Chicago Electric 67707 Set Up And Operating Instructions Manual

Chicago Electric 67707 Set Up And Operating Instructions Manual

12v lithium-ion multifunction tool
Hide thumbs
Table of Contents

Advertisement

Quick Links

muLtifunction tooL
Set up and operating inStructionS
Visit our website at: http://www.harborfreight.com
read this material before using this product.
failure to do so can result in serious injury.
SaVe thiS manuaL.
©
Copyright
2010 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
for technical questions or replacement parts, please call 1-800-444-3353.
12V Lithium-ion
model
®
. All rights reserved. No portion of this manual or any artwork
67707

Advertisement

Table of Contents
loading

Related Manuals for Chicago Electric 67707

Summary of Contents for Chicago Electric 67707

  • Page 1 12V Lithium-ion muLtifunction tooL model 67707 Set up and operating inStructionS Visit our website at: http://www.harborfreight.com read this material before using this product. failure to do so can result in serious injury. SaVe thiS manuaL. © ® Copyright 2010 by Harbor Freight Tools .

  • Page 2: Important Safety Information

    notice is used to SaVe thiS manuaL address practices not Keep this manual for the safety warnings related to personal injury. and precautions, assembly, operating, caution, without the inspection, maintenance and cleaning safety alert symbol, is procedures. Write the product’s serial number used to address practices not in the back of the manual near the assembly related to personal injury.
  • Page 3 a power tool while you are tired or power tool use and care under the influence of drugs, alcohol do not force the power tool. use or medication. A moment of inattention the correct power tool for your while operating power tools may result application.
  • Page 4 Keep cutting tools sharp and clean. multifunction tool Safety Warnings Properly maintained cutting tools with Maintain labels and nameplates on sharp cutting edges are less likely to the tool. These carry important safety bind and are easier to control. information. If unreadable or missing, use the power tool and accessories contact Harbor Freight Tools for a in accordance with these...
  • Page 5 flammable, but they also obstruct microscopic particles. (California Health vents under the Battery pack. & Safety Code § 25249.5, et seq.) Place the Battery Pack on a stable, solid, WARNING: Handling the Charger cord nonflammable surface (such as a stable on this product will expose you to lead, a metal workbench or concrete floor) at chemical known to the State of California...

  • Page 6: Vibration Safety

    Inspect Battery Pack before every use; abnormal vibration occurs, stop use do not use or charge if damaged. immediately. SaVe theSe Vibration Safety inStructionS. This tool vibrates during use. Repeated or long-term exposure to vibration may cause temporary or permanent physical grounding injury, particularly to the hands, arms and shoulders.

  • Page 7: Extension Cords

    the applicable standards of Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. Double insulated tools may be used in either of the 120 volt outlets shown in the preceding illustration. (See outlets for 2-prong plug.) extension cords note: Extension cords must not be used with this item’s Charger.

  • Page 8: Specifications

    assembling or making any SpecificationS adjustments to the tool. Charger Input 120 VAC note: For additional information regarding the Battery Type 12 V Lithium, 1.3 Ah parts listed in the following pages, refer to the Assembly Diagram near the end of Motor Speed 15,000 OPM (No Load) this manual.

  • Page 9: Charging The Battery Pack

    Unplug the Battery Pack from the Work piece and Work area Set up Charger and the Charger from the wall Designate a work area that is clean and outlet. well-lit. The work area must not allow note: Do not use a battery pack immediately access by children or pets to prevent after charging.

  • Page 10: General Operating Instructions

    general operating instructions Scraper Blade (501) Spindle (3) Secure loose work pieces using a vise or clamps (not included) to prevent movement while working. Install desired accessory. Cap Screw (1) figure 4 Retainer (2) note: When attaching the angled Cutting Power Switch Blade (502) or Scraper Blade (501), (26)
  • Page 11 Power Switch (26) figure 7 While holding the Tool with both hands, slide the Power Switch (26) forward to activate. Do not allow contact between Sandpaper, Scraper, or Blade and workpiece until tool is at full speed. Avoid contact with foreign objects such as metal screws and nails when sanding, scraping, or cutting.

  • Page 12: Maintenance And Servicing

    or Battery pack. Keep charger and maintenance and Battery pack dry. SerVicing Procedures not specifically explained in this manual must be performed only by a qualified technician. to preVent SeriouS injurY from accidentaL operation: turn the power Switch off and remove the Battery pack from the tool before performing any inspection, maintenance, or...

  • Page 13: Troubleshooting

    troubleshooting problem possible causes Likely Solutions Tool will not start. Battery Pack needs charging Charge Battery Pack. Battery Pack not properly seated. Check that Battery Pack is fully inserted into tool so that it snaps into place. Connection to Battery Pack Check that the terminals inside the tool are not damaged.

  • Page 14: Parts List & Assembly Diagram

    partS LiSt & aSSemBLY diagram part description part description Cap Screw M8 x 12 Left Housing Retainer Power Switch Spindle Screw ST3.2 x 14 Rubber Casing Electrical Contact Circlip for shaft 26 Screw ST3.2 x 14 Spring Washer Battery Cover (Front) Bearing 6000 Battery Button Block...

  • Page 15: Limited 90-Day Warranty

    Limited 90 daY WarrantY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
