LG 32LD550 Owner's Manual
  1. Manuals
  2. Brands
  3. LG Manuals
  4. LCD TV
  5. 32LD550
  6. Owner's manual
LG 32LD550 Owner's Manual

LG 32LD550 Owner's Manual

Hide thumbs Also See for 32LD550:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
iiil kiill _i_
/ LCD -I-V
Please
read this
your
set and
retain
it for future
reference.
manual
carefully
before
operating
LCD TV MODELS
LED LCD TV MODELS
32LD550
47LD650
32LE5400
42LE5500
47LE8500
42LD550
55LD650
42LE5400
47LE5500
55LE8500
46LD550
47LE5400
55LE5500
42LX6500
52LD550
55LE5400
42LE7500
47LX6500
6QLD55Q
42LE5350
47LE750Q
55LX65QQ
47LE535Q
55LE75QQ
PLASMA
TV MODELS
50PK750
60PK750
P/NO
: SAC34134203
(IO07-REV08)
www.Jg.com

Advertisement

Table of Contents
loading

Related Manuals for LG 32LD550

Summary of Contents for LG 32LD550

  • Page 1 iiil kiill _i_ / LCD -I-V Please read this manual carefully before operating your set and retain it for future reference. LCD TV MODELS LED LCD TV MODELS PLASMA TV MODELS 32LD550 47LD650 32LE5400 42LE5500 47LE8500 50PK750 42LD550 55LD650 42LE5400 47LE5500 55LE8500 60PK750...
  • Page 2 MY MEDIA ENTRY MODE The My Media menu will open automatically when you insert a USB drive. My Media can also be accessed by choosing My Media in the user menu. After choosing the desired type of media, choose a device to open files from.
  • Page 3 CONNECTION METHOD USB Connection 1 Connect the USB device to the USB IN jack on the side of TV. -< _>...
  • Page 4 MY MEDIA DLNA About DLNA This TV can display and play many types of movie, photo and music files from your DLNA server has been certified by DLNA for photos. The Digital Living Network Alliance (DLNA) is a cross-industry organization of consumer electronics, computing...
  • Page 5 Installing Nero MediaHome 4 Essentials Nero MediaHome 4 Essentials is easy to use DLNA server software for Windows. Requirement PC system before you install Nero MediaHome 4 Essentials _ Windows ® XP (Service Pack 2 or higher), Windows Vista ® (no Service Pack required), Windows ®...
  • Page 6 MY MEDIA Sharing files and folders After installing Nero MediaHome, you must add folders you wish to share. Double-click the Nero MediaHome 4 Essentials icon on the desktop. Click Network icon on the left and define your network name in the Network name field.

  • Page 7: Select My Media

    Playing back shared contents You can display and play movie, photo and music content stored on your computer or other DLNA media servers. 1 Start the server on your computer or other device that connected on your home network. Select MY MEDIA.
  • Page 8 MY MEDIA MOVIE LIST It displays all of the video files it recognizes. The On-Screen Display on your model may be slightly different. Supported movie file Resolution: under 1920 pixel (width) x 1080 pixel (height) Frame Rate: under 30 frame/sec (1920x1080), under 60 frame/sec...
  • Page 9 Supported Video Formats Only streams compliant to SMPTE 421M VC-1 standard are supported. Global motion compen- sation or quarterpel motion estimation does not supported. Streams using this syntax are not supported. .-< Global motion compen- sation or quarterpel motion estimation does not supported.

  • Page 10: Focused On

    MY MEDIA Screen Components Select Movie List, Select MY MEDIA. Moves to upper level folder @ Current page/Total pages @ Corresponding buttons on the remote control @ Contents under the folder -< focused @ Current page/total pages contents }> Abnormal files are displayed using...
  • Page 11 Movie Selection Select the target folder or drive. Select the desired movie title. Play the movie file. _ Use the CH (A V) button to navigate -< in the movie page. _> Mark Mode Select the target folder drive. Select the desired movie title.
  • Page 12 MY MEDIA Playing the Movie For 42/47/55LX6500 ...< Show the Option menu. }> Select the desired menu option. Using remote control Return to the previous menu. Select the required speed: x2, x4, x8, x16, x32 (backward/forward). Pauses the media player. If no buttons are pressed on the remote...
  • Page 13 Set Video Play Menu Options m Picture Size: Selects your desired picture format for videos. Full Mode: Files played in full =< screen mode regardless of the aspect ratio of video. Original Mode: Files played > according aspect ratio video. _ Audio Language: Changes...
  • Page 14 MY MEDIA * Image shown may differ from your TV. Set Video Menu Options For Plasma For LED LCD TV/LCD TV Picture Mode " Contrast *Tint i Diiamii c0nirai t i,,ii,ihaniir "c0i0r TemP! 0 -< T[uMotiorl _> Make appropriate adjustments. Then, select Previous.

