  • Page 1 Multimedia Projector PLC-XC50 MODEL PLC-XC55 Owner's Manual...

  • Page 2: Features And Design

    Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ◆...

  • Page 3: Table Of Contents

    Safety Instructions . . . . . . . . . . . . . . .5 Air Circulation Installing the Projector in Proper Position Moving the Projector Compliance .

  • Page 4: To The Owner

    SIDE and TOP – If the projector is not to be used for an extended time, unplug the projector from the power outlet. CAUTION DO NOT SET THE PROjECTOR IN GREASy, WET, OR SMOKy CONDITIONS SUCH AS IN A KITCHEN TO PREVENT A BREAKDOWN OR A DISASTER .

  • Page 5: Safety Instructions

    Do not place this projector on an unstable cart, stand, or table. The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector.

  • Page 6: Air Circulation

    To transport the projector through a courier or transport service, consult your dealer for their information. – Do not put the projector in a case before the projector is cooled enough. Do not point the projector up to project an image.

  • Page 7: Compliance

    Telephone No. : (818)998-7322 The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada: AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).

  • Page 8: Part Names And Functions

    Filter Cover ⑭ Adjustable feet Kensington Security Slot  This slot is for a Kensington lock used to deter theft of the projector. *Kensington is a registered trademark of ACCO Brands Corporation. Security Bar  A commercially available anti-theft chain or wire can be attached to the security bar on the projector.

  • Page 9: Rear Terminal

    Rear Terminal ② ① ① CONTROL PORT When the projector is controlled by a computer, connect to this jack with serial control cable. ② COMPUTER IN  / COMPONENT IN Connect output signal from a computer, RGB scart 21-pin video output or component video output to this terminal.

  • Page 10: Top Control

    Part Names and Functions Part Names and Functions Top Control ① ② ⑪ ⑩ POWER indicator ① – Light red when the projector is in stand-by mode. – Light green during operations. – Blink green in the Power management mode . (p.50) – Blink red during cooling down. LAMP REPLACE indicator ② Turn yellow when the life of the projection lamp draws to an end. (pp.60, 71-72) WARNING TEMP. indicator ③...

  • Page 11: Remote Control

    – Do not bend, drop or expose the remote control to moisture or heat. – For cleaning, use soft dry cloth. Do not apply benzene, thinner, spray or any chemical material. POWER ON/STAND-BY button ① Turn the projector on or off. (pp.18, 19) COMPUTER 2 button ② Select COMPUTER 2 input source. (pp.25, 38) COMPUTER 1 button ③ Select Computer 1 (Analog) or Computer 1 (Digital) input source. (pp.25, 26) VIDEO button ④...

  • Page 12: Remote Control Battery Installation

    ● Dispose of used batteries according to the instructions. Operating Range Point the remote control toward the projector (Infrared Remote Receiver) when pressing any button. Maximum operating range for the remote control is about 16.4' (5 m) and 60° in front of the projector.

  • Page 13: Installation

    Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set horizontally to the flat screen.  Notes: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image.

  • Page 14: Connecting To A Computer

    • Input sound to the COMPUTER 1 AUDIO IN terminal when using the COMPUTER IN 1 / DVI-I terminal as input. • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. Monitor Output...

  • Page 15: Connecting To Video Equipment

     Note: • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. Composite Video and Audio Output (R) (L) (Video)

  • Page 16: Connecting To Component Video And Rgb (Scart) Equipment

    • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. • See page 76 for ordering optional parts. Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables.

  • Page 17: Connecting The Ac Power Cord

    NOTE ON THE POWER CORD AC power cord must meet requirement of the country where you use the projector. Confirm the AC plug type with the chart below and proper AC power cord must be used. If supplied AC power cord does not match your AC outlet, contact your sales dealer.

  • Page 18: Basic Operation

    After the countdown, the input source that was selected the last time and the Lamp mode status icon (see page 51) appears on the screen. If the projector is locked with a PIN code, PIN code Input Dialog Box appears. Enter the PIN code as instructed below.

