PRODUCT NO.
BASE MODEL NO.
FRT21IS6BB2
FRT21IS6B
FRT21IS6BQ2
FRT21IS6B
FRT21IS6BW2
FRT21IS6B
MARKET
North America
WIRING DIAGRAM - # 240379009
OWNER'S GUIDE - # 240400106
SERVICE DATA SHEET - # 240379009
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995373791
020607
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21IS6A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21IS6A
Summary of Contents for Frigidaire FRT21IS6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21IS6BB2 FRT21IS6B R134a black FRT21IS6BQ2 FRT21IS6B R134a bisque FRT21IS6BW2 FRT21IS6B R134a white MARKET North America WIRING DIAGRAM - # 240379009 OWNER’S GUIDE - # 240400106 TOP MOUNT SERVICE DATA SHEET - # 240379009 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21IS6A 5995373791 DOOR 06/02...
- Page 3 FRT21IS6A Publication No. 5995373791 DOOR A = FRT21IS6B (FRT21IS6BB2) B = FRT21IS6B (FRT21IS6BQ2) C = FRT21IS6B (FRT21IS6BW2) POS. NO PART NO DESCRIPTION 240514611 A - - Gasket,frzr door seal ,black ,magnetic 240514607 - B C Gasket,frzr door seal ,white ,magnetic 240514612 A - - Gasket,refr door seal ,black ,magnetic...
- Page 4 Publication No. FRT21IS6A 5995373791 CABINET 06/02...
- Page 5 FRT21IS6A Publication No. 5995373791 CABINET A = FRT21IS6B (FRT21IS6BB2) B = FRT21IS6B (FRT21IS6BQ2) C = FRT21IS6B (FRT21IS6BW2) POS. NO PART NO DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut,push-on 240367401 A B C Damper-fan cover 5308000010 A B C...
- Page 6 Publication No. FRT21IS6A 5995373791 SHELVES 06/02...
- Page 7 FRT21IS6A Publication No. 5995373791 SHELVES A = FRT21IS6B (FRT21IS6BB2) B = FRT21IS6B (FRT21IS6BQ2) C = FRT21IS6B (FRT21IS6BW2) POS. NO PART NO DESCRIPTION 240358003 A B C Shelf,freezer ,full-width ,wire 5303299664 A B C Spacer,shelf 240380202 A B C Diffuser,air ,top 240362601 A B C Diffuser,air ,bottom...
- Page 8 Publication No. FRT21IS6A 5995373791 SYSTEM 06/02...
- Page 9 FRT21IS6A Publication No. 5995373791 SYSTEM A = FRT21IS6B (FRT21IS6BB2) B = FRT21IS6B (FRT21IS6BQ2) C = FRT21IS6B (FRT21IS6BW2) POS. NO PART NO DESCRIPTION 240444401 A B C Condenser,dynamic 218944001 A B C Drier-filter,R134a System 240496101 A B C Wiring Harness,machine compt, w/electric cord 6* # 240388701 A B C...
-
Page 10: Ice Maker
Publication No. FRT21IS6A 5995373791 ICE M AKER 06/02... - Page 11 FRT21IS6A Publication No. 5995373791 ICE MAKER A = FRT21IS6B (FRT21IS6BB2) B = FRT21IS6B (FRT21IS6BQ2) C = FRT21IS6B (FRT21IS6BW2) POS. NO PART NO DESCRIPTION 218976901 A B C Tube-water inlet, inlet valve to ice maker 5304420650 A B C Spring,shut-off arm 5308000039 A B C Screw, hex wshr hd, 8-32CA x 0.500, serrated head...
-
Page 12: Wiring Schematic
Publication No. FRT21IS6A 5995373791 WIRING SCHEMATIC 06/02... -
Page 13: Wiring Diagram
FRT21IS6A Publication No. 5995373791 WIRING DIAGRAM # = Fast-moving Parts 06/02 * = Non-Illustrated Parts...
