Product Specification/Installation Sheet
Description
The IntelliSlot Web/485 Card with Adapter
provides 10/100baseT Ethernet Network and
Modbus connectivity for your Emerson Network
Power equipment.
Operating status is monitored and alarms are
communicated via the network, using SNMP
and/or HTTP protocols and over RS-485 using
the Modbus protocol.

Additional Features

• SNMP v1, v2c with MIB-II support
• HTTP/HTTPS 1.1
• Telnet
Compatibility With Other Emerson Network Power Products
Precision Cooling Unit (Controller*)
• Liebert Challenger™ 3000 (L00, L15,
LSM, LAM)
• Liebert DataMate™ (L0B)
• Liebert Deluxe System/3™ (L10, L15,
LSM, LAM)
• Liebert Himod™ (LAM)
• Liebert Industrial Cooling Series™
(L10, LSM, LAM)
• Liebert Mini-Mate™ (L0B)
• Liebert Mini-Mate2™ (MM2)
• Liebert Mini-Mate2 8 Ton (L8T)
• Hiross™ Microface IGMnet
• PEC/Atlas™ (CEMS100/LECS15)
Overall and Mounting Dimensions
0.6" (15.3mm)
S W
®
LOT EB
* Controller Codes
L00:
L0B:
L10:
L15:
LSM:
LAM:
7" (177.8mm)
2.8"
(71.1mm)
Six holes, each
0.156" diameter
3.2"
(81.3mm)
/485 C
ARD
• BootP, DHCP per RFC2131
• Secure Sockets (SSL)
• Remote firmware updates via HTTP
Large UPS
Level 00 • Liebert Npower™
• Liebert Series 300™
Level 0B
• Liebert Series 600™/610™ (Single Module)
Level 10
• Liebert Series 610 System Control Cabinet
Level 15
(Multi-Module)
• Hiross 7200 (EMEA)
Standard
• Hiross HiPulse™ (EMEA)
Microprocessor
Power Management
Advanced
Microprocessor
• Liebert Datawave
• Liebert FPC™
• Liebert Precision Power Center™
• Liebert Static Transfer Switches:
STS™, STS2-3 pole, STS2/PDU
3.4"
(86.4mm)
0.8" (20.3mm)
0.4" (10.2mm)
1
W A
ITH DAPTER
®
2.4"
(61mm)
4"
(101.6mm)
0.2" (5mm)
