Frigidaire FRT21IS6B Factory Parts Catalog

Frigidaire FRT21IS6B Factory Parts Catalog

Top-mount refrigerator with ice-maker r134a series
Hide thumbs Also See for FRT21IS6B:

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Service Data Sheet
Installation Instructions 240568301
N05L00003.eps N05DCDBCA1.eps N05BBAAAA12.eps N05SACAFI17.eps
N05CAAAAA23.eps 115-1.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
THIS CATALOG SUPERCEDES
5995469144.
FRT21IS6BBA FRT21IS6BB8 FRT21IS6BQA FRT21IS6BQ8 FRT21IS6BWA FRT21IS6BW8
R134a
R134a
R134a
black
black
bisque
115
115
115
240398801
240398801
240398801
241694400
241694400
241694400
North America North America North America North America North America North America
240379018
240379018
240379018
240568301
240568301
240398801.eps 240398601.eps
Publication No.
5995478384
06/11/03
(EN/SERVICE/KHB)
137
R134a
R134a
R134a
bisque
white
white
115
115
115
240398801
240398801
240398801
241694400
241694400
241694400
240379018
240379018
240379018
240568301
240568301
240568301
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21IS6B
©
Copyright
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire FRT21IS6B

Summary of Contents for Frigidaire FRT21IS6B

  • Page 1 Product No. FRT21IS6BBA FRT21IS6BB8 FRT21IS6BQA FRT21IS6BQ8 FRT21IS6BWA FRT21IS6BW8 Series R134a R134a R134a R134a R134a R134a Color black black bisque bisque white white Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801 Owner's Guide 241694400 241694400 241694400 241694400 241694400 241694400 Market North America North America North America North America North America North America Service Data Sheet 240379018...
  • Page 2 Publication No: 5995478384 FRT21IS6B DOOR N05DCDBCA1 11/06...
  • Page 3 FRT21IS6B Publication No: 5995478384 DOOR Model Index: A FRT21IS6B (FRT21IS6BBA) B FRT21IS6B (FRT21IS6BB8) C FRT21IS6B (FRT21IS6BQA) D FRT21IS6B (FRT21IS6BQ8) E FRT21IS6B (FRT21IS6BWA) F FRT21IS6B (FRT21IS6BW8) POS. NO PART NO. DESCRIPTION 240514611 A B - - - - Gasket, seal, black, frzr door, magnetic 240514607 - - C D E F Gasket, seal, white, frzr door, magnetic...
  • Page 4 Publication No: 5995478384 FRT21IS6B CABINET N05BBAAAA12 11/06...
  • Page 5 FRT21IS6B Publication No: 5995478384 CABINET Model Index: A FRT21IS6B (FRT21IS6BBA) B FRT21IS6B (FRT21IS6BB8) C FRT21IS6B (FRT21IS6BQA) D FRT21IS6B (FRT21IS6BQ8) E FRT21IS6B (FRT21IS6BWA) F FRT21IS6B (FRT21IS6BW8) POS. NO PART NO. DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F Knob-damper control 5303212803 A B C D E F...
  • Page 6 Publication No: 5995478384 FRT21IS6B CABINET N05BBAAAA12 11/06...
  • Page 7 FRT21IS6B Publication No: 5995478384 CABINET Model Index: A FRT21IS6B (FRT21IS6BBA) B FRT21IS6B (FRT21IS6BB8) C FRT21IS6B (FRT21IS6BQA) D FRT21IS6B (FRT21IS6BQ8) E FRT21IS6B (FRT21IS6BWA) F FRT21IS6B (FRT21IS6BW8) POS. NO PART NO. DESCRIPTION 5304418225 A B C D E F Roller, compressor base, rear, (2) 5304455655 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin...
  • Page 8 Publication No: 5995478384 FRT21IS6B SHELVES N05SACAFI17 11/06...
  • Page 9 FRT21IS6B Publication No: 5995478384 SHELVES Model Index: A FRT21IS6B (FRT21IS6BBA) B FRT21IS6B (FRT21IS6BB8) C FRT21IS6B (FRT21IS6BQA) D FRT21IS6B (FRT21IS6BQ8) E FRT21IS6B (FRT21IS6BWA) F FRT21IS6B (FRT21IS6BW8) POS. NO PART NO. DESCRIPTION 240358006 A B C D E F Shelf, freezer, full-width, wire 240545901 A B C D E F Diffuser-air, top...
  • Page 10 Publication No: 5995478384 FRT21IS6B SYSTEM N05CAAAAA23 11/06...
  • Page 11 FRT21IS6B Publication No: 5995478384 SYSTEM Model Index: A FRT21IS6B (FRT21IS6BBA) B FRT21IS6B (FRT21IS6BB8) C FRT21IS6B (FRT21IS6BQA) D FRT21IS6B (FRT21IS6BQ8) E FRT21IS6B (FRT21IS6BWA) F FRT21IS6B (FRT21IS6BW8) POS. NO PART NO. DESCRIPTION 240444401 A B C D E F Condenser, dynamic 5303305677 A B C D E F Drier-filter, R12 &...

  • Page 12: Ice Maker

    Publication No: 5995478384 FRT21IS6B ICE MAKER 11/06...
  • Page 13 FRT21IS6B Publication No: 5995478384 ICE MAKER Model Index: A FRT21IS6B (FRT21IS6BBA) B FRT21IS6B (FRT21IS6BB8) C FRT21IS6B (FRT21IS6BQA) D FRT21IS6B (FRT21IS6BQ8) E FRT21IS6B (FRT21IS6BWA) F FRT21IS6B (FRT21IS6BW8) POS. NO PART NO. DESCRIPTION 218976901 A B C D E F Tube, water inlet, valve to IM 240561701 A B C D E F Seal-water inlet, inlet valve, to ice maker...

  • Page 14: Wiring Schematic

    Publication No: 5995478384 FRT21IS6B WIRING SCHEMATIC 11/06...

  • Page 15: Wiring Diagram

    FRT21IS6B Publication No: 5995478384 WIRING DIAGRAM 11/06 # Functional Parts * Non-Illustrated Parts...
