Sanyo PLC-XD2200 Owner's Manual

Hide thumbs Also See for PLC-XD2200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Manual
Multimedia Projector
MODEL
Owner's Manual
Downloaded From projector-manual.com Sanyo Manuals
PLC-XD2200
PLC-XD2600
Network Supported
Wired LAN
❏
Refer to the Owner's Manuals below for
details about network function.
Network Set-up and Operation
❏

Advertisement

Table of Contents
loading

Related Manuals for Sanyo PLC-XD2200

Summary of Contents for Sanyo PLC-XD2200

  • Page 1 Multimedia Projector Network Supported Wired LAN ❏ PLC-XD2200 Refer to the Owner's Manuals below for MODEL details about network function. Network Set-up and Operation ❏ PLC-XD2600 Owner’s Manual Downloaded From projector-manual.com Sanyo Manuals...

  • Page 2: Features And Design

    You can use the terminal as computer input or monitor output conveniently. (p.49) between presentations. ♦ ♦ Power Management Multilanguage Menu Display The Power management function reduces power Operation menu is available in 20 languages; English, consumption and maintains the lamp life (p.50). German, French, Italian, Spanish, Portuguese, Dutch, Swedish, Finnish, Polish, Hungarian, Romanian, ♦ Closed Caption Russian, Turkish, Kazakh, Vietnamese, Chinese, T his is a printed version of the program sound or other Korean, Japanese and Thai.(p.43) information displayed on the screen. You can turn on the feature and switch the channels. (p.52) Note: ✔ • The On-Screen Menu and figures in this manual may differ slightly from the product. • The contents of this manual are subject to change without notice. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 3: Table Of Contents

    Computer Input . . . . . . . . . . . . . . . . . . . . . .27 Input Source Selection (RGB: Computer 1/ Computer 2) Computer System Selection Auto PC Adjustment Trademarks Each name of corporations or products in this book is either a registered trademark or a trademark of its respective corporation. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 4: To The Owner

    If a chemical symbol is printed beneath the symbol mark, Not for use in a computer room as defined in the Standard this chemical symbol means that the battery or accumulator for the Protection of Electronic Computer/Data Processing contains a heavy metal at a certain concentration. This will be indicated as follows: Hg: mercury, Cd: cadmium, Pb: lead Equipment, ANSI/NFPA 75. In the European Union there are separate collection systems for used electrical and electronic equipment, batteries and accumulators. Please, dispose of them correctly at your local community waste collection/recycling centre. READ AND KEEP THIS OwNER'S MANUAL FOR Please, help us to conserve the environment LATER USE . we live in! Downloaded From projector-manual.com Sanyo Manuals...

  • Page 5: Safety Instructions

    This projector should never be placed operating condition. near or over a radiator or heat register. NOTE FOR CUSTOMERS IN THE US This projector should not be placed in a built-in installation Hg LAMP(S) INSIDE THIS PRODUCT CONTAIN such as a book case unless proper ventilation is provided. MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL Never push objects of any kind into this projector through LAWS. cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the projector. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 6: Air Circulation

    When moving the projector, replace the lens cap and retract adjustable foot to prevent damage to the lens and cabinet. When the projector is not in use for an extended period, put it into a suitable case. Air Intake Vent C AUTION IN CARRyING OR TRANSPORTING THE PROjECTOR – Do not drop or bump the projector, otherwise damages or malfunctions may result. – W hen carrying the projector, use a suitable carrying case. – Do not transport the projector by courier or any other transport service in an unsuitable transport case. This may cause damage to the projector. For information Air Intake Vent about transporting the projector by courier or any other Exhaust Vent transport service, consult your dealer. (Hot air exhaust) – Do not put the projector in a case before the projector is cooled enough. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 7: Compliance

    The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. wARNING: THIS APPARATUS MUST BE EARTHED . THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILy ACCESSIBLE . Downloaded From projector-manual.com Sanyo Manuals...

  • Page 8: Part Names And Functions

    ⑪ LAN Connection Terminal ⑫ Power Cord Connector ⑬ Exhaust Vents CAUTION Hot air is exhausted from the exhaust vent. Do not put heat-sensitive objects near this side. ⑭ Filters ⑮ Adjustable Foot ⑫ ⑬ ⑬ ⑭ ⑧ ✽ Bottom ⑭ ⑮ ✔Note: ⑪ LAN Connection Terminal is for the Network function. Refer to the owner’s manual of “Network Set-up and Operation” . Kensington Security Slot ✽ This slot is for a Kensington lock used to deter theft of the projector. Kensington is a registered trademark of ACCO Brands Corporation. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 9: Rear Terminal

    ③ COMPUTER IN 2 / MONITOR OUT Connect the audio output signal from video equipment connected to ⑤ to this jack. For a mono – Connect analog RGB output signal from a computer to this terminal (p.14). audio signal (a single audio jack), connect it to – This terminal can be used to output the incoming L(MONO) jack. (pp.14-16). analog RGB and Component signal from COMPUTER IN 1 /S-VIDEO IN /COMPONENT IN ⑧ AUDIO IN (PC) terminal to the other monitor (pp.14,16). Connect the audio output signal from computer or video equipment connected to ② and ③ to this ④ AUDIO OUT (VARIABLE) jack. (pp.14-16). Connect an external audio amplifier to this jack (pp.14-16). This terminal outputs sound from AUDIO IN terminal. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 10: Top Control

    (p.24). ⑧ wARNING indicator ③ AUTO SETUP button – L ights red when the projector detects an Execute the setting of Auto setup (includes Input Execute the setting of Auto setup (includes Input abnormal condition. search, Auto PC adj. and Auto Keystone functions) – B links red when the internal temperature of the in the setting menu. (pp.23, 44). (pp.23, 44). projector exceeds the operating range (pp.59, 70). ④ ON/STAND–By button Turn the projector on or off (pp.18-20). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 11: Remote Control

