FAIL-SAFE
TF17
TF28
7 0 W - 1 5 0 W
I n d u c t i o n
S U R F A C E M O U N T
T R A N S I T A N D C O M P L E X
E N V I R O N M E N T
L U M I N A I R E
• Choice of glass or
polycarbonate; prismatic for
glare control or clear
• Housing is available in die-
formed 14 gauge cold rolled
steel, 14 gauge 304 brushed
stainless steel or 1/8" thick
aluminum
• Housing is continuously
welded with ground ends to
form a one-piece seamless
construction for maximum
resistance to the
environment
• Aircraft grade safety cable
lanyards attaches
doorframe to housing
• Gasket is one-piece die-cut
EPDM closed cell sponge
with pressure sensitive
adhesive
• Stainless steel captive
Philips Head screws are
used to fasten doorframe to
housing
• Polyester powder coat finish
is standard; available colors
are utility gray, architectural
bronze, white or specify
color
• 150W Induction Icetron™
Lamp installed and fully
secured in unit
• High power factor, Universal
120V through 277V
• CUL Listed for Wet
Locations; optional
high-pressure hose down
available; high ambient
rating is available up to
45° C.
1508
COOPER LIGHTING
®
D E S C R I P T I O N
The Fail~Safe TF fixture is
designed for the most
demanding and complex
environments your application
has to offer. One-piece
seam-welded construction and
energy efficient lamp
technology make this fixture
an ideal candidate for
applications ranging from the
most hostile to the most fragile
environments. The TF fixture
provides a durable and long
life installation. Long lamp life
means less re-lamping and
less maintenance costs
resulting in a big payback. A
durable and anti-corrosive
construction ensures that your
investment is protected as
expected through the end.
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : T F 2 8 - 1 5 0 I C E - U N V - 9 3 - A L P - G R Y
Product Family
Lamp Type
Surface Mount
70ICE=70W
TF17
Icetron
TF28
Lamp
150ICE=150W
Icetron
Lamp
Notes: For additional options, consult your Cooper Lighting Representative. Specifications and Dimensions subject to change without notice.
1
Aluminum Housing (option ALP) required for high ambient applications above 25°C.
unit cannot be opened without corrupting seal.
D I M E N S I O N S
TF17
M O U N T I N G
TF17
Voltage
Door Frame / Housing Options
(14 Gauge Cold Rolled Steel Standard)
UNV=120V
™
through
SSN=Brushed Stainless Steel
277V
SSP=Stainless Steel, Polyester Powder
™
Lens Type
Fixture Side
ALP
85=.187 Clear
Polycarbonate
(Available Soon)
82=.187 Prismatic
Polycarbonate
(Available Soon)
93=.156 Prismatic
Tempered Glass
TF28
TF28
Options
F1=Single Fuse
(14 Gauge)
FS
Coat (14 Gauge)
PSI=High
1
=Aluminum Housing Polyester
Powder Coat (1/8" Thick)
Finish
GRY=Utility Gray
BRZ=Architectural
Bronze
WHT=High Gloss
White
BLK=Black
(For Custom Color,
Consult Customer
Service, Requires
Flat Fee)
2
FS Option is sealed and ready for immediate installation;
(Specify
Single
Voltage)
2
=Factory
Sealed
Pressure
Wash Down
Rated
(Available
Soon)
