Lightolier FBP60 Specification

700 L
FBP60
9.4"
(23.9 cm)
2.4"
(6.1 cm)
1.5"
(3.8 cm)
L
UMEN INEAR
Features
Illumination: The FBP60
provides 90 minutes of
emergency illumination by
utilizing existing fluorescent
lighting, and produces 600-700
lumens initial emergency light
output. If two-lamp operation
is selected, light output is
evenly divided between the
lamps for better emergency
illumination. The FBP60 can be
used with most 17-215 W
(2'-8') T8, T10, or T12
fluorescent lamps without
integral starters, including
U-shaped, HO, VHO, circline,
energy saving, and 4-pin
compacts. It is also compatible
with most 1-, 2-, 3-, and 4-lamp
electronic, standard, energy
saving and dimming AC ballasts.
See lamp operation for specific
lamp types.
Housing: Housing is
constructed of 20 gauge steel
with a high temperature
powder coat paint finish. Slim
housing allows for wireway
channel mounting on most
lighting fixtures.
Operating Temperature
Range:
32°F (0°C) to 131°F (55°C)
F
LUORESCENT
Electronics: 120/277 VAC
dual voltage input with surge
protected, solid-state charging
circuitry provides for a reliable
charging system. Charging
system is complete with AC
indicator lamp and test switch.
Electrical Specifications:
Input Power
3.5 W max.
Battery
Maintenance free, sealed nickel
cadmium battery. Supplies 90
minutes of emergency power.
Estimated service life of 10
years.
Lamp Operation 1 : Operates
2
the following lamp types :
T8 linear fluorescent
T12 linear fluorescent
T9 circline
T12 U-bent
T5 long compact fluorescent
Notes:
1) Consult factory for compatibility,
operation and performance of product
with lamp types not listed.
2) See table 1 on back for specific lamp
performance and operation.
Job Information Type:
Job Name:
Cat. No.:
Notes:
FBP60
E . B
M ALLAST
Page 1 of 2
Code Compliance
UL 924 and optional UL damp
location listed. NFPA 70, NFPA
101, NEC, BOCA, OSHA and
IBC illumination standards.
Suitable for use in sealed and
gasketed fixtures.
Warranty
Three year full electronics
warranty. Three year full
battery warranty.