  • Page 15: Displayed Using

    PHOTO LIST The On-Screen Display on your model may be slightly different. Supported photo file: *JPG _ Baseline: 64 pixel (width) x 64 pixel (height) to 15360 pixel (width) x 8640 pixel (height) Progressive: 64 pixel (width) x 64 pixel (height) to 1920 pixel...
  • Page 16 MY MEDIA Photo Selection Select the target folder or drive. Select the desired pho- tos. Photo file is displayed. _ Use the CH (A v) button to navigate in the photo page. -< _> Mark Mode Select the target folder or drive.
  • Page 17 Full Screen Menu More operations are available in full screen mode. -< _> aspect ratio of a photo change size of the photo displayed screen in full size. Select the target folder or drive. _ Use the CH (^ v) button to navigate in the photo...
  • Page 18 MY MEDIA Select the Slideshow, BGM, t4 (Rotate), / +_+, e_A2J (Energy Saving), Option, or Hide. Use < > button to select the previ- ous or next photo. -.< _. Slideshow: Selected photos are displayed during the slide show. If no photo is selected, all photos in the current...
  • Page 19 Using the Photo List Function ...< For 42/47/55LX6500 1,1-,1 Show the Option menu. Select the desired menu option. Set Photo View Menu Options si,disiiii Select Slide Speed or BGM. Make appropriate adjustments.
  • Page 20 MY MEDIA * Image shown may differ from your TV. Set Video Menu Options For Plasma For LED LCD TV/LCD TV Picture Mode ' Backlight - Contrast , Br ghtness ....* Brightness • Color - Dynamic Contrast -< " Edge Enhancer - Noise Reduction _>...

  • Page 21: Table Of Contents

    MUSIC LIST This TV cannot play back copy-protected files. The On-Screen Display on your model may be slightly different. Supported Music File: _.MP3 Bit rate range: 32 Kbps - 320 Kbps • Sampling rate MPEG1 Layer3:32 kHz, 44.1 kHz, 48 kHz .
  • Page 22 MY MEDIA Music Selection Select the target folder or drive. Select the desired music file. Music files are played. _ Use the CH (A v) button to navigate in the music page. -< > Mark Mode Select the target folder drive.

  • Page 23: Press The ........................ To (Refer To

    Using the Music List Function -< _> Show the Option menu. Select Set Audio Play. or Set Audio.. Using remote control Stop playback. Return to normal playback. Paused playback. Select the previous or next song. Play with Photo: Start playing the selected songs and then...
  • Page 24 MY MEDIA Set Audio Play Menu Options Select Repeat or Random. Make appropriate adjustments. _> Set Audio Menu Options Select Sound Mode, Auto Volume, Clear Voice II or Balance. Make appropriate adjustments.
  • Page 25 _ If you don't press any buttons for a while, the play information will float across the screen. This prevents screen pixel damage clue to a fixed image remaining on the screen for a extended period time. -< _>...
  • Page 26 MY MEDIA DIVX REGISTRATION CODE Using the registration number, movies can be rented or purchased at www.divx.com/vod. Only DivX files matched with the registration code of the purchased TV are playable. -< _> Select MY MEDIA. Select DivX Option. Select DivX Reg.
  • Page 27 DEACTIVATION The purpose of deactivation is to allow deactivation of devices for users who have activated all the available devices through the web server and are blocked from activating more devices. DivX VOD allows the consumer to activate up to 6 devices under one account.
  • Page 28 NETWORK LEGAL NOTICE SelectNETWORK. Check Legal notice. Select Legal Notice. Return to TV viewing.
  • Page 29 TV. _ To view the owner's manual that provided Content Provider, visit website http://www.lg.com. _ To activation method Yahoo!, Nefflix, or Vudu, click Yahoo!, Netflix, Vudu in the CD manual (For USA). Select...
  • Page 30 NETCAST YOUTUBE YouTube is a video sharing website where users can upload, view, and share video clips. Screen Components YouTube menu Videos list Set the option menu. Return to Netcast menu. _> Return to TV viewing.
  • Page 31 YouTube menu Home: You can watch the popular video in real time. Featured: The featured videos list will be displayed. Popular: The best rated videos list from YouTube server will be displayed. Most Viewed: The most viewed videos list will be displayed. Search: The keypad/keyboard menu...

