- Page 2 Table of Contents Safety ............3 Maintenance ..........9 Specifications ..........5 Parts List and Diagram ......10 Operation ............ 6 Warranty ............ 12 WARNING SYMBOLS AND DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
- Page 3 IMPORTANT SAFETY INFORMATION When using helmet, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator.
- Page 4 13. This helmet provides protection for intended c. Regularly replace the Front Lens Cover purposes only. There are certain applications if it becomes cracked, scratched, for which this helmet was designed. Do not pitted, or otherwise damaged. modify this helmet and do not use this helmet d.
-
Page 5: Specifications
Specifications Description Auto-Darkening Welding Helmet Power Source Solar powered cells with battery assistance (not rechargeable) Operating Temp. 23° to 131° F Resting Shade Shade # 4 Shade Range 9 to 13 UV/IR Protection up to DIN 16 at all times Lens Type ANSI Z87.1-2003 approved Viewing Area 3.86"... -
Page 6: Before Welding
Operating Instructions Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Function The Auto-Darkening Welding Helmet is designed to protect the eyes and face from sparks, splatter, and harmful radiation under normal welding conditions. -
Page 7: Adjusting Headband
Adjusting Headband Solar Cells Adjust the Headband so that the helmet This Welding Helmet utilizes high performance solar is seated securely on your head as low cells as power supply, and has two built-in 3V lithium as possible and close to your face. batteries as power backup. No change of battery is needed. Under normal welding conditions, users can Adjust the Headband width by turning the expect a battery lifetime of more than 6 years. -
Page 8: Troubleshooting
Common Problems and Remedies 1. Irregular Darkening Or Dimming a. Headband has been set unevenly on both sides of helmet (unequal distances from the eyes to filter’s lens). b. Reset Headband to reduce difference in distances to filter, if necessary. 2. Auto-Darkening Filter Does Not Darken Or Flickers a. Front Cover Lens is soiled or damaged (change the cover lens). b. -
Page 9: Lens And Helmet Maintenance
Maintenance and Servicing Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use. Lens and Helmet Maintenance Replace the Front Lens Cover if it is damaged Figure F... -
Page 10: Please Read The Following Carefully
Parts List and Diagram PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Parts List Part Description Part Description Shell (Welding Mask) Washer Front Cover Lens Tension Adjustment Knob Auto-Darkening Filter Screw Inside Cover Lens Ratcheting Headband Flat Washer Sweatband... -
Page 11: Assembly Diagram
Assembly Diagram Item 67854 For technical questions, please call 1-800-444-3353. Page 11... - Page 12 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
