Lightolier Sidelyte SIS2GPF2FT Specification

Page 1 of 2
• Direct/indirect side basket appearance.
• Perforated mesh lamp shields with white acrylic overlays.
• 55.1% efficient (2 lamp 40W TT5).
• Spacing to mounting ratio 1.4.
• Only 6" deep body.
• One-piece housing.
• Ballast accessible from room side.
• Perforated lamp shields hinge for easy relamping.
• 2 earthquake clips standard.
• UL Listed twin knockout access plate.
• Not suitable for continuous row mounting.
Mounting Methods
G exposed T-grid ceiling.
1/4" max.
1-1/2" max.
15/16"
or 1"
24"
drywall kit (see options)
Type "G" Support
Fixture
(by others)
Drywall Kit
(see options)
Dry Wall (by others)
Order Catalog Number: FK92X2 .
2/06
Sidelyte Recessed Fluorescent
Direct/Indirect 2' x 2' with Perforated Baskets
Dimensions
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2006 a Genlyte company
24" (610mm)
5"
(127mm)
2"x 2-1/2" access plate
with two K.O.s (7/8" dia.)
Type:
a Genlyte company
SIS2GPF2FT
Static, 2 Lamp TT5
6"
(152mm)
23-31/32"
(608mm)
www.lightolier.com
Section 5/Folio M17-10
