Frigidaire FRT18IG4A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18IG4A
  6. Factory parts catalog
Frigidaire FRT18IG4A Factory Parts Catalog

Frigidaire FRT18IG4A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT18IG4A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18IG4AQ6
FRT18IG4A
FRT18IG4AT6
FRT18IG4A
FRT18IG4AW6
FRT18IG4A
FRT18IG4AZ6
FRT18IG4A
MARKET
North America
ENERGY GUIDE - 218791460
OWNER'S GUIDE - 240400107
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque (right)
R134a
bisque (left)
R134a
white (right)
R134a
white
Publication No.
5995379988
021021
-EN/SERVICE/KHB
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
(left)
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18IG4A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FRT18IG4A

Summary of Contents for Frigidaire FRT18IG4A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18IG4AQ6 FRT18IG4A R134a bisque (right) FRT18IG4AT6 FRT18IG4A R134a bisque (left) FRT18IG4AW6 FRT18IG4A R134a white (right) FRT18IG4AZ6 FRT18IG4A R134a white (left) MARKET North America ENERGY GUIDE - 218791460 OWNER’S GUIDE - 240400107 SERVICE DATA SHEET - 240379010 TOP MOUNT REFRIGERATOR...
  • Page 2 Publication No. FRT18IG4A 5995379988 DOOR 10/02...
  • Page 3 FRT18IG4A Publication No. 5995379988 DOOR A = FRT18IG4A (FRT18IG4AQ6) B = FRT18IG4A (FRT18IG4AT6) C = FRT18IG4A (FRT18IG4AW6) D = FRT18IG4A (FRT18IG4AZ6) POS. NO PART NO DESCRIPTION 240542103 A B C D Gasket-frzr door,white ,magnetic 240542106 A B C D Gasket-refr door,white ,magnetic 240534901 A B C D Rack-door...
  • Page 4 Publication No. FRT18IG4A 5995379988 CABINET 10/02...
  • Page 5 FRT18IG4A Publication No. 5995379988 CABINET A = FRT18IG4A (FRT18IG4AQ6) B = FRT18IG4A (FRT18IG4AT6) C = FRT18IG4A (FRT18IG4AW6) D = FRT18IG4A (FRT18IG4AZ6) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
  • Page 6 Publication No. FRT18IG4A 5995379988 SHELVES 10/02...
  • Page 7 FRT18IG4A Publication No. 5995379988 SHELVES A = FRT18IG4A (FRT18IG4AQ6) B = FRT18IG4A (FRT18IG4AT6) C = FRT18IG4A (FRT18IG4AW6) D = FRT18IG4A (FRT18IG4AZ6) POS. NO PART NO DESCRIPTION 240358002 A B C D Shelf-freezer,full width 5303299664 A B C D Spacer,shelf 240545001 A B C D Diffuser,air ,top 240362601...
  • Page 8 Publication No. FRT18IG4A 5995379988 SYSTEM 10/02...
  • Page 9 FRT18IG4A Publication No. 5995379988 SYSTEM A = FRT18IG4A (FRT18IG4AQ6) B = FRT18IG4A (FRT18IG4AT6) C = FRT18IG4A (FRT18IG4AW6) D = FRT18IG4A (FRT18IG4AZ6) POS. NO PART NO DESCRIPTION 240406404 A B C D Condenser,static 5303208866 A B C D Spacer,condenser tube ,black 5308000296 A B C D Bracket,condenser mtg ,(4)

  • Page 10: Ice Maker

    Publication No. FRT18IG4A 5995379988 ICE MAKER 10/02...
  • Page 11 FRT18IG4A Publication No. 5995379988 ICE MAKER A = FRT18IG4A (FRT18IG4AQ6) B = FRT18IG4A (FRT18IG4AT6) C = FRT18IG4A (FRT18IG4AW6) D = FRT18IG4A (FRT18IG4AZ6) POS. NO PART NO DESCRIPTION 218976901 A B C D Tube-water inlet, inlet valve to ice maker 5304420650 A B C D Spring, shut-off arm 3206299...

  • Page 12: Wiring Schematic

    Publication No. FRT18IG4A 5995379988 WIRING SCHEMATIC 10/02...

  • Page 13: Wiring Diagram

    FRT18IG4A Publication No. 5995379988 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...