    ⑬ MUTE button Mute the sound. (p.24) ⑭ IMAGE button Select the image mode. (pp.26, 32, 39) ⑮ P-TIMER button Operate the P-timer function. (pp.26, 51) ⑯ LAMP button Select a lamp mode. (pp.25, 53) ⑰ INFO . button Operate the information function. (p.58) ⑱ KEySTONE button Correct keystone distortion. (pp.23, 45) ⑲ SELECT button – Execute the selected item. (p.21) – Expand or compress the image in Digital zoom mode. (p.35) ⑳ COMPONENT button Select the COMPONENT input source. (p.37) ✔Note: To ensure safe operation, please observe the following precautions: – Do not bend, drop or expose the remote control to moisture or heat. – For cleaning, use a soft dry cloth. Do not apply benzene, thinner, spray, or any chemical material. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 12: Remote Control Battery Installation

    Change the remote control code for the projector first before changing that for the remote control. See "Remote control" in the Setting Menu on page 53. Press and hold the MENU and IMAGE buttons for more MENU button than five seconds to switch between the Code 1 and Code 2. The initial code is set to Code 1. IMAGE button Downloaded From projector-manual.com Sanyo Manuals...

  • Page 13: Installation

    6096 x 4572 4 : 3 aspect ratio 4.3'(1.30m) 10.7'(3.26m) 16.1'(4.90m) 21.5'(6.55m) 32.3'(9.84m) Zoom (max) 5.1'(1.55m) 12.9'(3.92m) 19.4'(5.90m) 25.8(7.87m) 38.7'(11.80m) Zoom (min) Adjustable Foot Projection angle can be adjusted up to 10.0 degrees with the adjustable foot. Lift the front of the projector and push the foot lock latch on the projector. Release the foot lock latch to lock the adjustable foot and rotate the adjustable foot to adjust the position and tilt. To retract the adjustable foot, lift the front of the Foot Lock Latch projector and push and undo the foot lock latch. Adjustable Foot Keystone distortion of the projected image can be corrected by menu operation.(see pages 23, 44-45) Downloaded From projector-manual.com Sanyo Manuals...

  • Page 14: Connecting To A Computer

    Monitor Monitor Output Output External Audio Equipment VGA VGA cable cable Audio cable Audio Input (stereo) COMPUTER IN 1 This terminal is switchable. COMPUTER IN 2 / / S-VIDEO IN Set up the terminal as MONITOR OUT /COMPONENT IN either Computer input or Monitor output. (See Page 49.) Audio cable (stereo) AUDIO OUT (stereo) AUDIO IN ✔Note: • Input sound to the AUDIO IN terminal when using the COMPUTER IN 1/ S-VIDEO IN / COMPONENT IN and the COMPUTER IN 2/MONITOR OUT terminals as input. • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. • When the cable is of the longer variety, it is advisable to use the COMPUTER IN 1 /S-VIDEO IN /COMPONENT IN and not the COMPUTER IN 2/MONITOR OUT. Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 15: Connecting To Video Equipment

    • Video Cable • S-Video Cable • S-Video-VGA Cable • Audio Cables (Cables are not supplied with the projector. ) S-Video Output and Audio output Composite Video and Audio Output External Audio Equipment S-Video cable Audio cable Audio (stereo) Video cable Audio Input cable (stereo) S-Video-VGA cable Audio cable VIDEO IN COMPUTER IN 1 AUDIO IN AUDIO IN (stereo) / S-VIDEO IN /COMPONENT IN AUDIO OUT (stereo) Note: ✔ • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. • See page 73 for ordering optional cables. Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 16: Connecting To Component Video And Rgb (Scart) Equipment

    Cables used for connection • Audio Cables • Scart-VGA Cable • Component Cable • Component-VGA Cable (Cables are not supplied with this projector.) Audio Output RGB Scart 21- Component Video Output pin Output (Y, Pb/Cb, Pr/Cr) Component External Audio Equipment cable Audio Input Scart-VGA cable Audio cable Component- Audio cable (stereo) VGA cable (stereo) AUDIO OUT (stereo) COMPUTER IN 1/ S-VIDEO IN / COMPONENT IN AUDIO IN ✔ Note: • When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. • See page 73 for ordering optional cables. Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 17: Connecting The Ac Power Cord

    For Continental Europe For the U .K . For the U .S .A . and Canada Ground Ground To power cord To the AC outlet. connector on your To the AC outlet. To the AC outlet. (200 - 240 V AC) projector. (200 - 240 V AC) (120 V AC) Downloaded From projector-manual.com Sanyo Manuals...

  • Page 18: Basic Operation

    Input signal guidance window the screen (p.45). • When the Input Search function is set to On2, the input No signal signal will be searched automatically (p.44). Current Input setting:RGB • When Off is selected in the Display function, the Video/ PC selection window and the input signal guidance Is signal processed correctly? window are not shown on the screen. (p.45) Is cable connected properly? Downloaded From projector-manual.com Sanyo Manuals...
  • Page 19 After entering the four-digit number, move the pointer to Set. Press the SELECT button so that you can start to operate the projector. If you entered an incorrect PIN code, PIN code and the number (✳✳✳✳) will turn red for a moment. Enter the correct PIN code all over again. what is PIN code? PIN (Personal Identification Number) code is a security code that allows the person who knows it to operate the projector. Setting a PIN code prevents unauthorized use of the projector. A PIN code consists of a four-digit number. Refer to the PIN code lock function in the Setting Menu on pages 54-55 for locking operation of the projector with your PIN code. ✔Note: • If the PIN code number is not entered or wrong PIN code number is entered within three minutes after the PIN code dialog box appeared, the projector will be turned off automatically. • The “1234” is set as the initial PIN code at the factory. CAUTION ON HANDLING PIN CODE If you forget your PIN code, the projector can no longer be started. Take a special care in setting a new PIN code, write down the number in a column on page 76 of this manual and keep it on hand. Should the PIN code be missing or forgotten, consult your dealer or service center. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 20: Turning Off The Projector