  • Page 19: Turning Off The Projector

    • The fan rotation will terminate directly if the AC power cord is unplugged immediately after the projector is turned off. • The projector can be turned on after the POWER indicator turns red. The waiting time to restart will be shortened when the normal power-off processing for fan cooling is completed, compared with the time the AC power cord is immediately unplugged after the power-off.

  • Page 20: How To Operate The On-Screen Menu

    Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. Refer to the following pages regarding each adjustment and setting procedures. Press the MENU button to display the On-Screen Menu. ◄►...

  • Page 21: Menu Bar

    G/B) / Sharpness / Gamma / Noise reduction / Progressive ] (pp.42-43) Basic Operation Setting Menu U s e d t o s e t t h e projector's operating configurations. (pp.45-56) Sound Menu Used to adjust the volume or mute the sound.

  • Page 22: Zoom And Focus Adjustment

    Basic Operation Zoom and Focus Adjustment Open the slide shutter. Rotate the Zoom Ring to zoom in and out. Rotate the Focus Ring to adjust the projected picture focus. Close the slide shutter.  Note: Close the slide shutter of lens operation part to keep out dust just after zoom and focus adjustments.

  • Page 23: Sound Adjustment

    Sound Adjustment Direct Operation Volume Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Press the MUTE button on the remote control to cut off the sound.
  • Page 24  Note: Lamp mode cannot be changed for a while after turning on the projector. Lamp needs some time to stabilize after the power is turned on. Stored lamp mode will be active after the lamp is stabilized.

  • Page 25: Computer Input

    Computer Input Input Source Selection (RGB: Computer 1 (Analog)/Computer 2 ) Direct Operation Choose Computer 1 (Analog) or Computer 2 by pressing the INPUT button on the top control or choose Computer 1(Analog) by pressing the COMPUTER 1 button on the remote control or choose computer 2 by pressing COMPUTER 2 button on the remote control.

  • Page 26: Input Source Selection (Rgb(Pc Digital), Rgb(Av Hdcp))

    The specification of HDCP is decided and controlled by Digital Content Protection, LLC. Should the specification be changed, this projector may not display the digital content protected by HDCP. • When the Input Search function is set On1 or On2, the input signal will be searched automatically (p.46)

  • Page 27: Computer System Selection

    WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If Computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional setting. (Signal formats provided in this projector is shown on pages 73-74)

  • Page 28: Auto Pc Adjustment

    To store adjustment parameters Adjustment parameters from Auto PC Adjustment can be memorized in this projector. Once parameters are memorized, the setting can be done just by selecting Mode in the PC System Menu (p.27). See "Store" on page 30.

  • Page 29: Manual Pc Adjustment

    Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has 5 independent memory areas to memorize those parameters manually adjusted.
  • Page 30 ◄► Press the Point buttons to decrease/increase the value. Display area V Adjust the vertical area displayed by this projector. Press ◄► the Point buttons to decrease/increase the value. Reset To reset the adjusted data, select Reset and press the SELECT button.

  • Page 31: Image Level Selection

    Dynamic Picture level suitable for viewing picture in a bright room. Standard Normal picture level preset on this projector. Real Picture level with improved halftone for graphics. Blackboard (Green) Picture level suitable for the image projected on a blackboard.
  • Page 32 SELECT button. Dynamic Picture level suitable for viewing picture in a bright room. Standard Normal picture level preset on this projector. Real Picture level with improved halftone for graphics. Blackboard (Green) Picture level suitable for the image projected on a blackboard.

  • Page 33: Image Level Adjustment

    Image Level Adjustment Press the MENU button to display the On-Screen ◄► Menu. Press the Point frame pointer to the Image Adjust Menu icon. ▲▼ Press the Point buttons to move the red frame pointer to the item that you want to adjust, and then press the SELECT button.

