COROLLA
2 0 1 0
QUICK REFERENCE
GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Toyota Corolla

Summary of Contents for Toyota Corolla

  • Page 1 COROLLA 2 0 1 0 QUICK REFERENCE GUIDE...
  • Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Corolla.
  • Page 3 EMERGENCY FEATURES Seatbelts Seatbelts-Shoulder belt adjustment Spare tire & tools Tire Pressure Monitoring (warning) System 20 Trunk-Internal release Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information.

  • Page 4: Instrument Panel

    OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Voice command button Telephone controls Ignition switch (mechanical key) Cruise control VSC/TRAC OFF switch Power rearview mirror control Auxiliary storage Headlight, turn signal and front fog light controls Wiper and washer controls Emergency flasher button Audio system Air Conditioning controls...
  • Page 5 Air Conditioning system Front passenger seatbelt reminder light “AIR BAG ON” and “AIR BAG OFF” indicator Engine immobilizer indicator AUX adapter Tire Pressure Monitoring (warning) System reset Tilt and telescopic steering control Hood lock release lever If equipped Vehicles with navigation system: for details, refer to the “Navigation System Owner’s Manual.”...

  • Page 6: Instrument Cluster

    OVERVIEW Instrument cluster Optitron type meters Non-optitron type meters Service indicator and reminder Tachometer Speedometer Fuel gauge Trip meter reset/Instrument panel light control Odometer and two trip meters Automatic Transmission shift range display (if equipped) Multi-information display Display button Engine coolant temperature...

  • Page 7: Indicator Symbols

    Anti-lock Brake System warning Vehicle Stability Control OFF indicator Low engine oil pressure warning Engine oil replacement reminder If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer.

  • Page 8: Fuel Tank Door Release And Cap

    OVERVIEW Keyless entry (if equipped) Locking operation Unlocking operation Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will Push relock for safety. Trunk lid operation Panic button Push and hold Push and hold Fuel tank door release and cap...

  • Page 9: Hood Release

    Hood release Pull Pull up latch and raise hood Engine maintenance 4 cylinder (2AZ-FE) engine 4 cylinder (2ZR-FE) engine Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank Note: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance.

  • Page 10: Features/Operations

    FEATURES/OPERATIONS Automatic Transmission (if equipped) Standard type Multi-mode type Park* Reverse Park* Neutral Reverse Drive Neutral Third gear Drive Second gear “S” mode First gear “S” “D” * The ignition switch must be “ON” and the brake pedal depressed to shift from Park.
  • Page 11 Automatic door locks can be programmed to operate in two different modes, or turned OFF. Doors lock when shifting from Park. -Doors lock when the vehicle speed is approximately 12 mph or higher. Doors unlock when shifting into Park. -Doors unlock when the driver’s door is opened within 10 seconds after setting the engine switch or “ENGINE START STOP”...
  • Page 12 Lock release button Lock release button Single wipe Adjust frequency* Pull to wash and wipe Interval wipe Slow Fast Rotate to increase/decrease wipe frequency (if equipped). Window lock switch Down Push the switch completely down and release to fully open. To stop window midway, lightly push the switch in the opposite direction.
  • Page 13 Headlights Parking lights High beam Low beam High beam flasher Headlights turn on automatically upon starting engine. The brightness of the headlights will automatically change depending on the darkness of the surroundings. Turn Front fog lights come on only when the headlights are on low beam. Right turn Lane change Lane change...
  • Page 14 Preset buttons - functions in other Eject CD modes indicated above number Push to Push and turn turn to ON/OFF adjust tone & balance Seek Push to skip station/ up/down CD track folder and select radio category Station/CD type track scan View CD text Mode...
  • Page 15 Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. Push and hold “SCAN” to scan preset stations. Push again to hold selection. By inserting a mini plug into the AUX audio jack, you can listen to music from a portable audio device through the...
  • Page 16 Airflow vent In “ ” or “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging. Fan speed Temperature selector Air Conditioning ON/OFF Use for quick cooling. MAX A/C changes air intake to recirculate. It is not possible to change intake to fresh, or to turn A/C OFF in this mode.

  • Page 17: Clock

    System ON/OFF Resume Increase speed Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Display button (1) Clock (2) Outside temperature (3) Current gas mileage (4) Average gas mileage* (5) Miles left on remaining fuel (6) Average vehicle speed from engine start*...

  • Page 18: Voice Command Button

    ® Start call Volume control End call Voice command button ® Bluetooth technology allows dialing or receive calls without taking hands from the steering wheel or using a cable to connect the compatible telephone and the system. Refer to the Owner’s Manual for more details. (1) Push and hold the display button to set the clock.
  • Page 19 Recommended driving position to minimize wind noise. Open Tilt Close Close Push once to open partway; again to open completely. Angle Length Hold wheel, push lever down, set angle and length, and return lever. Lock release lever Note: Do not attempt to adjust while the vehicle is in motion. Unlock Lock...
  • Page 20 Brightness control Pull Pull Pull Push...
  • Page 21 Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely. To find more information about seatbelts, and how to install a child restraint system, refer to the Owner's Manual.
  • Page 22 If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. : The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light.
  • Page 23 Tool box Jack Spare tire (1) Remove the luggage floor cover. (2) Remove the tool tray. (3) Loosen the center fastener that secures the spare tire. Refer to the Owner’s Manual for tire changing and jack positioning procedures.
  • Page 24 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 Printed in U.S.A. 1/09 08-TCS-02940 00505-QRG10-COR...