    • The projector can be turned on after the POWER indicator turns red. The waiting time to restart will be shortened when the normal power-off processing for fan cooling is completed, compared with the time the AC power cord is immediately unplugged after the power- off. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 21: How To Operate The On-Screen Menu

    Standard Real ► Blackboard(Green) Colorboard Image 1 Image 2 Image 3 Image 4 Point The currently set item is check marked. ► or SELECT The selected item is button highlighted in orange. Dynamic Standard Real Blackboard(Green) Colorboard Image 1 Image 2 Image 3 Image 4 Downloaded From projector-manual.com Sanyo Manuals...

  • Page 22: Menu Bar

    Screen ⑤ For computer source, used to adjust size of the image [ Normal, True, wide, Full, Custom, Custom adj. and Digital zoom +/– ] (pp.34-35). For Video source, used to set size of image [Normal, wide, Custom and Custom adj.] (p.42). Sound ⑥ Used to adjust the volume or mute the sound (p.24). Setting ⑦ Used to set the projector’s operating configurations (pp.43-57). Information ⑧ Display the input source information: Input , H-sync freq ., V-sync freq ., Screen, Language, Lamp status, Lamp counter , Power management, Key lock, PIN code lock and Remote control (p.58). Network ⑨ See the owner’s manual of “Network Set-up and Operation”. Guide ⑩ The key operation is displayed. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 23: Zoom And Focus Adjustment

    POINT ▲▼ buttons is not provided properly with this operation, manual adjustments are required (pp.30-31). KEySTONE button Keystone Correction If a projected picture still has keystone distortion after pressing the AUTO SETUP button on the top control or the AUTO SET button on the remote control, correct the image manually as follows: • The white arrows indicate that there is no Press the KEYSTONE button on the remote control. The correction. Keystone dialog box appears. Use the Point buttons to ▲▼ • A red arrow indicates the direction of correction. correct keystone distortion. The keystone adjustment can be • An arrow disappears at the maximum correction. stored (see page 45). • If you press the KEYSTONE button on the remote control once more while the keystone Reduce the upper width Reduce the lower width dialog box is being displayed, the keystone with the Point button. with the Point button. ▲ ▼ adjustment will be canceled. • The adjustable range is limited depending on the input signal. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 24: Sound Adjustment

    Volume Dialog Box items. of the volume. Use the Point buttons to select the desired submenu ▲▼ item and press the SELECT button to access the selected item. Press the MUTE button to set the Volume Mute function On or Off. The dialog box disappears after 4 seconds. Press the Point button to turn up the volume; press the ► Point button to turn down the volume. ◄ Sound Menu Mute Press the SELECT button to switch the mute function On/ Off. When the sound is turned off, On is displayed. Press the VOLUME +/– buttons again to turn the sound back on. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 25: Remote Control Operation

    Note: ✔ See the next page for the description of other D .ZOOM buttons buttons. Press the D.ZOOM buttons on the remote control to enter to the Digital zoom +/– mode. See page 35 for details. LAMP button Press the LAMP button on the remote control to select the lamp mode for changing the brightness on the screen. High ... Brighter than the Normal mode. Normal .. Normal brightness Eco .... Lower brightness reduces the lamp power consumption and extends the lamp life. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 26: Image Button

    • • • • • ✔Note: When use the MUTE button to release the No Show function, the mute function can not be operated at the same time. P-TIMER button Press the P-TIMER button on the remote control to operate the Count up/Count down function. Refer to p.51 for detail of Setting for the P-timer function. To stop the count time, press the P-TIMER button. P-Timer display To cancel the P-timer function, press and hold the P-TIMER button. SCREEN button IMAGE button P-TIMER button Press the IMAGE button on the remote control to select a NO SHOw button desired image mode of the screen. See pages 32, 39 for IMAGE button details. SCREEN button Select the screen size (See pages 34-35, 42 for details). Note: ✔ See the previous page for the description of other buttons. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 27: Computer Input

    Computer 2 (RGB) Input Menu Menu Operation Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Input and ▲▼ then press the Point or the SELECT button. ► Use the Point buttons to select Computer 1. ▲▼ When Computer 1 is selected, press the Point ► button to access the submenu items. Use the Point ▲ buttons to select the RGB input source and then ▼ press the SELECT button. Computer Computer 1 Component RGB(Scart) S-video ✔Note: When the Input Search function is set to On1 or On2 in the Auto setup function, the input signal will be searched automatically (p.44). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 28: Computer System Selection

    SVGA 1 The projector chooses a proper system provided in the projector and displays it. *Mode 1 and SVGA 1 are examples. Customized Mode Selecting Computer System Manually (1–10) set in the PC adjust Menu PC system can also be selected manually. (pp.30-31). PC System Menu Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Input and ▲▼ then press the Point or the SELECT button. ► Use the Point buttons to select System and then ▲▼ press the Point or the SELECT button. ► Use the Point buttons to select the desired system ▲▼ and then press the SELECT button. Systems in this dialog box can be selected. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 29: Auto Pc Adjustment