  • Page 32: To Tv Viewing

    NETCAST PICASA Picasa is a photo organizing or sharing website where users can upload, view, and share photos. Screen Components Picasa menu Photo list Navigate the desired photos. iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiil _> The selected photo file is displayed. Return to Netcast menu. Return to TV viewing.
  • Page 33 Picasa menu Home: The featured photos list will be displayed. Friends: You can register users with the pictures you want as friends You can add up to 10 friends Search: The keypad/keyboard menu will be displayed. My Photos: You can view the pictures uploaded to the Web.
  • Page 34 PICTURE CONTROL PICTURE SIZE (ASPECT RATIO) CONTROL This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV. You can select a different aspect ratio depending on input source (analog broadcasting, digital broad- casting,...
  • Page 35 16:9 linear Adjust picture horizontally, in a Choose 4:3 when you want to view a picture proportion to fill the entire screen. with an original 4:3 aspect ratio. Jusf Scan Zoom Normally edges video signals Choose Zoom when you want to view cropped 1-2%.
  • Page 36 PICTURE CONTROL PICTURE WIZARD This feature lets you adjust picture quality of the original image. Use this to calibrate screen quality by adjusting the Black and White Level etc. You can calibrate the screen quality by easily follow- ing each step.
  • Page 37 For LED LCD TV/LCD Adjust Backlight. Adjust Color. i.e) Adjust Horizontal Sharpness. Select input source apply the settings. Save. Finish the Picture Wizard. Adjust Vertical Sharpness. _ If you stop Picture Wizard before final step, the changes will not be saved the TV.

