Frigidaire FRT18IG4A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT18IG4A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18IG4AQ4
FRT18IG4A
FRT18IG4AT4
FRT18IG4A
FRT18IG4AW4
FRT18IG4A
FRT18IG4AZ4
FRT18IG4A
MARKET
North America
WIRING DIAGRAM - # 240398801
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque (right)
R134a
bisque (left)
R134a
white (right)
R134a
white
Publication No.
5995369047
020326
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
(left)
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18IG4A
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading

Related Manuals for Frigidaire FRT18IG4A

Summary of Contents for Frigidaire FRT18IG4A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18IG4AQ4 FRT18IG4A R134a bisque (right) FRT18IG4AT4 FRT18IG4A R134a bisque (left) FRT18IG4AW4 FRT18IG4A R134a white (right) FRT18IG4AZ4 FRT18IG4A R134a white (left) MARKET North America WIRING DIAGRAM - # 240398801 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 TOP MOUNT REFRIGERATOR...
  • Page 2 Publication No. FRT18IG4A 5995369047 DOOR 03/02...
  • Page 3 FRT18IG4A Publication No. 5995369047 DOOR A = FRT18IG4A (FRT18IG4AQ4) B = FRT18IG4A (FRT18IG4AT4) C = FRT18IG4A (FRT18IG4AW4) D = FRT18IG4A (FRT18IG4AZ4) POS. NO PART NO DESCRIPTION 240514605 A B C D Gasket-frzr door,white ,magnetic 240514606 A B C D Gasket-refr door,white ,magnetic 240331401 A B C D Rack-door,20.27"...
  • Page 4 Publication No. FRT18IG4A 5995369047 CABINET 03/02...
  • Page 5 FRT18IG4A Publication No. 5995369047 CABINET A = FRT18IG4A (FRT18IG4AQ4) B = FRT18IG4A (FRT18IG4AT4) C = FRT18IG4A (FRT18IG4AW4) D = FRT18IG4A (FRT18IG4AZ4) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
  • Page 6 Publication No. FRT18IG4A 5995369047 SHELVES 03/02...
  • Page 7 FRT18IG4A Publication No. 5995369047 SHELVES A = FRT18IG4A (FRT18IG4AQ4) B = FRT18IG4A (FRT18IG4AT4) C = FRT18IG4A (FRT18IG4AW4) D = FRT18IG4A (FRT18IG4AZ4) POS. NO PART NO DESCRIPTION 240358002 A B C D Shelf-freezer,full width 5303299664 A B C D Spacer,shelf 240362502 A B C D Diffuser,air ,top 240362601...
  • Page 8 Publication No. FRT18IG4A 5995369047 SYSTEM 03/02...
  • Page 9 FRT18IG4A Publication No. 5995369047 SYSTEM A = FRT18IG4A (FRT18IG4AQ4) B = FRT18IG4A (FRT18IG4AT4) C = FRT18IG4A (FRT18IG4AW4) D = FRT18IG4A (FRT18IG4AZ4) POS. NO PART NO DESCRIPTION 240406404 A B C D Condenser,static 240405201 A B C D Grommet,rubber ,black ,cond tube/wire 5303208866 A B C D Spacer,condenser tube ,black...

  • Page 10: Ice Maker

    Publication No. FRT18IG4A 5995369047 ICE MAKER 03/02...
  • Page 11 FRT18IG4A Publication No. 5995369047 ICE MAKER A = FRT18IG4A (FRT18IG4AQ4) B = FRT18IG4A (FRT18IG4AT4) C = FRT18IG4A (FRT18IG4AW4) D = FRT18IG4A (FRT18IG4AZ4) POS. NO PART NO DESCRIPTION 218976901 A B C D Tube-water inlet,inlet valve to ice maker 5304420650 A B C D Spring,shut-off arm 5308000039 A B C D...

  • Page 12: Wiring Schematic

    Publication No. FRT18IG4A 5995369047 WIRING SCHEMATIC 03/02...

  • Page 13: Wiring Diagram

    FRT18IG4A Publication No. 5995369047 WIRING DIAGRAM # = Fast-moving Parts 03/02 * = Non-Illustrated Parts...