    Auto PC adj. Fine sync Total dots 1365 Horizontal ✔Note: Vertical • Fine sync, Total dots, Horizontal and Vertical Current mode Clamp position of some computers cannot be fully adjusted Display area H 1024 Display area V with the Auto PC Adjustment function. When the image Reset Mode free is not provided properly with this operation, manual Store adjustments are required (pp.30-31). • The Auto PC Adjustment cannot be operated when 480i, 575i, 480p, 575p, 720p,105i or 1080i is selected in the PC System Menu (p.28). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 30: Manual Pc Adjustment

    . of the connected computer. Clamp Use the Point buttons to adjust the clamp level. When ◄► the image has dark bars, try this adjustment. Display area H Use the Point buttons to adjust the horizontal area ◄► displayed by this projector. Display area V Use the Point buttons to adjust the vertical area ◄► displayed by this projector. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 31 Display area H 1024 Mode 6 Display area V Display area V Mode 7 Mode 8 Mode 9 Mode 10 Press MENU button Press SELECT button to to close this dialog store the data. box. ✔Note: • Display area (H/V) cannot be selected when 480i, 575i, 480p, 575p, 720p, 105i or 1080i is selected in the PC System Menu (p.28). • When input computer signal to the projector, PC adjust will become available. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 32: Image Mode Selection

    For viewing pictures in a bright room. Standard Normal picture mode preset on the projector. Real Picture mode with improved halftone for graphics. Blackboard (Green) For the image projected on a blackboard. This mode helps enhance the image projected on a blackboard. This is mainly effective on a green colored board, not truly effective on a black colored board. Colorboard Dynamic At the time of simple projection on the colored wall, you Standard can get the close color image to the color image projected Real Blackboard(Green) on a white screen by selecting the similar color to the wall Colorboard color from the preset four colors. Image 1 Image 2 Image 3 Image 1–4 Image 4 For viewing with the user preset image mode in the Image Adjust Menu (see pages 33-34). This Image memory is provided in each computer, component, S-video and video input source. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 33: Image Adjustment

    Use the Point buttons to adjust the gamma value to ◄► obtain a better balance of contrast (from 0 to 15). ✔Note: • When White balance Red, Green or Blue is adjusted, Color temp . will change to User. Reset • When Blackboard(Green) or Colorboard To reset the adjusted data, select Reset and press the is selected in Image select, Color temp . will SELECT button. A confirmation box appears and then select change to Blackboard or Colorboard. yes. All adjustments will return to their previous figures. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 34: Screen Size Adjustment

    ▲▼◄► image. When adjusted, the arrows will turn red. When reached to the correction limits, the arrows will disappear. wide Normal True Provide the image to fit the wide video aspect ratio (16:9) by Full expanding the image width uniformly. This function can be Wide Custom used for providing a squeezed video signal at 16:9. Custom adj. Digital zoom + Digital zoom - Full Provide the full screen image. Custom Provide the last stored aspect screen image. ✔Note: • The Screen Menu, only Normal and Custom can be operated, wide will be disabled and displayed in gray when 720p, 105i, or 1080i is selected in the PC System Menu (p.28). • This projector cannot display any resolution higher than 1920 x 1200. If your computer’s screen resolution is higher than it, reset the resolution to the lower before connecting to the projector. • The image data in other than 1024 x 768 is modified to fit the screen size in initial mode. • True, Full, and Digital zoom +/– are disabled and cannot be displayed when 480i, 575i, 480p or 575p is selected in the PC System Menu (p.28). Downloaded From projector-manual.com Sanyo Manuals...
  • Page 35 To return to the previous screen size, select a screen size • When Custom is selected, the Digital from the Screen Size Adjustment Menu or select an input zoom - function is disabled. source from the Input Source Selection Menu (see page 27) again, or adjust the screen size with the D.ZOOM ▲▼ buttons. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 36: Video Input

    ► the Point buttons to select the S-video and then press ▲▼ the SELECT button. When the input source is coming from video S-video equipment connected to the COMPUTER IN 1/S-VIDEO IN/COMPONENT IN terminal with a S-video-VGA cable, select S-VIDEO. Auto ✔Note: When the Input Search function is set to On1 or On2 in Computer the Auto setup function, the input signal will be searched automatically (p.44). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 37: Input Source Selection (Component, Rgb Scart 21-Pin)

    Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Input and ▲▼ then press the Point or the SELECT button. ► Use the Point buttons to select Computer 1 and ▲▼ then press the Point button. ► Use the Point buttons to select Component or ▲▼ RGB(Scart) and then press the SELECT button. When the input source is coming from video Component equipment connected to the COMPUTER IN 1/S-VIDEO IN/COMPONENT IN terminal with a Component-VGA Cable, select Component. When the input source is coming from video RGB (Scart) equipment connected to the COMPUTER IN 1/S-VIDEO IN/COMPONENT IN terminal with a Scart-VGA Cable, select RGB (Scart). S-video ✔Note: When the Input Search function is set to On1 or On2, the input signal will be searched automatically (p.44). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 38: Video System Selection

    PAL, SECAM, NTSC, NTSC 4 .4, PAL-M, and PAL-N. Component AV System Menu (Component) Auto The projector automatically detects an incoming video signal, and adjusts itself to optimize its performance. COMPONENT VIDEO SIGNAL FORMAT If the projector cannot reproduce proper video image, select a specific component video signal format from among 480i, 575i, 480p, 575p, 720p, 105i, and 1080i. ✔Note: The AV System Menu cannot be selected when selecting RGB (Scart). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 39: Image Mode Selection

