Asus P8H61-M PRO User Manual page 34

Audio 2, 4, 6, or 8-channel configuration
Port
Light Blue
Lime
Pink
Orange
Black
Gray
To configure an 8-channel audio output:
Use the chassis with HD audio module in the front panel to support 8-channel audio output.
11. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0/1.1 devices.
12. USB 3.0 ports 1 and 2. These two 9-pin Universal Serial Bus (USB) ports connect to
USB 3.0/2.0 devices.
13. DVI port. This port is for any DVI-D compatible device. DVI-D can't be converted to
output RGB Signal to CRT and isn't compatible with DVI-I.
14. HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector,
and is HDCP compliant allowing playback of HD DVD, Blu-Ray and other protected
content.
15. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0/1.1 devices.
1-22
Headset 2-channel
Line In
Line Out Front Speaker Out
Mic In
-
- Rear Speaker Out
-
4-channel 6-channel
Line in Line in
Front Speaker Out
Mic In
- Center/Subwoofer
Rear Speaker Out
-
8-channel
Line in
Front Speaker Out
Mic in Mic in
Center/Subwoofer
Rear Speaker Out
- Side Speaker Out
Chapter 1: Product introduction
