Lightolier WA Series 232 Specification

Page 1 of 2 SURFACE WRAPAROUND FLUORESCENT, 9" WIDE x 2 5/8" DEEP x 48" OR 96" LENGTHS
Features
• Step back housing for an apparent depth of 1 1/2".
• Completely assembled with setup ends to lamp holders.
• Only 3" total depth.
• Prismatic virgin acrylic lens – 9" wide.
• Efficiency 70.9%.
• Luminous catadioptic end caps.
• Two side self-leveling lens hinging.
• Zip-clip flush mount on T-grid ceilings.
• Off center 7/8" K.O. for flush mount to T-grid ceiling.
• Optional UL-Listed low density mounting spacers.
Features
DOMINAIRE II
Dimensions
2-11/32"
(60mm)
7/8" K.O. within 1-7/8" K.O.
44-1/16" (1119mm)
39-5/8" (1006mm)
31/32"
(77mm)
5"
(127mm)
48-3/4" (1238mm)
7/8" K.O. within 1-7/8" K.O.
4-9/16" (116mm)
39-5/8"
(1006mm)
31/32"
(77mm)
5"
24-7/16"(624mm)
(127mm)
97-1/2"(2477mm)
Job Information
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier
a Genlyte Thomas Company
Technical Information: (978) 657-7600 • Fax (978) 658-0595
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902
WA SERIES 232
2 LAMP, T8 OR T12
2-5/8"
(67mm)
9" (227mm)
4-9/16" (116mm)
9/32" mounting holes
92-13/16"
(2357mm)
39-5/8"
(1006mm)
31/32"
(77mm)
29-5/16"(744mm)
9/32" mounting holes
Type:
www.lightolier.com
Section 3A/Folio H90-12 Rev. B
2-11/32"
(60mm)