  • Page 38: Energy Saving

    PICTURE CONTROL ENERGY SAVING It reduces the TV's power consumption. The default factory setting is adjusted to the comfortable level to be viewed at home. You can increase the brightness of your screen by adjusting the Energy Saving level or by adjusting Picture Mode.
  • Page 39 PRESET PICTURE SETTINGS (PICTURE MODE) There are factory presets for picture settings available in the user menus. You can use a preset, change each setting manually, or use the Intelligent Sensor. JE_J_ @_r_'_i i jjj1 _XD@ _Ziii iii] ii] Other models Plasma TV 47/55LE85©©...
  • Page 40 PICTURE CONTROL MANUAL PICTURE ADJUSTMENT - USER MODE Adjust the picture appearance to suit your preference and viewing situations. _ Backlight (For LED LCD TV/LCD TV): Select PICTURE. This function adjusts brightness backlight behind screen. Adjusting backlight Select Picture MOdel recommended when setting...
  • Page 41 PICTURE IMPROVEMENT TECHNOLOGY (ADVANCED CONTROL) Advanced Control allows you to adjust some of the advanced features of your LG display. To reset to the factory default after making adjustments to each input source, execute the Picture Reset function for each Picture Mode.
  • Page 42 PICTURE CONTROL EXPERT PICTURE CONTROL Expert1 and _ Expert2 provide even more advanced picture settings for users. Typical used by professionals for calibrating the TV. LED LCD TV, Plasma LC D TV Select PICTURE. Select Picture MOdel Select Expert1 or _ Expert2.
  • Page 43 Blu-ray movies are filmed at 24 frames per second (fps). With LG Real Cinema, every frame is consistently processed 5 times in 1/24 a second producing 120 fps with TruMotion or 2 times in 1/24...
  • Page 44 PICTURE CONTROL _."_ S how clearer and distinctive yet natural edges in the video. _:_ This produces richer colors. _ This feature represents rich color as much as conventional video signal. _'_This function is enabled in "Picture mode - Cinema Cinema Bright Room,...
  • Page 45 PICTURE RESET Settings of the selected picture modes return to the default factory settings. Select PICTURE. Select Picture Reset. Select Yes. Initialize the adjusted value. Return to TV viewing.
  • Page 46 P(CTURE CONTROL TRUMOTION - For LED LCD TV, LCD TV Advance video technology that provides clearer, smoother images, even during fast action scenes cre- ating a more stable structure for a crisper picture. [] Off: Turn off TruMotion operation. Select PICTURE.
  • Page 47 LED LOCAL DIMMING - For 42/47/55LE5500, 42/47/55LE7500, 47/55LE8500, 42/47/55LX6500 After analyzing the signal of the input video by areas of the screen, if adjusts the bacMight to improve the contrast ratio. This feature is disabled in "Picture Mode-Game". Select PICTURE. Select LED Local Dimming.
  • Page 48 PICTURE CONTROL POWER INDICATOR - For LED LCD TV, LCD TV Adjust the power/standby indicator light on the front of the TV. _ Standby Light: Determines whether Select OPTION. to set the indicator light on the front of the TV to On or Off in standby mode.
  • Page 49 IMAGE STICKING MINIMIZATION (ISM) METHOD-For Plasma TV A frozen still picture displayed on the screen for prolonged periods can result in a ghost image. can use Orbiter to help prevent image sticking. The other two functions are for removing a ghost image.
  • Page 50 SOUND & LANGUAGE CONTROL AUTO VOLUME Auto Volume makes sure that the volume level remains consistent whether you are watching a com- mercial or a regular TV program. Because each broadcasting station has its own signal conditions, volume adjustment may be needed every time the channel...
  • Page 51 CLEAR VOICE II By differentiating the human sound range from others, it improves the sound quality of voices. Select AUDIO. Select Clear Voice Select On or Off. Adjustment for Clear Voice Level with selecting _> Select Level. _> Make appropriate adjustments.
  • Page 52 SOUND & LANGUAGE CONTROL BALANCE Adjust the left/right sound of speaker to suit your taste and room situations. Select AUDIO. Select Balance. Make appropriate adjustments. Return to the previous menu. _> Return to TV viewing. _>...
  • Page 53 PRESET SOUND SETTINGS (SOUND MODE) Sound Mode lets you enjoy the best sound without any special adjustment using factory presets. _ Standard, Music, Cinema, Sport, Select AUDIO. Game are preset for optimum sound quality at the factory. Select Sound Mode. _;_ You can also adjust Sound...
  • Page 54 Sport, or Game. ate. _ Infinite Sound: Infinite Sound is a Select Infinite Sound, Treble, or Bass. patented LG proprietary sound pro- cessing technology that strives immersive 5.1 surround sound with Make appropriate adjustments. just two front speakers. Return to the previous menu.
  • Page 55 AUDIO RESET Settings of the selected Sound Mode return to the default factory settings. Select AUDIO. Select Reset. Select Yes. _> Initialize the adjusted value. _> Return to TV viewing.