    Image 1 and then press the SELECT button . Image 2 Image  Image 4 Dynamic Image select Menu For viewing pictures in a bright room. Standard Normal picture mode preset on the projector. Cinema Picture mode adjusted with fine tone. Blackboard (Green) For the image projected on a blackboard. This mode help enhance the image projected on a blackboard. This is mainly effective on a green colored board, not truly effective on a black colored board. Colorboard At the time of simple projection on the colored wall, you can get the close color image to the color image projected on a white screen by selecting the similar color to the wall color from the preset four colors. Image 1–4 For viewing with the user preset image mode in the Image Adjust Menu (see pages 40-41). This Image memory is provided in each computer, scart, component, S-video and video input source. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 40: Image Adjustment

    ◄ Point button to deepen green tone (from 0 to 63). ► white balance (Blue) Press the Point button to lighten blue tone; press the ◄ Point button to deepen blue tone (from 0 to 63). ► ✔Note: • When the white balance Red, Green or Blue is adjusted, the Color temp. level will change to User. • Tint cannot be selected when the video system is PAL, SECAM, PAL-M or PAL-N (p.38). • When Blackboard(Green) or Colorboard is selected in Image select, Color temp . will change to Blackboard or Colorboard. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 41 Store Menu Reset To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select yes. All adjustments will return to their previous figures. Store To store the adjusted data, select Store and press the Point or the SELECT button. Use the Point buttons to ► ▲▼ select one from Image 1 to 4 and press the SELECT button. A confirmation box appears and then select yes. Stored data can be called up by selecting an Image (1–4) in the Image Mode Selection on page 39. A confirmation box appears and then select yes. ✔Note: Noise reduction and Progressive cannot be selected when 480p, 575p, 720p, 105i or 1080i is selected (p.38). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 42: Screen Size Adjustment

    Position H/V .. Adjust the Horizontal/Vertical screen position. Common ... Save the adjusted scale or position to all the inputs. Press the SELECT button at Common to display a confirmation box. To save the scale or position, press the SELECT button at yes. When Custom is selected, the saved scale or position is used. Reset .... Reset the all adjusted values. Press the SELECT button at Reset to display ✔Note: a confirmation box. To reset, press the • When no signal is detected, Normal is set SELECT button at yes. automatically. • The adjustable range for Scale H/V and Position H/V is limited depending on the input signal. • wide cannot be operated when 720p, 105i or 1080i is selected in the AV System Menu (p.38). Downloaded From projector-manual.com Sanyo Manuals...

  • Page 43: Setting

    ▲▼ and press the Point or the SELECT button to access ► the submenu items. Use the Point buttons to select the desired item ▲▼ and then press the Point or the SELECT button to ► access the selected item. Use the Point buttons select the desired item and ▲▼ then press the SELECT button. Language Language The language used in the On-Screen Menu is available in English, German, French, Italian, Spanish, Portuguese, Dutch, Swedish, Finnish, Polish, Hungarian, Romanian, Russian,Turkish, Kazakh, Vietnamese, Chinese, Korean, japanese and Thai. Menu position This function is used to change the position of the On-Screen Menu. Select Menu position and press the SELECT button. The Menu position changes each time you press SELECT button as follows. the top left → the top right → the center → the bottom left → the bottom right → the top left →..Downloaded From projector-manual.com Sanyo Manuals...
  • Page 44 • Perfect correction of the image distortion cannot ✔Note: be ensured with the Auto setup function. If the • While Input search is set to On1 or On2, the status of Input distortion is not corrected properly by pressing the and Lamp are displayed every time the signal is switched. AUTO SETUP or the AUTO SET button, adjust • Only the last selected input source can be detected. manually by pressing the KEYSTONE button on • During Input search is in progress, If the MENU button or the the remote control or selecting Keystone in the Setting menu (pp.23, 45). ON/STAND-BY button is pressed, Input search will stop. If • Fine sync, Total dots, Horizontal and Vertical the COMPUTER 1/2 button or VIDEO or COMPONENT or S- position of some computers cannot be fully VIDEO button is pressed, Input search will stop and go back adjusted with the Auto PC Adjustment function. to the button's input signal. When the image is not provided properly with • Input search, Auto PC adj . and Auto Keystone cannot be this operation, manual adjustments are required set Off at the same time. (pp.30-31). Downloaded From projector-manual.com Sanyo Manuals...
  • Page 45 Countdown Off.. Show the input image instead of the countdown when turning on the projector. Use this function when you want to project the image as early as possible even when the lamp is not bright enough. Off ...... Hide the On-Screen Displays except; ● On-Screen Menu. ● Power off? (p.20) ● P-Timer display. (p.26) ● No signal for Power management (p.50) ● Please wait . . . ● Arrows for the True function in the Screen Menu. (p.34) Downloaded From projector-manual.com Sanyo Manuals...
  • Page 46 Logo select This function allows you to customize the screen logo with Logo select, capture, Logo PIN code lock and Logo PIN English code change functions. Store Blue ✔Note: ► When On is selected in the Logo PIN code lock function, Logo select and Capture functions cannot be selected. Computer 2 Direct on Network Logo select This function decides on the starting-up display from among following options. User .. Show the image you captured. Default Default .. Show the factory-set logo. Off ... Show the countdown display only. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 47 • When there is no captured image or it is interrupted while capturing an image, User cannot be selected, you can only switch between Default and Off. Logo PIN code lock Logo PIN code lock This function prevents an unauthorized person from changing the screen logo. Off ... The screen logo can be changed freely from the Logo Menu (p.46). On ... The screen logo cannot be changed without a Logo PIN code. If you want to change the Logo PIN code lock setting, press the SELECT button and the Logo PIN code dialog box appears. Enter a Logo PIN code by following the steps below. The initial Logo PIN code is set to “4321” at the factory. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 48 THE LOGO PIN CODE NO . MEMO ON PAGE 76 , AND KEEP IT SECURELy . SHOULD THE LOGO PIN CODE BE LOST OR FORGOTTEN, THE LOGO PIN CODE SETTING CAN NO LONGER BE CHANGED . Exit ---- Downloaded From projector-manual.com Sanyo Manuals...
  • Page 49 (See page 9) Select Computer 2 or Monitor Out with the Point buttons. ▲▼ Computer 2 . . computer input Monitor Out . . monitor out Terminal function is not available when selecting Computer 2 to the input source. Change the input source to the others (Computer 1, and so on) so that the Terminal function will be available. (p.25, 36, 37) Downloaded From projector-manual.com Sanyo Manuals...

