HARDWARE OPTIONS
IP Transport Stream Output
(RX83XX/HWO/IP/OUT, FAZ 101 0108/22)
•
Encapsulation of transport stream output into IP multicast
•
MPTS or single SPTS output stream
•
2x Gigabit Ethernet RJ-45 interfaces
Russian SECAM Output
(RX83XX/HWO/RSECAM, FAZ 101 0108/33)
•
High quality Russian SECAM output
•
Mutually exclusive with IP TS output option
SOFTWARE OPTIONS
Input Options
The RX8330 comes with DVB-S, QPSK support as standard. The unit can
also be licensed to support the DVB-S2 satellite transmission standard.
DVB-S2 QPSK License
(RX83XX/SWO/DVBS2/QPSK, FAZ 101 0108/6)
•
Adds DVB-S2 QPSK capability to DVB-S2 input option card
DVB-S2 8PSK License
(RX83XX/SWO/DVBS2/8PSK, FAZ 101 0108/4)
•
Adds DVB-S2 QPSK, 8PSK capability to DVB-S2 input option card
DVB-S2 16APSK License (RX83XX/SWO/DVBS2/16APSK)*
•
Adds DVB-S2 QPSK, 8PSK and 16APSK capability to DVB-S2 input
option card
DVB-S2 Low Symbol Rate License
(RX83XX/SWO/DVBS2/LSYM, FAZ 101 0108/5)
•
Enables DVB-S2 symbol rate of 1 Msym/s to 5 Msym/s
DVB-S2 Multi-Transport Stream License
(RX83XX/SWO/DVBS2/VCM)*
•
Provides DVB-S2 Variable Coding and Modulation support
•
Single TS output
Null Packet Detection Redundancy Switching
(RX83XX/SWO/NULL, FAZ 101 0108/17)
•
Redundancy switching from primary to secondary input triggered by
presence of a user defined % of null packets in the incoming stream
Decoding Options
The RX8330 is designed to support a range of video decoding standards
MPEG-2 SD Decoding
(RX83XX/SWO/MPEG2/SD, FAZ 101 0108/10)
•
Enables MPEG-2 SD 4:2:0 decoding
MPEG-2 HD Down-conversion
(RX83XX/SWO/MPEG2/HD, FAZ 101 0108/9)
•
Enables MPEG-2 SD and HD 4:2:0 decoding
•
HD video is down-converted and presented as SD on CVBS output
MPEG-4 AVC SD Decoding
(RX83XX/SWO/MP2/MP4/SD, FAZ 101 0108/12)
•
Enables MPEG-2 and MPEG-4 AVC SD 4:2:0 video decoding
MPEG-4 AVC HD Down-conversion
(RX83XX/SWO/MP2/MP4/SD/HD, FAZ 101 0108/11)
•
Enables MPEG-2 SD and HD, MPEG-4 AVC SD and HD 4:2:0 decoding
•
HD video is down-converted and presented as SD on CVBS output
Video Output Options
The RX8330 is always supplied with analog composite video output. The
RX8330can additionally be enabled with this option.
SDI Digital Video Output (RX83XX/SWO/SDI, FAZ 101 0108/35)
•
Enables SDI digital video output on RX8330 unit
Ericsson RX8330 Distribution Receiver
Screw Terminal Audio Break-Out Cable
(RX8XXX/CABLE/SCRTRM, FAZ 101 0108/23)
•
Provides screw terminal connections for analog audio output
•
1x stereo pair per breakout cable
XLR Terminal Audio Break-Out Cable
(RX8XXX/CABLE/XLR, FAZ 101 0108/24)
•
Provides XLR terminal connections for analog audio output
•
1x stereo pair per breakout cable via 2x XLR connectors
Security Options
Password Protection of Web Browser
(RX83XX/SWO/PW, FAZ 101 0108/29)
•
Enables password protection feature of web browser control
Audio Options
®
Dolby
Digital Decode (RX83XX/SWO/AC3, FAZ 101 0108/28)
•
Enables decoding of Dolby Digital Audio
•
2x 2.0 (stereo) decoding
•
2x 5.1 down-mix to 2.0 (stereo)
AAC Decode (RX83XX/SWO/AAC, FAZ 101 0108/2)
•
Enables decoding of AAC-LC and HE-AAC
•
2x 2.0 (stereo) decoding
•
2x 5.1 down-mix to 2.0 (stereo)
Conditional Access Options
Multi-Service CAM Decryption
(RX83XX/SWO/MSD, FAZ 101 0108/13)
•
Decrypt multiple services via professional CAMs
•
Simultaneously decrypt up to 10 services or 24 PIDs max
Director by Ericsson Multi-service Decryption
(RX83XX/SWO/DIR5/MSD, FAZ 101 0108/3)
•
Director multi-service decryption,
•
Director over-air control and software download
BISS Multi-service CA
(RX83XX/SWO/BISS/MSD, FAZ 101 0108/16)
•
Multi-service decryption for BISS
•
Support for multiple BISS keys
Stream Processing Options
Single Service Filtering
(RX83XX/SWO/SING/SERVFILT, FAZ 101 0108/15)
•
Filter multiple services to output a single service
•
Re-map PIDs for the outgoing service
Multi-Service Filtering
(RX83XX/SWO/MULT/SERVFILT, FAZ 101 0108/14)
•
Filter N multiple incoming services to M outgoing services
•
Re-map PIDs for a single service
•
CBR MPTS transport stream output
•
Service splitting for multiple IP SPTS output
SMPTE 2022M Pro-MPEG FEC License on IP TS Output
(RX83XX/SWO/IP/OUT/PROMPEG, FAZ 101 0108/8)
•
Enables SMPTE 2022M Pro-MPEG FEC capability for the IP output
card
•
Requires IP output card
Data Options
High Speed Data Output (RX83XX/SWO/IP/DATA, FAZ 101 0108/7)
•
MPE based data de-encapsulation of IP data
•
Requires IP TS output option
08-2012-v6