  • Page 56 SOUND & LANGUAGE CONTROL TV SPEAKERS ON/OFF SETUP If you wish to use an external Hi-Fi system, turn off the TV's internal speakers. Select AUDIO. Select TV Speaker. Select or Off. Return to the previous menu. Return to TV viewing.
  • Page 57 STEREO/SAP BROADCAST SETUP On analog signals, this TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used if the broadcast is only in Mono.
  • Page 58 SOUND & LANGUAGE CONTROL AUDIO LANGUAGE This feature operates only in DTV/Cable DTV mode. Select OPTION. Select Language. Select Audio Language. _> Select your desired language. _> Return to the previous menu. Return to TV viewing.
  • Page 59 ON-SCREEN MENUS LANGUAGE SELECTION The menus can be shown on the screen in the selected language. i!:i!:i!i_!_i!il Select OPTION. Select Language. Select Menu Language. Select your desired language. _> From this point on, the on-screen menus will be shown in the selected language.
  • Page 60 SOUND & LANGUAGE CONTROL CAPTION MODE Analog Broadcasting System Captions Captions are provided to help the hearing impaired watch TV. Select a caption mode for displaying captioning information if provided on a program. Analog caption displays information at any position on the screen and is usually the program's...
  • Page 61 Digital Broadcasting System Captions Choose the language you want the DTV/Cable DTV Captions to appear Other Languages can be chosen for digital sources only if they are included on the program. This function in only available when Caption Mode is set On. Select OPTION.
  • Page 62 SOUND & LANGUAGE CONTROL Caption Option Customize the DTV/Cable DTV captions that appear on your screen. This function in only available when Caption Mode is set On. _ Size: Set the word size. Select OPTION. _ Font: Select a typeface for the text.
  • Page 63 TIME SETTING CLOCK SETTING Auto Clock Setup The time is set automatically from a digital channel signal. The digital channel signal includes information for the current time provided by the broadcasting sta- tion. Set the clock manually if the current time is set incorrectly by the auto...
  • Page 64 TiME SETTING Clock Setup Manual If the current time setting is wrong, reset the clock manually. Select TIME. Select Clock. Select Manual. Select the Year, Month, Date, Hour, or Minute option. the Year, Month, Date, Hour, or Minute option. Return to the previous menu.
  • Page 65 AUTO ON/OFF TIME SETTING This function operates only if the current time has been set. The Off Time function overrides the On Time function if they are both set to the same time. The TV must be in standby mode for the On Time to work.
  • Page 66 TiME SETTING SLEEP TIMER SETTING The Sleep Timer turns the TV off at the preset time. Note that this setting is cleared when the TV is turned off. _ To cancel the Sleep Timer, select Off. Select TIME. _ You can also adjust Sleep...
  • Page 67 PARENTAL CONTROL / RATINGS Parental Control can be used to block specific channels, ratings other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcasting station. The default setting is to allow all programs to be viewed.
  • Page 68 PARENTAL CONTROL RATINGS Set Password Change the password by inputting a new password twice. Select LOCK. Input the password. Select Set Password. Choose digits your password. As soon as the 4 digits are entered, re-enter same digits Confirm. )> Return to the previous menu.
  • Page 69 Lock System Enables or disables the blocking scheme you set up previously. Select LOCK. _ When select Lock System is enable. Input the password. Select Lock System. Select or Off. Return to the previous menu. "u _> Return to TV viewing. _>...
  • Page 70 PARENTAL CONTROL RATINGS CHANNEL BLOCKING Blocks any channels that you do not want to watch or that you do not want your children to watch. _s, I f channel is locked, enter Select LOCK. password to unlock it temporarily. Input the password.
  • Page 71 MOVI E & TV RATI NG Movie Rating (MPAA)- For USA Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level.
  • Page 72 PARENTAL CONTROL RATINGS TV Rating Children - For USA Prevents children from watching certain children's TV programs, according to the ratings limit set. The children rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audiences in the TV Rating...
  • Page 73 TV Rating General - For USA Based on the ratings, blocks certain TV programs that you and your family do not want to view. Select LOCK. _ Age (applies TV-G,TV-PG,TV- 14,TV-MA). Input the password. s_Dialogue-sexual dialogue (applies TV- PG,-I-V-14). Language-adult language (applies Select...
  • Page 74 PARENTAL CONTROL RATINGS TV Rating English -For CANADA Selecting Canadian English rating system. Select LOCK. _ If TV Rating-English or TV Rating- French is locked, enter the password to unlocked it temporarily. Input the password. _ E (Exempt) _ C (Children) _ C8+ (Children eight...