  • Page 34: Screen Size Adjustment

    Image Level Selection on page 31. Quit Exit the Image Adjust Menu. Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen ◄►...
  • Page 35 Wide Provide the image to fit wide video aspect ratio (16:9) by expanding the image width uniformly. This function can be used for providing a squeezed video signal at 16:9. Full Provide the full screen image. Custom Adjust the screen scale and position manually with this function.
  • Page 36 Computer Input For zooming in and out the images Digital zoom + When the Digital zoom + is selected, the On-Screen Menu disappears and the message "D. zoom +" is displayed. Press the SELECT button to expand the image size. And ▲▼◄►...

  • Page 37: Video Input

    Video Input Input Source Selection (Video, S-video) Direct Operation Choose Video by pressing the INPUT button on the top control or choose Video by pressing the VIDEO button or choose S-video by pressing the S-video button on the remote control. Before using these buttons, correct input source should be selected through menu operation as described below.

  • Page 38: Input Source Selection (Component, Rgb Scart 21-Pin)

    Video Input Input Source Selection (Component, RGB Scart 21-pin) Direct Operation Choose Computer 2 by pressing the INPUT button on the top control or press the COMPUTER 2 button on the remote control. Choose Component by pressing COMPONENT button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below.

  • Page 39: Video System Selection

    When Video System is PAL-M or PAL-N, select system manually. PAL/SECAM/NTSC/NTSC4 .4/PAL-M/PAL-N If the projector cannot reproduce proper video image, it is necessary to select a specific broadcast signal format among PAL, SECAM, NTSC, NTSC 4.43, PAL-M, and PAL-N.

  • Page 40: Image Level Selection

    Dynamic Picture level suitable for viewing picture in a bright room. Standard Normal picture level preset on this projector. Cinema Picture level adjusted for the picture with fine tone. Blackboard (Green) Picture level suitable for the image projected on a blackboard.
  • Page 41 SELECT button. Dynamic Picture level suitable for viewing picture in a bright room. Standard Normal picture level preset on this projector. Cinema Picture level adjusted for the picture with fine tone. Blackboard (Green) Picture level suitable for the image projected on a blackboard.

  • Page 42: Image Level Adjustment

    Video Input Image Level Adjustment Press the MENU button to display the On-Screen ◄► Menu. Press the Point frame pointer to the Image Adjust Menu icon. ▲▼ Press the Point buttons to move the red frame pointer to the item that you want to adjust, and then press the SELECT button.

  • Page 43: Press The Point ◄ Button To Soften The Image And The Point ► Button To Sharpen The Image. (From 0 To 15.)

    L1 ..Select "L1" for an active picture. L2 ..Select "L2" for a still picture. Film . . . Select "Film" for watching a film. With this function, the projector reproduces pictures faithful to the original film quality. Reset To reset the adjusted data, select Reset and press the SELECT button.

  • Page 44: Screen Size Adjustment

    Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen ◄► Menu. Press the Point frame pointer to the Screen Menu icon.

