (Outside temperature) %2= Sensor 2 temperature (Inside temperature1) %3= Sensor 3 temperature (Inside temperature2) -
Page 73: Cr_Tempfail Command
PLC-XK2200 /2600 /XK3010 Expand Serial Command Functional Specifications 9.12.7 CR_TEMPFAIL Command Command "CR_TEMPFAIL”[CR] Get the temperature inside a projector when abnormal temperature occurs. Details If there are several sensors installed, it is possible to get information from all the sensors at once. Acceptable “000_%a_%b_%c”[CR] %a ------------------ Sensor 1 temp.