  • Page 75 TV Rating French -For CANADA Selecting Canadian French rating system. _ E (Exempt) Select LOCK. _ G (General) 8ans+ (General-Not convenient Input the password. little children) 13ans+ (Not convenient for children of 13 years and younger) Select TV Rating-French. 16ans+ (Not convenient for children...
  • Page 76 PARENTAL CONTROL RATINGS DOWNLOADABLE RATING This function is available only for digital channels. This function operates only when TV has received Region5 Rating data. _ Based on rating table, your TV's (On Screen Display) may dif- fer slightly from what is shown this manual.
  • Page 77 EXTERNAL INPUT BLOCKING Enables you to block an input. Select LOCK. Input the password. Select input B_ock. Select input source. Select On or Off. "13 _> Return to the previous menu. _> Return to TV viewing. _>...
  • Page 78 PARENTAL CONTROL RATINGS KEY LOCK This feature can be used to prevent unauthorized viewing by locking out the front panel controls, that it can only be used with the remote control. This TV is programmed to remember which option it was last set to even if you turn the TV off.
  • Page 79 APPENDIX TROUBLESHOOTING _ Is the sleep timer set7 _ Check the power control settings. Power interrupted. _ If there is no signal, the TV turns off automatically in 15 minutes. _ Check whether the product is turned _ Try another channel.
  • Page 80 APPENDIX _ Check High Speed HDMI cable. s_Check USB cable over version 2.0. _ Use normal MP3 file. _This feature is not available for all models. Activate the Auto configure feature or adjust size, phase, or H/V position. (Option) _ Check the signal cable.
  • Page 81 _sCheck whether the file extension is supported. _ Check whether file is playing normally a PC. (Check whether damaged.) Check whether the audio codec is supported. _ Check whether the bit rate is supported. B Bi i Check whether the sample rate is supported. _sCheck whether the file is playing normally on a PC.
  • Page 82 APPENDIX MAINTENANCE Early malfunctions can be prevented. Careful regular cleaning can extend the amount of time can enjoy your new TV. Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen Here's a great...
  • Page 83 PRODUCT SPECIFICATIONS 9.2 kg (20.2 Ibs) 13,8 kg (30,4 Ibs) 23.6 kg (52.0 Ibs) 16,6 kg (36,5 Ibs) 35.7 kg (78.7 Ibs) AC 100-240 V N 50 / .60 Hz NTSC-M, ATSC, .64 & 256 VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135 75 ©...
  • Page 84 APPENDIX 1137.0 mmx 685.0 76.8 1329.0 x 796.0 96.5 (44.7 inch x 26.9 inch x 3.0 inch) (52.3 inch x 31.3 inch x 3.7 inch) 18.3 kg (40.3 Ibs) 28,8 kg (63,4 Ibs) AC 100-240 V N 50 / 60 Hz NTSC-M, ATSC, 64 &...
  • Page 85 29.9 kg (65.9 Ibs) 42,7 kg (94,1 Ibs) AC 100-240 V N 50 / 60 Hz NTSC-M, ATSC, 64 & 256 VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135 75 © Less than 85 % _aThe specifications shown above may be changed without...
  • Page 86 APPENDIX 10,5 kg (25,1 Ibs) 16,7 kg (36,8 Ibs) 22,9 kg (50,4 Ibs) 34,5 kg (76,0 Ibs) 19,6 kg (43,2 Ibs) 28,8 kg (63,4 Ibs) AC120VN 50 / 60 Hz NTSC-M, ATSC, 64 & 256 QAM VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135...
  • Page 87 19,1 kg (42,1 Ibs) 23,0 kg (50,7 Ibs) 33,5 kg (73,8 Ibs) 43.8 kg (96.5 Ibs) 31.6 kg (69.6 Ibs) 35.8 kg (78.9 Ibs) 26.9 kg (59.3 Ibs) AC120VN 50 / 60 Hz NTSC-M, ATSC, 64 & 256 VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135...
  • Page 88 APPENDIX IR CODES *This feature is not available for all models. 1. How fo Connect _ Connect your wired remote control to the Remote Control port on the TV. 2. Remote Control IR Codes _ Output waveform Single pulse, modulated with 37.917 kHz signal at 455 kHz Carrier frequency...
  • Page 89 Remote Control Button CH ^ Remote Control Button VOL + Remote Control Button Remote Control Button ..ii!iii@i!iiiiliiiii!i!ii!ii!i!i_ii_i_!:ii3iiii!iiiiiiBiiiiii!!!!iii_ Remote Control Button (TV Input Selection) FAV/MARK Remote Control Button COMPONENT1 Discrete IR Code BAcK RemOte COntrol Button (Component1 Input Selection) AV MODE Remote Control Button...
  • Page 90 APPENDIX EXTERNAL CONTROL THROUGH RS-232C The RS-232C port allows you connect the RS-232C input jack to an external control device (such a computer or an A/V control system) to control the TV's functions externally. _ Note: RS-232C on this unit is intended to be used with third...
  • Page 91 RS-232C Configurations D-Sub 9 D-Sub 9 D-Sub 9 D-Sub 9 Set ID Use this function to specify a TV ID number. Refer to 'Real Data Mapping'. _ Real data mapping Select OPTION. Step Select Set ID. _> Step 10 (Set ID 10) "13 "13 Choose...
  • Page 92 APPENDIX Command Reference List Transmission / Receiving Protocol O0 - 01 [Command 1] i First c0mmand to control the Set: (j, k, _-_Oi x) iii!i!: ii ili !i i,ii!ii!ii!i!ii!i!i! @ !i!: ! @i! !@:iiiiiiiiiiiiiiiiiiii:i:i R18T [Command 2] ; Second command tO Caatro! the set.
  • Page 93 01.Power (Command: 05. Volume Mute (Command: k e) Tocontrol Power On/Off oftheT_ To control volume mute on/off. Transmission [k][a][][Set I D][][Data][Cr] You can also adjust mute using the MUTE button remote control. Data 0 0:Power Off Data 01: P ower On Transmission [k][e][ ][Set...