  • Page 50: Power Management

    Direct on down, the power will be turned off. Network Off .... Power management function is off. Timer .... If the input signal is interrupted and no button is pressed for more than 30 seconds, the timer display with No signal appears. It starts the countdown until the lamp is turned off. Use the Point buttons to set the ▲▼ Timer(1~30min). ✔Note: Factory default is Ready: 5 min. Direct on When this function is set to On, the projector will be automatically turned on just by connecting the AC power cord to a wall outlet. ✔Note: • Be sure to turn off the projector properly (see “Turning Off the Projector” on page 20). If the projector is turned off in the incorrect sequence, the Direct on function will not work properly. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 51 Start and the indication changes into Stop. To stop Count up or Count down, press the SELECT button at Stop on the screen menu,then the indication changes into Restart. Press the SELECT button at Restart to resume Count up or Count down. Reset .... Reset the P-timer values. Press the SELECT button at Reset to return to the following value; Stop or Cancel the P-timer via Remote Control Count up ... "000:00" To stop the P-timer, press the P-TIMER button. Count down ... Timer that you set To cancel the P-timer, press and hold the P-TIMER Exit ....... To exit the P-timer operation. button for a few seconds. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 52 Closed Caption is a printed version of the program sound or other information displayed on the screen. If the input signal contains closed captions, you can turn on the feature and switch the channels. Press the Point buttons to select ▲▼ Off, CC1, CC2, CC or CC4. If the closed caption is not clear, you can change the text from Color to white. ✔Note: The Closed Caption is available only under the situation below. . • When the input signal is Component (for adjustment only), Video or S-video, and the system is set to Auto, NTSC or 480i, the Closed caption is available. Color • If the system is set to Auto, and choose NTSC or 480i as the input signal, the Closed caption will be available. • Closed Caption will be unavailable when under other setting conditions. • The Closed caption is unavailable when On-Screen menu and P-timer are displayed. • The item of Closed Caption is displayed in gray while it is not available. Color Press the Point ▲▼ buttons to select Off, CC1, CC2, CC or CC4, and then press the SELECT button. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 53 Remote control (Code 2). This switching function prevents remote control interference when operating several projectors or video equipment at the same time. When operating the projector in Code 2, both the projector and the remote control must be switched to Code 2. To change the code for the projector: Select either Code 1 or Code 2 in this Setting Menu. To change the code for the remote control: Press and hold both the MENU and IMAGE buttons together for 5 seconds or more. After changing the code, make sure the remote control operates properly. ✔Note: • When different codes are set on the projector and on the remote control, any operation cannot be made. In that case, switch the code on the remote control to fit the code on the projector. • If the batteries are removed from the remote control for a long period of time, the remote control code will be reset. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 54 .. Lock the operation of the remote control. To unlock, use the top control. If the top control accidentally becomes locked and you do not have the remote control nearby or there is something wrong with your remote control, contact the dealer where you purchased the projector or the service center. PIN code lock This function prevents the projector from being operated by unauthorized persons and provides the following setting options for security. Off ... Unlocked. On1 .. Enter the PIN code every time turning on the projector. On2 .. Enter the PIN code to operate the projector once the power cord is disconnected; as long as the AC power cord is connected, PIN code lock the projector can be operated without a PIN code. Whenever you change the PIN code lock setting or the PIN code (the four-digit number), you are required to enter the PIN code. The “1234” is set as the initial PIN code at the factory. If you want to change the PIN code lock setting, press the SELECT button and the PIN code dialog box appears. When the projector is locked with the PIN code, the Security icon appears on the guide. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 55 DOwN THE NEw PIN CODE IN COLUMN OF THE PIN CODE NO . MEMO ON PAGE 76, AND KEEP IT SECURELy . IF yOU FORGET yOUR PIN CODE, THE PROjECTOR CAN NO LONGER BE STARTED . Downloaded From projector-manual.com Sanyo Manuals...
  • Page 56 Be sure to reset the Lamp replacement counter after the lamp is replaced. (p. 62) Press the Point buttons to choose the Lamp counter ▲▼ function and then press the Point SELECT button to ► or the access the submenu items. Lamp counter....This item shows the total accumulated time of the lamp usage. Lamp counter reset..Press the SELECT button to choose Lamp counter reset . Select yes in the confirmation box if you want to reset the lamp counter, and then choose yes in the second confirmation box to reset lamp counter. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 57: Filter Counter

    ▲▼ 100H/ 200H/ 00H) depending on the use environment. Filter warning icon appears on the screen at a set time. ✔Note: This icon also appears at turning on. ✔Note: The Filter warning icon (Fig.1) will not appear when the Display function is set to Off (p.45), during Freeze(p.25), Factory default or No show (p.26). warning log This function records anomalous operations while the projector is in operation and use it when diagnosing faults. Up to 10 warning logs are displayed with the latest warning message at the top of the list, followed by previous warning messages in chronological order. ✔Note: When the Factory default function is executed, all the warning log records will be deleted. Factory default This function returns all setting values except for the User logo, PIN code lock, Logo PIN code lock, Lamp counter and Filter counter to the factory default settings. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 58: Information