  • Page 45: Setting

    Setting Setting This projector has Setting menu that allows you to set up the other various functions described as follows: Press the MENU button to display the On-Screen ◄► Menu. Press the Point frame pointer to the Setting Menu icon.
  • Page 46 AUTO SET button on the remote control. On2 . . . Input search works under the situation below. • When turning on the projector with pressing the POWER ON/STAND-BY button on the top control or on the remote control.
  • Page 47 Countdown off . . . Show the input image instead of the countdown when turning on the projector. Use this function when you want to project the image as early as possible even when the lamp is not bright enough.
  • Page 48 After capturing the projected image, go to the Logo select function and set it to "User". Then the captured image is displayed when turning on the projector next time or pressing the NO SHOW button. (p.24) To capture the image, select [Yes]. To cancel the Capture function, select [No].
  • Page 49 WRITE DOWN THE NEW PIN CODE IN COLUMN OF THE LOGO PIN CODE NO . MEMO ON PAGE 7, AND KEEP IT SECURELy . SHOULD THE LOGO PIN CODE BE LOST OR FORGOTTEN, THE PROjECTOR CAN NO LONGER BE OPERATED . Logo PIN code lock ▲▼...
  • Page 50 For reducing power consumption as well as maintaining the lamp life, the Power management function turns off the projection lamp when the projector is not used for a certain period. When the input signal is interrupted and no button is pressed for more than 30 seconds, the timer display with "No signal"...
  • Page 51 AC power cord to a wall outlet.  Note: Be sure to turn the projector off properly (see "Turning Off the Projector" on page 19). If the projector is turned off in the incorrect sequence, the On start function does not operate properly.
  • Page 52 (Code 2). This switching function prevents remote control interference when operating several projectors or video equipment at the same time. When operating the projector in "Code 2", both the projector and the remote control must be switched to "Code 2".
  • Page 53 Security (Key lock and PIN code lock settings) This function allows you to use Key lock and PIN code lock function to set the security for the projector operation. Key lock This function locks operation of the top control or the remote control.
  • Page 54 DOWN THE NEW PIN CODE IN COLUMN OF THE PIN CODE NO . MEMO ON PAGE 7, AND KEEP IT SECURELy . IF yOU FORGET yOUR PIN CODE, THE PROjECTOR CAN NO LONGER BE STARTED . Enter a PIN code ▲▼...
  • Page 55 Warning log This function records anomalous operations while the projector is in operation and use it when diagnosing faults. Up to 10 warning logs are displayed with the latest warning message at the top of the list, followed by previous warning messages in chronological order.
  • Page 56 If the filter is out of scroll and the projector reaches a time set in the timer setting, Fig. 2 appears on the screen, indicating that the filter cartridge replacement is necessary.

  • Page 57: Maintenance And Care

    This projector has an electrically operated filter which helps you to replace the filter easily. The projector monitors the condition of the filter at all time and replaces a filter with a new one automatically when it detects the clogging.

  • Page 58: Replacing The Filter Cartridge

    Replacing the Filter Cartridge Turn off the projector, and unplug the AC power cord from the AC outlet. First, clean up the dust on the projector and around the air vents. Loosen 2 screws of the filter cover with a screwdriver and open the filter cover.

  • Page 59: Resetting The Filter Counter

    Resetting the Filter Counter Be sure to reset the Filter counter after replacing the filter cartridge. Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the Setting Menu icon. Use the Point ▲▼buttons to move the red frame pointer to Filter counter and then press the SELECT button.

  • Page 60: Lamp Replacement

    LAMP REPLACE indicator should light is depending on the lamp mode. CAUTION Allow a projector to cool, for at least 45 minutes before you open the Lamp cover. The inside of the projector can become very hot. CAUTION For continued safety, replace with a lamp of the same type.
  • Page 61 Follow these steps to replace the lamp. Turn off the projector and disconnect the AC power cord. Allow the projector to cool for at least 45 minutes. Loosen the screw with a screwdriver, slide and open the lamp cover. Loosen 2 screws of the lamp with a screwdriver and pull out the lamp upwards vertically by grasping the handle.

  • Page 62: Resetting The Lamp Counter

    Additionally, check carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service.

  • Page 63: Warning Temp. Indicator

    WARNING TEMP . indicator The WARNING TEMP. indicator shows the state of the function which protects the projector. Check the state of the WARNING TEMP. indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING TEMP .

  • Page 64: Cleaning The Lens Cover

    Avoid using an excessive amount of cleaner. Abrasive cleaners, solvent, or other harsh chemicals might scratch the surface. When the projector is not in use, put the projector in an appropriate carrying case to protect it from dust and scratches.

