Sanyo PLC-XD2200 - XGA Able Multimedia Projector Specification Sheet

2200/2600 LUMENS
PLC - X D2200/2600
PLC - X D2200/2600
ULTRAPORTABLE PROJECTOR
Built-in Network
3LCD
ULTRA-COMPACT, FULLY PORTABLE XGA DESIGN
Not much larger than a laptop PC, the PLC-XD2200/2600 weighs
less than 5.7 pounds and delivers true XGA picture quality in a
versatile, go anywhere system.
COMPLETE EASY AUTO SET UP FUNCTION, SMART AUTO
INPUT SEARCH AND AUTO VERTICAL KEYSTONE
CORRECTION
PLC-XD2200/2600 provides "Auto Set Up Function" that corrects
keystone shaped distortion by searching for an input signal and
detecting projector incline, therefore reducing set up time.
PLC-XD2200/2600 automatically compensates for keystone picture
distortion. Auto Keystone Correction, Auto Input Search and Auto PC
Adjustment make it a easy to use smart projector.
WIRED LAN (RJ-45) FOR NETWORK PROJECTOR CONTROL
This model is equipped with Wired LAN (RJ-45) that allows you to
manage and control the projector via Network. It is possible to check
the operating time of lamp and manage the warning notification by
email. Power ON/OFF and switching of the input signal can be
controlled.
DUAL D-SUB15 and Dual Audio INPUTS
The PLC-XD2200/2600 offers excellent flexibility via a pair of
D-Sub15 RGB and Audio input terminals. This model can be used
with Dual D-Sub15 and Dual audio input and also trading audio
output follows input source to audio output automatically. One of the
D-Sub15 terminals can even be switched between input and monitor
output for greater programming flexibility.
BLACK BOARD / COLOR BOARD MODE
The PLC-XD2200/2600 is compatible with four variously colored (red,
blue, green, and yellow) projection surfaces via 'Color Board Mode'
without a screen.
ULTRA-LONG UNFAILING LAMP: 6000H (eco)
The PLC-XD2200/2600 allows saving your total cost of ownership
with equipping ultra long life lamp. This lamp enable to be used
6000H with eco mode in ideal condition.
CLOSED CAPTION
PLC-XD2200/2600 is Closed Caption compatible.
XGA ULTRAPORTABLE PROJECTOR
Resolution
Brightness (typical)
Contrast Ratio
Image Size
Aspect Ratio
Projection Lamp
Scanning Frequency
Fan Noise
Voltage
Power Consumption
Input signal compatibility
Color System
Closed Caption
Projection Lens (inch)
Throw Ratio
Throw Distance (feet)
Zoom / Focus
Up / Down Ratio
Digital Keystone Correction
Digital Zoom
Speaker Output
Weight (lbs)
Dimensions (inch) W,H,D
Replacement Lamp
Replacement Remote
Lamp Life * (hours)
Input
Output
Other Feature
Included Accessories
Optional Accessories
Warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a
general estimate. The brightness of a lamp usually decreases over time and use.
PLC-XD2200
2200 Lm
H:15-100kHz, V:50-100Hz
100-240V AC (auto voltage) ; 50/60 Hz
UXGA/ WXGA/ SXGA+/ SXGA/ XGA/ SVGA/ VGA/
MAC/ 1080i/50,60 / 1035i/ 720p/ 480p/ 480i/ 575p/ 575i
NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N
F 2.00– 2.15 f=0.72" – 0.87"
V +/- 30°(Auto keystone +/- 20°)
D-sub 15 x1 (RGB, Component, S-Video)
PC/Video D-sub 15 x1 (RGB, Monitor out)
RCA x1 (Composite)
Stereo mini jack x 1
Audio
RCA x2 (R/L, mono)
PC/Video D-sub 15 x1 (in common)
Audio Stereo mini jack x 1
RJ-45 (LAN)
Dsub 9pin (RS232C)
Power cord
VGA cable
Lens Cap
Remote control
w.Battery
POA-CA-COMPVGA
POA-CA-VGAS
POA-CACVCL2
Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Back Panel
PLC-XD2600
XGA (1024 x 768)
2600 Lm
500:1
40"-300"
4:3
215W
29 dBA (Eco)
186 W (Eco)
1.62 - 1.92 : 1
4.3' – 38.7'
Manual
6 :1
16x – 1/4x
1W
5.7 lbs
13.1 x 3.4 x 9.7"
# 610 349 7518
# 645 099 3213
6000h (Eco)
Quick reference guide
Owner's Manual(CD-Rom)
PJ-Net Manager(CD-Rom)
PIN code Label
(Component -VGA cable)
(S-Video –VGA cable)
(Soft carry case)
©2010 SANYO