    V-sync freq . The vertical frequency of the input signal is displayed in Hz, or - - - - Hz when no signal. Numbers of Hz doubles when during Interlace. Screen The selected screen size is displayed. Language The selected language is displayed. Lamp status The selected lamp mode is displayed. Lamp counter The cumulative lamp operating time is displayed. Power management Off, Ready or Shut down, and Timer are displayed. Key lock The selected Key lock icon is displayed. PIN code lock Off or On1 or On2 is displayed. Remote control The selected remote code is displayed. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 59: Maintenance And Cleaning

    – Has the projector been installed near an Air-Conditioning/ Heating Duct or Vent? Move the installation of the projector away from the duct or vent. – Is the filter clean? Clean the filter periodically. The projector is shut down and the wARNING Top Control indicator lights red . When the projector detects an abnormal condition, it is automatically shut down to protect the inside of the projector and the WARNING indicator lights red. In this case, unplug the AC power cord and reconnect it, and then turn the projector on once again to verify operation. If the projector WARNING lights cannot be turned on and the WARNING indicator still lights red, unplug the AC power cord and contact the service center. CAUTION DO NOT LEAVE THE PROJECTOR WITH THE AC POWER CORD CONNECTED UNDER AN ABNORMAL CONDITION. IT MAY RESULT IN FIRE OR ELECTRIC SHOCK. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 60: Cleaning The Filters

    Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Setting and Filter counter ▲▼ then press the Point button. Reset? appears. ► or the SELECT Use the Point buttons to select Filter counter and ▲▼ then press the Point SELECT button. Use the ► or the buttons to select Filter counter reset and Point ▲▼ Select yes, then then press the SELECT button. Filter counter Reset? another confirmation appears. Select yes to continue. box appears. Another confirmation dialog box appears, select yes to Select yes again reset the Filter counter. to reset the Filter counter. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 61: Attaching The Lens Cap

    CAUTION Do not use any flammable solvents or air sprays on the projector and in its vicinity. The explosion or fire hazard may occur even after the AC power cord is unplugged because the temperature inside the projector is extremely high due to the lamps. In addition, there is a risk that the internal parts may be damaged not only by the flammable air spray but also by the cold air. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 62: Lamp Replacement

    Remove the lamp cover gently. Small pieces of glass may fall out when the lamp cover is opened. If pieces of glass get into your eyes or mouth, seek medical advice immediately. Lamp Cover Follow these steps to replace the lamp. Unplug the AC power cord. Let the projector cool for at least 45 minutes. Loosen the screw and open the lamp cover. Screw Loosen the three (3) screws that secure the lamp. Lift Screw the lamp out of the projector by using the handles. Handles Screw Replace the lamp with a new one and secure the three (3) screws. Make sure that the lamp is set properly. Lamp Close the lamp cover and secure the screw. Connect the AC power cord to the projector and turn on the projector. Reset the lamp replacement counter . See "Lamp Counter" on page 56. Screw Downloaded From projector-manual.com Sanyo Manuals...

  • Page 63: Lamp Handling Precautions

    No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service. Inappropriate attempts to service the unit by anyone, especially those who are not appropriately trained to do so, may result in an accident or injury caused by pieces of broken glass. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 64: Appendix

    Image is out of focus . – Adjust focus of the projector. See page 23. – Provide proper distance between the projector and the projection screen. See page 13. – Check the projection lens to see if it needs cleaning. See page 61. – Moving the projector from a cool to warm place may result in moisture condensation on the projection lens. In such cases, leave the projector off and wait until condensation evaporates. Image is Left/Right reversed . – Check the Ceiling/Rear function. See page 49. Image is Top/Bottom reversed . – Check the Ceiling function. See page 49. Picture is not bright enough . – Check if the Contrast or Brightness is adjusted properly. See pages 33, 40. – Check if Image mode is selected properly. See pages 32, 39. – Check the lamp control function. See pages 25, 53. – Check the LAMP REPLACE indicator. If it lights, the end of lamp life is approaching. Replace the lamp with a new one promptly. See page 62. Downloaded From projector-manual.com Sanyo Manuals...
  • Page 65 Capture function does not work . – Check the connection and the input signal to see if there is signal. Auto setup does not work properly . – Make sure Off is not selected at any function of Auto setup. See page 44. – Make sure On is not selected at the Ceiling function. See page 49. Auto keystone function does not – Make sure the Auto keystone function is not set to Manual. Press work even when the projector is the AUTO SETUP button on the top control. See pages 23, 44. tipped . Downloaded From projector-manual.com Sanyo Manuals...
  • Page 66 The exclamation mark appears – Your operation is invalid. Operate correctly. on the screen . Top control does not work . – The top control is not available if the top control is locked at Key lock under Security of SETTING section. See page 54. Unable to unlock the Logo PIN – Contact the dealer where you purchased the projector or the service code lock, Security key lock center. or Security PIN code lock . Downloaded From projector-manual.com Sanyo Manuals...
  • Page 67 High voltages are used to operate this projector . Do not attempt to open the cabinet . If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Specify the model number and explain about the problem. We will advise you how to obtain service. This symbol on the nameplate The CE Mark is a Directive conformity means the product is Listed mark of the European Community (EC). by Underwriters Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety standards against Pixelworks ICs used. risk of fire, casualty and electrical hazards. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 68: Menu Tree