  • Page 65: Appendix

    – Make sure you have properly connected the projector to peripheral equipment as described on pages14-16. – Make sure all equipment is connected to AC outlet and the power is turned on. – When you operate the projector with a computer and it does not project an image, restart the computer. Problem No power The initial display is not shown .
  • Page 66 Capture function does not work Auto setup does not work properly Auto keystone does not work properly even when the projector is tipped The image is distorted or runs off PIN code dialog box appears at the start-up – Check the Ceiling/Rear function. (See page 50) –...
  • Page 67 High voltages are used to operate this projector . Do not attempt to open the cabinet . If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Give the model number and explain about the problem. We will advise you how to obtain service.

  • Page 68: Menu Tree

    Appendix Menu Tree　 Computer Input/Video Input Computer 1 (Analog) Input Computer 1 (Digital) Computer 2 Video Sound Sound Volume Mute Quit Computer Input System (1) PC Adjust Auto PC Adj. Fine sync Total dots Horizontal Vertical Current mode Clamp Display area H Display area V Reset Mode free...
  • Page 69 Image Select Dynamic Standard Real Blackboard (Green) Colorboard Image 1 Image 2 Image 3 Image 4 Image Adjust Contrast Brightness Color temp. Green Blue Sharpness Gamma Reset Store Quit Screen Normal True Wide Full Custom Scale H&V Position Common Reset Quit Digital zoom + Digital zoom –...
  • Page 70 Closed Caption Off/CC1/CC2/CC3/CC4 Color/White Quit Lamp control Normal/Auto/Eco Filter control Yes/No Remote control Code 1/Code 2 Security Key lock Projector Remote Control Quit PIN code lock PIN code lock entry PIN code change Quit Quit L1/L2 Warning log Lamp counter Hour(s)

  • Page 71: Indicators And Projector Condition

    (approx. 0.5 seconds ON, 0.5 seconds OFF) LAMP Projector Condition REPLACE yellow The projector is off. (The AC power cord is unplugged.) The projector is in stand-by mode. Press the POWER  ON/STAND-BY button to turn on the projector. ...
  • Page 72 WARNING FILTER indicator on the top control lights up. Replace the filter as soon as possible. If the filter is out of scroll and the projector reaches a time set in the timer setting, Fig. 3 appears on the screen and the WARNING FILTER indicator lights up.

  • Page 73: Compatible Computer Specifications

    Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V, H-Frequency below mentioned and less than 140 MHz of Dot Clock for Analog signal and 110 MHz of Dot Clock for digital signal. When selecting these modes, PC adjustment can be limited.
  • Page 74 Appendix When the input signal is digital from DVI terminal, refer to the chart below. ON-SCREEN H-Freq . RESOLUTION DISPLAy (KHz) D-VGA 640 x 480 31.47 D-480p 640 x 480 31.47 D-575p 768 x 575 31.25 D-SVGA 800 x 600 37.879 D-XGA 1024 x 768...

  • Page 75: Technical Specifications

    Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Foot Adjustment Panel Resolution LCD Panel System Panel Resolution Number of Pixels Signal Compatibility Color System High Definition TV Signal Scanning Frequency Optical Information Projection Image Size (Diagonal)

  • Page 76: Optional Parts

    Appendix Accessories Owner's Manual (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable PIN Code Label ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.

  • Page 77: Configurations Of Terminals

    Configurations of Terminals COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG) DVI-I (DIGITAL/ANALOG) C1 C2 Terminal : Analog RGB (Mini D-sub 15 pin) CONTROL PORT CONNECTOR (D-sub  pin) Analog Red Input Analog Green Input Analog Blue Input Analog Horiz. sync Analog Ground (R/G/B) T.M.D.S.

  • Page 78: Dimensions

    Appendix Dimensions 2.81(71.5) 16.14 5.91(150.2) (102.0) (50.8) (230.0) (50.0) Unit: inch (mm) Screw Holes for Ceiling Mount Screw: M4 Depth: 0.47(12.0) 4.04(102.7) 4.38(111.2)

  • Page 79: Pin Code Number Memo

    PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No .