  • Page 94 APPENDIX 11. Sharpness (Command: k k) Color Temperature (Command: x u) To adjust screen sharpness. To adjust color temperature. You can also adjust sharpness in the Picture menu. also adjust color temperature in the Picture menu. Transmission [k][k][ ][Set ID][ ][Data][Cr] Transmission [x][u][...
  • Page 95 Data5: The table above lists the binary code which must Channel Add/Del (Command: m b) converted to Hexadecimal before sending. For exam- To add delete channels. ple: The binary code to tune the sub source to an Transmission [m][b][ ][Set ID][ ][Data][Cr] NTSC cable channel...
  • Page 96 APPENDIX OPEN SOURCE LICENSE GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc., 51 licensed everyone's free or not licensed at all. Franklin Street, Fifth Floor, Boston, MA 02110-1301 The precise terms and conditions for copying, distribution and modification...
  • Page 97 c) Accompany it with the information you received as to must cause work that distribute or pub- offer to distribute corresponding source code. lish, that whole part contains derived (This alternative is allowed only for noncommercial from Program or any part there of, to be...
  • Page 98 APPENDIX If, as a consequence of a court judgment or allegation program specifies a version number of this license of patent infringement or for any other reason (not lim- which applies to it and "any later version", have ited to patent issues), conditions are imposed...
  • Page 99 END OF TERMS AND CONDITIONS Also add information on how to contact you by electronic and paper mail. to apply these terms to your programs If the program is interactive, make it output a short notice like this when it starts in an interactive mode: If you...
  • Page 100 APPENDIX LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 that there is no warranty for the free library. Also, if the Copyright (C) 1991, 1999 Free Software Foundation, Inc. library is modified by someone else and passed on, the Franklin Street, Fifth Floor,...
  • Page 101 Although theLesser General Public L icense isLess p rotec- notices that refer to this license to the absence tiveoftheusers' freedom, itdoes ensure t hattheuser o fa warranty; distribute a copy of this license along program thatislinked w iththeLibrary h as thefreedom and with Library.
  • Page 102 APPENDIX You may opt to apply the terms of the ordinary the library will still fall under Section General Public License instead of this License to a given copy of the Library. To do this, you must alter all the Otherwise, if the work is a derivative of the library,...
  • Page 103 You are not responsible enforcing compliance executable, required form "work that third parties with this license. uses library" must include data utility pro- grams needed reproducing executable from 11. If, as a consequence of a court judgment or allegation However, a special exception, materials...
  • Page 104 APPENDIX it free software that everyone can redistribute and change. If the library does specify a license version number, You can do so by permitting redistribution under these choose version ever published by the Free Software Foundation. terms (or, alternatively, under terms of the...
  • Page 105 MOZILLA PUBLIC LICENSE Version 1.Definitions. which, at the time of its release under this license not already covered code governed by this license. 1.0.1. "Commercial use" means distribution or otherwise 1 iOi. making the covered code available to a third party.
  • Page 106 APPENDIX the licenses granted in this section 2.1(a) and (b) offer or impose any terms on any source code ver- effective on the date Initial developer first sion that alters or restricts the applicable version distributes original code under the terms of this this license...
  • Page 107 (c) Representations. code with other code not governed by the terms contributor represents that, except as disclosed pur- this license and distribute the larger work as a single suant to section 3.4(a) above, contributor believes that product. In such a case, you must make sure...
  • Page 108 APPENDIX 7. DISCLAIMER OF WARRANTY. ed to You such participant under sections COVERED CODE PROVIDED UNDER THIS 2i(b) and 2.2(b) are revoked effective as of the LICENSE "AS IS" BASIS, WITHOUT date you first made, used, sold, distributed, WARRANTY KIND, EITHER EXPRESSED made,...
  • Page 109 11. MISCELLANEOUS. EXHIBIT A -Mozilla Public License. This license represents the complete agreement con- cerning subject matter hereof. If any provision of this license is held to be unenforceable, such provision The contents of this file are subject to the Mozilla Public shall be reformed...
  • Page 110 L, i fds Good The model and seria "_umber of-t-he TV s located o'_ the back and/or one side of fhe TV Record if beow should you ever need service MODEL SERIAL...