    Mode 7 Image 2 Mode 8 Image 3 Mode 9 Image 4 Screen Normal Mode 10 True Store Mode 1 Wide Mode 2 Full Mode 3 Custom Mode 4 Custom adj. Scale Mode 5 H&V On/Off Mode 6 Position Mode 7 Common Yes/No Reset Mode 8 Yes/No Mode 9 Digital zoom + Mode 10 Digital zoom – Downloaded From projector-manual.com Sanyo Manuals...
  • Page 69 L1/L2 Image 3 Fan control Off/On1/On2 Image 4 Video delay control Off/On Lamp counter Lamp counter Screen Normal Lamp counter reset Yes/No Wide Filter counter Filter counter Custom Timer Off/100H/200H/300H Custom adj. Scale Filter counter reset Yes/No H&V On/Off Warning log Position Factory default Yes/No Common Yes/No Reset Yes/No Information Input Source Information Display Downloaded From projector-manual.com Sanyo Manuals...

  • Page 70: Indicators And Projector Condition

    The projector is in stand-by mode. Press the ON/STAND-BY button ✽ to turn on the projector. The projector is operating normally. ✽ The projector is preparing for stand-by or the projection lamp is being cooled down. The projector cannot be turned on until cooling ✽ is completed and the POWER indicator stops blinking. The projector is in the Power management mode. ✽ The temperature inside the projector is abnormally high. The projector cannot be turned on. When the projector is cooled down enough and the temperature returns to normal, the POWER ✽ indicator stops blinking and the projector can be turned on. (The WARNING indicator keeps blinking.) The projector has been cooled down enough and the temperature returns to normal. When turning on the projector, the WARNING ✽ indicator stops blinking. The projector detects an abnormal condition and cannot be turned on. Unplug the AC power cord and plug it again to turn on the projector. If the projector is turned off again, unplug the AC power ✽ cord and contact the dealer or the service center for service and checkup. Do not leave the projector on. It may cause an electric shock or a fire hazard. • • • green. • • • red • • • off • • • blinks green. • • • blinks red. When the projection lamp reaches its end of life, the LAMP REPLACE indicator lights yellow. When this indicator lights yellow, replace the projection lamp with a new one promptly. (pp. 56, 62) Downloaded From projector-manual.com Sanyo Manuals...

  • Page 71: Compatible Computer Specifications

    62.50 58.60 720p 1280 x 720 45.00 60.00 SXGA 3 1280 x 1024 63.90 60.00 720p 1280 x 720 37.50 50.00 60.00 1035i 1920 x 1035 33.75 SXGA 4 1280 x 1024 63.34 59.98 (Interlace) 1080i 60.00 1920 x 1080 33.75 (Interlace) 1080i 50.00 1920 x 1080 28.125 (Interlace) ✔Note: The specifications are subject to change without notice. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 72: Technical Specifications

    16.4�� (5 m)��30˚ 16.4�� (5 m)��30˚ Dimensions Dimensions 2.0" (W) x 0.7" (H) x 4.3" (D) (52 mm x 18 mm x 110 mm) 2.0" (W) x 0.7" (H) x 4.3" (D) (52 mm x 18 mm x 110 mm) Net Weight Net Weight 2.37 oz (67 g) (including batteries) 2.37 oz (67 g) (including batteries) Downloaded From projector-manual.com Sanyo Manuals...

  • Page 73: Optional Parts

    Lens Cap with String PIN Code Label Ferrite core The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are ● effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels. Optional Parts The parts listed below are optionally available. When ordering those parts, specify the item name and Model No. to the sales dealer. Model No. COMPONENT-VGA Cable : POA-CA-COMPVGA S-video-VGA Cable : POA-CA-VGAS SCART-VGA Cable : POA-CA-SCART VGA-Cable (10 m) : KA-MC-DB10 Soft Carrying Case : POA-CAC-VCL2 Downloaded From projector-manual.com Sanyo Manuals...

  • Page 74: Pj Link Notice

    Appendix Pj Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see the owner’s manual of “Network Set-up and Operation.” Projector Input PJLink Input Parameter RGB 2 Computer 1 Component RGB 3 RGB (Scart) RGB 5 S-video RGB 4 RGB 1 Computer 2 Video Video VIDEO 2 PJLink is a registered trademark of JBMIA and pending trademark in some countries. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 75: Configurations Of Terminals

    Ground (Vert.sync.) Blue Input/Output ----- ----- ----- Ground (Horiz.sync.) Horiz. sync. Input/Output Ground (Red) Vert. sync. Ground (Green) ----- Ground (Blue) CONTROL PORT CONNECTOR (D-sub 9 pin) Serial ----- R X D T X D ----- ----- ----- LAN TERMINAL TX + ----- TX – RX – RX + ----- ----- ----- Downloaded From projector-manual.com Sanyo Manuals...

  • Page 76: Pin Code Number Memo

    Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service center. PIN Code Lock No . Factory default set No: 1 2 3 4* Logo PIN Code Lock No . Factory default set No: 4 3 2 1* *Should the four-digit number be changed, the factory set number will be invalid. While the projector is locked with the PIN code. Put the label below (supplied) on in a prominent place of the projector's body while it is locked with a PIN code. Downloaded From projector-manual.com Sanyo Manuals...

  • Page 77: Dimensions

    Appendix Dimensions Unit: mm(inch) Screw Holes for Ceiling Mount Screw: M4 Depth: 10.0(0.39) 333.5 217.0 (13.13) (8.54) 99.5 10.0 50.0 (3.92) (0.39) (1.97) 51.0 (2.01) Downloaded From projector-manual.com Sanyo Manuals...
  • Page 78 KR8AC Downloaded From projector-manual.com Sanyo Manuals...
