Lightolier OBL432 Specification

Page 1 of 2
Features
• For nursing homes, hospitals and other health care facilities.
• Separate lamp compartments for controlled uplight and downlight.
• Four-way pull switch, standard (120 volt only).
• .125 thick DR acrylic linear prismatic refractor. (impact resistant).
• Flat white fascia standard.
• Cold rolled steel body with die-cast aluminum ends.
• Concealed pull-action spring-loaded latches to retain lens.
• Optional oak fascia insert.
• Optional low voltage electronic sequential switch for push button
control of up/down lighting. UL 544 listed. Includes phone jack type
receptacle.
Features
enclosed, controlled
up-n-down light
concealed pull-action
spring-loaded latches
4/03
Over Bed, Wall Mounted, Fluorescent, Uplight/Downlight
5-9/16" Width, 48" Nominal Length, 2, 3, or 4 Lamp T8
Dimensions
Switching:
4 Lamps = 1, 2, 3, 4
3 Lamps = 1, 2, 4
2 Lamps = 2, 4
1-7/8" Dia. K.O.
7/8" Dia. Holes (3)
5-61/64"
16" (406mm)
(151mm)
23-61/64" (608mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2003 Genlyte Thomas Group LLC (Lightolier Division)
A0902
OB Series
1 2
6-1/16"
(154mm)
4
3
Pull Switch
5-9/16" (141mm)
3/16" x 5/8" Oval K.O.'s (4)
32" (813mm)
47-57/64" (1216mm)
Type:
Section 8/Folio R35-10
OBL432
www.lightolier.com
